Dot Origin VTAP100-PAC-W Bedienungsanleitung

Installation Guide -

VTAP100 WiegandReader

VTAP100-PAC-W

Revised November 2023 v3.1

If you need help to set up or use your VTAP100, beyond what is contained in this Installation

Guide, then please contact our support team.

Email: [email protected]

Download the latest documentation and firmware from https://vtapnfc.com

Telephone UK and Europe: +44 (0) 1428 685861

Telephone North America and Latin America: +1 (562) 262-9642

If you have any feedback on setting up or using your VTAP100 or this documentation, then

please contact our support team. The product is constantly being reviewed and improved and

we value feedback about your experience.

No part of this Installation Guide may be published or reproduced without the written

permission of Dot Origin Ltd except for personal use. This Installation Guide relates to correct

use of the VTAP100 only. No liability can be accepted under any circumstances relating to the

operation of the user’s own PC, network or infrastructure.

Dot Origin Ltd

Unit 7, Coopers Place Business Park, Combe Lane, Wormley

Godalming GU8 5SZ United Kingdom

+44 (0) 1428 685861

Contents

1 Using this guide 1

2 How the VTAP100 works 2

2.1 Test using factory settings 3

2.2 Start reading your own passes 3

2.3 Check status in BOOT.TXT 7

2.4 Send pass payload over a Wiegand interface 9

2.5 Wiegand wiring (for model VTAP100-PAC-W only) 12

3 Choose a location for your VTAP100 21

4 Obtain a custom label for the case 23

5 Mount a VTAP100 25

6 Hardware lock to disable USB mass storage device 27

7 Find your hardware version 29

8 Disposal 30

VTAP100-PAC-W INSTALLATION GUIDE © DOT ORIGIN PAGE I

VTAP MOBILE WALLET READERS

Safety instructions

WARNING: INTENDEDUSE

The VTAP100-PAC-W are boxed products for end-users. Although the enclosure may be

opened when the device is not connected, components mounted on the VTAP PCB are not

user-serviceable.

WARNING: ESD PRECAUTIONS

If the enclosure is opened to access the PCB, we recommend careful handling of

Electrostatic Sensitive Devices (ESDs) .

WARNING: POWERSUPPLY

Use a standard micro-USB cable to connect the VTAP100-PAC-W model to a PC or

alternatively power the unit by connecting it to an access controller, using the Wiegand

connector cable. If the VTAP100 is being powered through its Wiegand connector, you can

still make an additional USB data connection to a PC, provided that the PC is already

powered before the connection is made.

EMC emissions and immunity certifications are only valid when using the VTAP100-PAC-W

with the supplied cable.

VTAP100-PAC-W INSTALLATION GUIDE © DOT ORIGIN PAGE II

VTAP MOBILE WALLET READERS

1  Using this guide

This guide is for first-time users of the VTAP100-PAC-W.

Figure 1-1 VTAP100 in compact (-CC) or square (-SQ) case

It contains the information you need to install your VTAP100.

Consult the VTAP Configuration Guide for more about custom configuration and

maintenance features for any VTAP100, including how to update the firmware on your

VTAP100-PAC-W, when a new release is available.

If you need help beyond what is contained in this guide please contact

[email protected].

VTAP100-PAC-W INSTALLATION GUIDE © DOT ORIGIN PAGE 1

VTAP MOBILE WALLET READERS

VTAP100-PAC-W INSTALLATION GUIDE © DOT ORIGIN PAGE 2

2  How the VTAP100 works

With the VTAP100-PAC-W connected to a PC, simply tap your smartphone against the

VTAP. Your mobile NFC pass will be read and data sent to the connected PC. The extra

facility with the VTAP100-PAC-W model only, is that it can alternatively be connected to an

access controller, using the Wiegand connector supplied.

Of course, the data can only be read if your phone contains a mobile NFC pass, which has

been issued in connection with the Merchant ID(s)/Collector ID(s) and ECC key(s) that are

known to the VTAP. The unit comes with default values, so that you can test Test using

factory settings before you begin customising any settings.

When the VTAP100-PAC-W is connected to a computer it appears as a generic mass storage

device (like a memory stick). To configure your VTAP, you simply edit or create text files.

These will be read automatically, and control the operation of the VTAP. There is information

in Start reading your own passes to take the first steps to configure your VTAP for use. The

VTAP100-PAC-W must be configured over USB from a PC, before it will send pass data over

the Wiegand interface. After being configured it does not need to be connected to a PC.

Consult the VTAP Configuration Guide for more detail.

By default the VTAP is fully upgradable in the field. However, the VTAP can be locked in

software or hardware, before deploying the unit, so that operation is no longer easily

changed.

VTAP MOBILE WALLET READERS

2.1 Test using factory settings

Before anyone changes the configuration from its default, you can confirm that the unit is

working.

These steps demonstrate that the hardware can detect and interact with an OriginPass demo

mobile NFC pass, which is ready to work with the default configuration of your VTAP100.

1. Obtain an OriginPass from Dot Origin by visiting https://originpass.com/VTAP/ and add it

to Google or Apple Wallet. (You will require a username and password - contact

[email protected] to get these.)

2. Connect the VTAP100 to your PC, using a USB cable.

3. Open a text editor, such as Windows Notepad.

4. When you tap the OriginPass on the VTAP100:

lPass contents will be displayed in the open text editor, through keyboard/barcode

emulation.

lThe feedback LEDs on the VTAP100 PCB will flash green.

lYour smartphone may signal with a buzz or beep.

Note: Some Android phones will only interact if their screen is on, although it does not

need to be unlocked. You may need to enable NFC in the settings for the smartphone.

Note: If the pass detected does not match the key and ID on the VTAP, or is moved away

too quickly to be read, the pass contents displayed may be an 8 digit random hex string,

such as '08E22AC1', different on each presentation. OriginPass contents will be a

consistent string, such as '3~ffymeK9f_mziYtA6~53999301628695~Valued'. Any

separator, such as '~' or '|', will depend on your keyboard language settings. (See VTAP

Commands Reference Guide for option to ignore random UIDs if needed.)

Note: If local security settings prevent or limit the use of removable storage devices, or

the connection of additional keyboards, an administrator may need to alter those

permissions.

2.2 Start reading your own passes

If you navigate to the VTAP in the computer's file system, it will appear as an attached mass

storage device and list the files contained, including the main config.txt file.

To read any mobile NFC pass, you will need to provide your pass reading parameters in the

config.txt file. This means a collector ID or merchant ID and ECC keys. These allow you to

read and decrypt pass data that is held by your users, on their smartphones.

VTAP100-PAC-W INSTALLATION GUIDE © DOT ORIGIN PAGE 3

VTAP MOBILE WALLET READERS

VTAP100-PAC-W INSTALLATION GUIDE © DOT ORIGIN PAGE 4

This first time, you will need to connect the VTAP100 to your PC, using a USB cable. (If

needed, you can make changes remotely in future over a virtual COM port or serial port, see

VTAP Serial Interface Guide.)

Step 1: Upload private key file(s) to your VTAP100

1. Ensure these are ECC private key(s), and each is stored in a file with the name

private#.pem, following the .pem format, where # is replaced with a number from 1

to 6, matching the key slot you will save it in. (The demo passes are accessed using the

key in KeySlot 6, so don't overwrite this one unless you are finished with demo passes.)

Note: You cannot use more than 6 key files.

2. Load your keys by copying these files onto your VTAP100, which shows up in the file

system of your PC as a mass storage device.

Note: When you reboot the VTAP100 your key will have been stored in hardware, and

will no longer be listed as a file on the device. You can confirm key file(s) have been

loaded when you Check status in BOOT.TXT. If the key file does not disappear and

there is an error in Boot.txt, check your .pem file as it is likely it did not adhere to the

standard - perhaps it was not an ECC key?

VTAP MOBILE WALLET READERS

Step 2:Declare Merchant ID(s)/Collector ID(s) in the config.txt file

1. Open the file config.txt in a text editor (such as Windows Notepad). It already

contains parameters for accessing the demo passes, prefixed VAS1 and ST1, both relying

on KeySlot 6. You can overwrite these, or keep them in addition to your own pass

reading parameters.

2. Add your pass reading parameters in the config.txt file to access up to 6 Apple

VAS and up to 6 Google Smart Tap IDs, and identify the keys to be used in each case.

Note: Although the VTAP100 supports multiple IDs, Apple expect most users will only

use one. Multiple collector IDs are not supported by Android, which means you cannot

request more than one Collector ID from Google. Only one should be live at any one

time. Multiple IDs is an advanced feature that should be used with care. The VAS# and

ST# numbers define the order in which IDs will be requested from Apple or Android

phones respectively. The lowest numbered ID will be requested first, then continuing in

ascending numeric order.

Put each parameter on a new line. Order of parameters does not matter to the

VTAP100, but could help other people who need to edit the file. Start any comment

lines in the config.txt file, that the VTAP100 should ignore, with a semicolon. Each

parameter should only appear once - if it accidentally appears more than once then only

the last instance will take effect.

Example:Settings in config.txt to interact with both

Apple VASand Google Smart Tap mobile passes

!VTAPconfig



VAS1MerchantID=<yourmerchantID>

VAS1KeySlot=1

;Thissaysusethekeyaddedasfile'private1.pem'toreadand

;decryptanypassconnectedtoyourmerchantIDonanAppleiPhone



ST1CollectorID=<yourcollectorID>

ST1KeySlot=2

ST1KeyVersion=1

;Thissaysusethekeyaddedasfile'private2.pem'atkeyversion1

;toreadanddecryptanypassconnectedtoyourcollectorID

;onanAndroidphone

3. Save the amended config.txt file and these changes will take effect immediately. (A small

number of changes to the config.txt file require a reboot to take effect, for instance

to the status of the virtual COM port, but these are highlighted in later sections).

VTAP MOBILE WALLET READERS

Note: If a VAS#KeySlot parameter is omitted, or set to 0, then all available keys will be

automatically tried to choose the right key. If the data received by the VTAP100 cannot be

decrypted, the Apple iphone will register a pass read, but the data will not be output.

Note: If an ST#KeySlot parameter is omitted, or set to 0, then authentication will be

omitted and decryption will not be performed. In this case, Google Smart Tap data will be

received and sent on by the VTAP100, only if the pass does not require authentication by

the terminal.
