AFTI 45

User guide

Telephone with Caller ID

English

2 www.doro.com

English

www.doro.com 3

Installation

Batteries

In order for the Caller ID, memory and other functions to operate, the telephone

requires three good quality AAA 1,5 V alkaline batteries to be installed. If batteries

are either not installed or running low, the symbol will be visible in the display,

you will need to change the batteries as soon as possible.

The battery compartment is located on the underside of the telephone.

1. Ensure the telephone line cord is disconnected from the telephone network

wall socket.

2. Unscrew the retaining screw that holds the battery cover in place and remove

the cover.

3. Install the batteries ensuring correct battery polarity is observed.

4. Replace the battery cover and ret the retaining screw.

Connection

Once the batteries have been installed:

1. Connect the curly cord to the handset and to the socket marked q on the

underside of the telephone.

2. Connect the telephone line cord to the socket marked T on the underside of

the telephone and then to a telephone network wall socket.

3. A click will be heard when the modular plug is correctly in place.

4. Position the cables in the grooves underneath the telephone.

5. Lift the handset and listen for the dial tone. Your telephone is now operational.

Wall Mounting

1. Remove the desktop bracket.

2. Secure two screws, vertically positioned 100 mm apart.

3. The screws should locate into the two ‘keyholes’ on the back of the

telephone.

4. Remove the hanging peg (located by the hook switch) by pushing it upwards.

5. Rotate the hanging peg 180 degrees, and then replace it.

English

4 www.doro.com

Installation

The Display

In the standby mode (handset down, no dial tone) the display will show the

time, total number of new phone calls and the total number of telephone

numbers (70 maximum) that have been stored in the Caller ID memory.

Setting the Time and Date

1. Press W, MEMORY will be displayed.

2. Scroll until SETTINGS is displayed using v/V

. Press 0

3. TIME/DATE will be displayed. Press 0

4. The hour digits will now ash. Scroll until the desired hour (24-hour format)

is displayed using v/V

. Press 0

5. The minute digits will now ash. Scroll until the desired minutes are

displayed using v/V

. Press 0

6. The date digits will now ash. Scroll until the desired date is displayed using

v/V

. Press 0

7. The month digits will now ash. Scroll until the desired month is displayed

using v/V

. Press 0

8. Conrm the programmed settings by pressing C.

Language

The display messages can be shown in the following languages: Swedish,

English, Finnish, Danish, Norwegian, Turkish, German, Dutch, Portuguese,

Italian, Spanish and French.

1. Press W, MEMORY will be displayed.

2. Scroll until SETTINGS is displayed using v/V

. Press 0

3. Scroll until LANGUAGE is displayed using v/V

. Press 0

4. Scroll until the desired language you require is shown using v/V

. Press 0

5. Conrm the programmed settings by pressing C.

English

www.doro.com 5

Operation

Mute Button

The handset microphone can be disabled during a call by pressing z.

Press z once more to reactivate the microphone.

The display will show MUTE for as long as the function is active.

Redial Button

The ve most recently dialled numbers can easily be redialled using r.

1. Press r repeatedly to scroll through the numbers.

2. Press 0

, the selected number will now be dialled.

Volume Control

The handset earpiece volume may be adjusted during a call using . Press

the button once to increase the volume, press again to decrease the volume.

Ringer

The ringer characteristics are adjusted using switches located on the

underside of the telephone:

Ringer volume

Ringer type

Ringer tone

English

6 www.doro.com

Operation

Display Contrast

There are 7 different settings being available for the displays contrast.

1. Press W.

2. Scroll using v/V until SETTINGS is displayed. Press 0

3. Scroll using v/V until LCD is displayed. Press 0

4. Scroll using v/V to the display contrast required (1 light > 7 dark).

5. Conrm the programmed settings by pressing c.

Timer

Approximately 5 seconds after dialling a timer will be shown on the display. The

timer helps you keep track of how long the call lasts.

Recall

Press the recall button R followed by the extension number to transfer calls

when connected to a PBX (TBR only).

Access to additional network services can be gained by using the recall button R,

* and # keys. Contact your network operator for more information.

Hearing Aid Compatible

This telephone is hearing aid compatible. Select the T mode on your hearing

aid to enable this feature.

English

www.doro.com 7

Caller Identication

Explanation of Caller ID

Caller ID allows you to see who is calling before you answer a call, and to see

who has called in your absence. If the number received is stored in the phone

book, that corresponding entry is shown as well.

Numbers received are logged with date and time, and can easily be retrieved for

review or dialling. The call log will store up to 70 telephone numbers.

New calls are indicated by the message waiting indicator light ashing and an

envelope symbol in the display. The display will also indicate the number of calls

both new and total received. The indicator and the envelope will stop ashing as

soon as the new number(s) are reviewed.

When the log is full, the oldest number will be deleted automatically, as a new

call is logged.

Calls from the same telephone number will only be saved in one location.

The symbols x 0-9 state the number of calls received from that particular

telephone number.

Please note!

In order for numbers to be shown, the Caller ID service must be provided by your network

operator and a current subscription in place. Contact your operator for more information.

Retrieving CID phone Numbers

Press v/V to review phone numbers that have been stored in the CID

memory. The telephone will automatically return to standby mode.

Dialling a number from CID

This function allows the telephone number currently shown on the display to

be dialled.

1. Scroll to the desired telephone number using v/V

2. Lift the handset and press 0

. The displayed telephone number will now

be dialled.

English

8 www.doro.com

Caller Identication

Messages

Besides showing telephone numbers, the display may also show a number of

text messages.

UNAVAILABLE It is an International call or a call from a PBX (no

information received)

SECRET Information on the number is blocked. The call could

also be from a PBX.

MESS WAITING Indicated when a message has been received to a

message service with your network operator. The

message waiting light will ash, and the number of calls

will also be displayed.

Erasing Individual Numbers from CID

1. Scroll to the telephone number you wish to erase v/V

2. Press c. The display will show ERASE?

3. Press c again to conrm.

Erasing ALL numbers from CID

1. Scroll to any telephone number in the CID list using v/V .

2. Press and hold c until ERASE ALL? is displayed.

3. Press c again to conrm.

English

www.doro.com 9

Menu Description

The telephone has an easy menu system with distinct display texts.

The following buttons are used to operate the menu system:

W Access menu system.

v/V Used to scroll through the menus.

0 Conrms selected option, and/or moves forward one

step.

c Used to erase or correct, and/or moves back one step.

The menu contains the following main headings:

MEMORY Under this setting you can store, change or erase

entries in the phone book, and the direct memory

(CARE) number.

SETTINGS To programme date and time, display contrast, least cost

routing (LCR) and language selections for display texts.

English

10 www.doro.com

Memory

One-touch Memories

Apart from the phone book (see page 11) there are three One-touch Memory

buttons, M1, M2 and M3. Using One-Touch Memory dialling, a call can be

made by simply pressing one button.

Storing One-touch memories

1. Press w. MEMORY will be displayed. Press 0

2. Scroll until STORE M1/M2/M3 is displayed using v/V

. Press 0

3. Enter telephone number (up to 22 digits). Use c to erase or change.

4. Press 0

5. Enter name. Press the corresponding number button until the rst letter of

the name being entered is displayed, (See table on next page), the cursor will

automatically move, repeat this until the name is entered.

6. Conrm the programmed settings by pressing 0

Please note!

Press r if you want a pause in the telephone number.

In case of a number change, store the new number in the location of the old one following

the procedure above.

Dialling using One-Touch Memories

1. Lift the handset and wait for a dialling tone.

2. Dial the desired number by pressing the corresponding memory location,

M1, M2 or M3.

Memory List

Enter the name or number stored in memory on the memory list. The memory

list is located within the two halves of the Hook switch cover.

1. Open the top half of the Hook switch cover by pulling on the exposed

upper edge.

2. Place the memory list in the recess provided in the bottom half of the Hook

switch cover.

3. Close the top half of the hook switch by carefully clipping it into place.
