DOUXE DTS-01 Bedienungsanleitung
DTS-01 – TV wall mount
Instruction Manual
Congratulations on your product purchase and thank you
for choosing Douxe products. This is the Douxe DTS-01 –
TV wall mount. It is a fully adjustable mount designed to
support up to 35kg (77lbs) in load capacity for TV sizes
between 17”- 60”. It can be installed on wood studs or
concrete wall surfaces. The retractable mounting arm has
three joints that provide horizontal swivel action (±90°
and ±180°). It also provides a -5° ~ +8° tilt f or optimal
viewing comfort.
To ensure proper installation and avoid property damage
or personal injury, please read the following instructions
carefully. Please keep this manual in a safe place for
future reference.
2. Warnings and Safety Instructions
1. Introduction
1
•Please do not begin installation until you have
thoroughly read and understood these instructions.
•Do not exceed the maximum load capacity for this
product − 35kg(77lbs).
•Improper installation may cause property damage
and/or personal injury.
•Use only recommended mounting surfaces: wood
stud and solid flat concrete/brick. For installation on
any other surface, use suitable hardware (not
included).
•Do not install on surfaces that are prone to vibration,
movement, or impact. Do not install near heat
sources or air-conditioning.
When receiving your shipment, make sure that the
contents are consistent with the packing list. Notify your
distributor of any missing items. If the equipment appears
to be damaged, file a claim immediately with the carrier
and notify your distributor at once, giving a detailed
description of any damage. Save the damaged packing
container to substantiate your claim.
Extended arms Extendible mount
•This product contains small parts that may constitute
choking hazards. Please keep these items as well as the
product packaging away from children.
3. Safety Information
•Please make use of proper safety equipment during
installation.
• To enable proper support and handling, it is
recommended that two people perform this
installation.
•Please consult a qualified contractor or installation
specialist in the case of any uncertainty or ambiguity.
pment
5. Contents of Package
2
4.Receiving your shipment
A. M4x25 screws (x4) B. M5x25 screws (x4)
C. M6x25 screws (x4) D. 6 Flat washer (x4)
E. 12mm Plastic sleeve (x4) F. 10mm Wrench
L. M6 nut (×4)
3
G. M7x70 Self-tap screw (x4) H. 10x60 Plastic Anchor (x4)
L. M6x12 Screws (x4)
6.Product Specification
Material
Surface Finish
Color
Recommended Screen
Size
Installation
Rated Weight Capacity
Distance to Wall
Tilt
Swivel
Rotation
Max.VESA
Metal
Powder Coated
Black
17”- 60”
Wooden, solid and plaster wall
35kgs/77lbs
62 - 424 mm
+5°/-15°
180°
±3°
400×400mm
4
7.Installation Instructions
5
Step 1
Remove clips and plastic cover as shown.
F
6
Step 2A
For wood stud wall mounting.
G
70m
m
2.
84.5m
m
7
Step 2B
For solid brick and concrete mounting.
G
H
70mm
2.8
10mm
8
Step 3A
Installing of TV with interface.
(A/B/C)+D,E
9
Step 3B
Installing of TV with interface.
(A/B/C)+D,E
F
J I
