Doro CONGRESS 150 Bedienungsanleitung

SENSOR 150

Telephone with calling number display

User guide

AUDIOLINE SENSOR 150 TABLE OF CONTENTS

TABLE OF CONTENTS

Installation ............. 1Calling Number Display .... 7

Location of controls ........ 1Explanation of CND ........... 7

Battery .................. 2New calls ................... 7

Connection .............. 2To view the new call information .. 8

Wall mounting ............ 2Caller display log full ........... 8

Warning ................. 3Dialling from the caller display log .9

The display .............. 3Erase caller display number ...... 9

Setting the date and time ..... 3

Using the telephone ..... 4Phone Book (Memories) ... 10

Ringer volume ............ 4Programming ................. 10

Select Language ........... 4Dialling from memory .......... 11

Handset On/Off ........... 4Erasing ..................... 11

Earpiece volume ........... 4 Answering incoming calls

5 .................. Settings 12 .................... To

make a call ................ 5 Least Cost Routing (LCR) ....... 12

Call timer ................ 5 Programming ................. 12

Last number redial ......... 5

Additional network services .. 5 Other ................. 13

Main Menu ............... 6 Troubleshooting ............ 13

Cleaning ................ 13

REN/RN .................. 13

Thunderstorm Warning ........ 14

Guarantee ................. 14

ABC

WXYZTUVPQRS

MNOJKLGHI

DEF

INSTALLATION AUDIOLINE SENSOR 150

LOCATION OF CONTROLS

1Earpiece 7Scroll UP and * button

2Display 8Microphone

3Talk/OK button 9Scroll DOWN and # button

4Menu button 10 Recall button

5Last number redial 11 End call/Erase button

6Keypad 0-9 12 New call indicator

AUDIOLINE SENSOR 150 INSTALLATION

BATTERY

3x1.5 V batteries (AAA) must be installed, otherwise functions such as caller display,

memory etc will not work. When the batteries are low the symbol will illuminate on

the display.

PRemove the line cord before installing or replacing batteries.

PRemove the screw from the battery compartment on the rear of the handset. Fit the

batteries (supplied) observing correct polarity.

NOTE: For the telephone to operate correctly batteries must be installed. If no

batteries are installed the talk button must be pressed and held down for 1-2 seconds

to access the telephone line.

CONNECTION

PFit the batteries, as described above.

PConnect the line cord to a telephone wall socket.

WALL MOUNTING

The telephone can be placed on the desk or on the wall with the supplied wall bracket.

Check for hidden cables, water pipes, etc, before drilling holes, also ensure that the

intended mounting point is within reach of a telephone socket.

PUse the wall bracket provided to mark two holes (86 mm apart) on a wall, one above

the other.

PHold the wall bracket to the wall and secure with two screws (not supplied.)

WARNING The handset may retain small ferromagnetic objects, such as pins

and staples around the earpiece. To prevent injury, you should check for the

presence of these objects before use.

INSTALLATION AUDIOLINE SENSOR 150

THE DISPLAY

When the Sensor 150 is in standby mode, the 11 character/13 digit display will show the

current date and time, how many incoming calls are stored in the caller log, and if the

battery is low.

Text information

Incoming telephone number

Low battery

New call Number Time Date

indicator of calls

SETTING THE DATE AND TIME

PPress the MENU button. The display will show "VOLUME"

PPress the button repeatedly until the display shows "SETTING". Press OK.

PPress the button repeatedly until the display shows "SET TIME". Press OK.

PThe hour digit(s) will flash on the display. Use the buttons to set the

correct hour. Press OK to store the setting.

PSet the minute, day and month in the same way. Press OK after every setting.

PPress the Cbutton to store the setting and return to standby.

AUDIOLINE SENSOR 150 USING THE TELEPHONE

RINGER VOLUME

The ringer can be set to either high, low or off.

nPress the MENU button. The display will show "VOLUME".

nPress theor buttons until the display shows "SETTING". Press OK.

nThe display will show "RING". Press OK.

nThe display shows the current setting (2 = High, 1 = Low, 0 = Off).

nPress the or buttons to set the volume. Press OK.

SELECT LANGUAGE

The Sensor 150 can change the display texts language. The languages available are

English, German, French and Spanish.

nPress the MENU button. The display will show "VOLUME".

nPress the or buttons until the display show "SETTING". Press OK.

nPress the or buttons until the display show "LANGUAGE". Press OK.

nThe display will show the current setting.

nPress the or buttons to select the desired language. Press OK.

HANDSET ON/OFF

The Sensor 150 does not have a hook switch. Access to the telephone line is via two

buttons, TALK/OK and END CALL/C.

#Press the TALK/OK button you will hear dial tone.

#Press the END CALL/C button to terminate the call.

EARPIECE VOLUME

The earpiece volume can be set to two levels (1=low, 2=high).

nPress the MENU button. The display will show "VOLUME". Press OK.

nPress the or buttons to set the volume. Press OK.

USING THE TELEPHONE AUDIOLINE SENSOR 150

ANSWERING INCOMING CALLS

nTo answer an incoming call press the TALK/OK button

nPress the End Call button to terminate the call.

NOTE: For the telephone to operate correctly batteries must be installed. If batteries

are not installed the talk button must be pressed and held down for 1-2 seconds to

access the telephone line.

TO MAKE A CALL

nDial the telephone number you wish to call. If you enter an incorrect digit this can be

erased using the Cbutton.

#Press the TALK/OK button .

#Press the END CALL/C button to terminate the call.

Alternatively

#Press the TALK/OK and then dial the telephone number required.

#Press the END CALL/C button to terminate the call.

CALL TIMER

Afew seconds after a call has started, the call timer will display the elapsed time of the

call.

LAST NUMBER REDIAL

If the last number dialled was engaged or the call was not answered, it is possible to redial

the number using the Redial button .

nPress the last number Redial button .

nPress the TALK/OK button.

ADDITIONAL NETWORK SERVICES

Network services such as call waiting, call forward etc., can be accessed via the Recall

[R], #and *buttons. For further information, contact your Network Operator.

AUDIOLINE SENSOR 150 USING THE TELEPHONE

MAIN MENU

The Sensor 150 has a simple menu system which displays texts, this is accessed using

five buttons.

The MENU button is used to enter the menu system.

The and buttons are used to scroll through the menu system.

The OK button is used to confirm your choice.

The Cbutton is used to erase an incorrect entry.

THE MAIN MENU HAS FOUR HEADINGS:

VOLUME - Earpiece volume

You can select the earpiece volume required. See page 4 for more information.

CALLER ID - Calling Number Display

The incoming telephone numbers can be displayed and dialled. See pages 7-9 for more

information.

PHONE BOOK - Memories

Most frequently dialled telephone numbers/names can be stored into memory. See pages

10-11 for more information.

SETTING - Settings

All of the settings for the telephone ringer, language etc can be altered. See page 4 for

more information.

CALLING NUMBER DISPLAY AUDIOLINE SENSOR 150

EXPLANATION OF CALLING NUMBER DISPLAY

Calling Number Display allows you to see who is calling before you answer a call, and

also to see who called in your absence. When you have subscribed with your telephone

network service provider to the "Calling Number Display" service, the telephone number,

name (if the number is stored in the phonebook), date and time of your calls will be

displayed. Up to 15 numbers can be stored in the Sensor 150 call log.

It is not possible to view the call log and take a new call at the same time.

NOTE: Calling Number Display is an optional telephone Network service. This

telephone will provide Calling Number Display information provided the service is

available via your Network service provider and any subscription charges have been

paid. Check with your service provider for full details.

If the Calling Number Display service is not implemented on your telephone line,

incoming call information will not be displayed.

NEW CALLS

When a new call is received the new call indicator at the top of the telephone will flash,

the words "NEW CALLS" and the total number of new calls will be displayed.

Below is an example of four new numbers/calls, with a total of thirteen calls in the call log.

AUDIOLINE SENSOR 150 CALLING NUMBER DISPLAY

TO VIEW THE NEW CALL INFORMATION

nPress the MENU button. The display will show "VOLUME"

nPress the button until the display shows "CALLER ID". Press OK.

nPress the or to see the incoming telephone numbers.

nPress the MENU button to exit.

The button scrolls from the beginning of the call log, showing the oldest telephone

number first.

The button scrolls from the end of the call log, showing the newest telephone

number first.

The time & date when a call is received, the phone number and the ascending caller

displaylog number will be shown. For example: Phone number 0462805000, time

received 18:08 on the 16th of October. Caller display ID log number is 20. DORO is

stored in the phonebook memory.

OUT OF AREA

If the display shows "OUT OF AREA" instead of a telephone number, this means that

no information was received from the Network. The call may have been an international

call or from a PBX.

PROTECT

If the display shows "PROTECT" it indicates that the calling number is an unlisted

(silent) number or the caller has barred the number so it will not be displayed. It could

also come from a mobile telephone or a PBX.

CALLER DISPLAY LOG FULL

When the call log is full (15 calls) the oldest call will be deleted automatically.
