LED Lichtmanagement-Netzteil CASAMBI
LED Light management power supply CASAMBI
4941-350 4941-500
4941-700 4941-950
DE
Bedienungsanleitung
EN
User manual
09/2020
Abmessungen / dimensions
Eingangsspannung / input voltage
Frequenzbereich / frequency
Max. Eingangsstrom / max. input current
Leistungsfaktor / power factor
Technische Daten / technical details
4941-350
215x70x31mm
176-240 V AC/DC
50/60 Hz
max. 0,22 A
0,96
87%
CASAMBI / PUSH-Dim
20- 50 V DC
350mA
38 W
-25°C - +60°C
IP20
75°C
Ausgangsspannung/ output voltage
Ausgangsstrom/ output current
Effizienz / efficiency
Ausgangsleistung
dimmbar / dimmable
IP-Schutz / Waterproof rating
Umgebungstemperatur / ambient temp.
Tc Temperatur / tc temperautre
5. Operating Note
- A bluetooth enabled device is required for setting of
dimming function
- Follow the instructions given on Casambi App
6. Recycling information
- If this symbol is displayed on a product, this
product is covered under the European
Guidelines 2012/16/EU.
- All old electrical and electronic devices as
well as batteries must be disposed of separately from
household garbage, at specially provided public
locations.
- By properly disposing of the old device, you avoid
damage to the environment and endangerment of the
personal health.
- Further information on the disposal of old appliances
may be obtained from the Town Hall, the local or
municipal waste disposal authority or the shop or
business from which you obtained the product.
7. Declaration of conformity CE
This product fulfils the requirements of the
applicable European and national directives
(Radio Equipment Directive 2014/53/EU
RoHS Directive 2011/65/EU). Conformity has been
demonstrated. The relevant declarations and
documents are held by the manufacturer.
Please find the EU-declaration of conformity
under the following link:
http://www.dotlux.de/konformitaetserklaerungen/
8. Manufacturer
Dotlux GmbH
Richard -Stuecklen-Str. 7, 91781 Weißenburg
Phone: +49 9141/4051 0 Fax: +49 9141/4051 999
www.dotlux.de
Thank you for choosing a DOTLUX product.
To ensure correct and safe installation, usage and
functioning of the product, always follow these
instructions carefully and keep them for future reference.
1. Package Contents
- Driver
- this user manual
- Note - Please check that the set is complete before
using it and ensure that none of the parts are faulty or
damaged.
2. Safety Notes
- Warning - danger of life! Always disconnect the power
supply prior to installation, maintenance or repair
activities.
- Electronic work may only be performed by authorised
specialists.
- Always consider all technical specifications of the
product.
- Protect the product from dirt, moisture and overheating.
- Only connect the product to the specified voltage.
- Use only a dry cloth to clean the product.
- Note - The light source of this product is
non-replaceable. At the end of the life of the light source
the whole product need to be replaced.
- In the event of damage to the product, stop using the
product.
- Repair work may only be performed by authorised
specialists.
3. Intended Use
- This product is intended for indoor use.
- Only use the product for the intended purpose.
4. Warranty Disclaimer
Dotlux GmbH assumes no liability and provides no
warranty for damage resulting from improber
installation/mounting, improber use of the product
or from failure to observe the operating instructions
and/or safety notes.
EN
User manual
4941-500
215x70x31mm
176-240 V AC/DC
50/60 Hz
max. 0,22 A
0,96
87%
CASAMBI / PUSH-Dim
20- 50 V DC
500mA
38 W
-25°C - +55°C
IP20
75°C
4941-950
215x70x31mm
176-240 V AC/DC
50/60 Hz
max. 0,22 A
0,96
87%
CASAMBI / PUSH-Dim
20- 40 V DC
950mA
38 W
-25°C - +50°C
IP20
75°C
4941-700
215x70x31mm
176-240 V AC/DC
50/60 Hz
max. 0,22 A
0,96
87%
CASAMBI / PUSH-Dim
20- 50 V DC
700mA
38 W
-25°C - +55°C
IP20
75°C
