DPtech LSW5602 Ethernet Switch Installation Manual

DPtech LSW5602 Ethernet Switch

Installation Manual

DPtech LSW5602 Ethernet Switch Installation Manual

Hangzhou DPtech Technologies Co., Ltd. provides full- range technical support.

If you need any help, please contact Hangzhou DPtech Technologies Co., Ltd. and its sale agent, according to where

you purchase their products.

Hangzhou DPtech Technologies Co., Ltd.

Address: 6th floor, zhongcai mansion, 68 tonghelu, Binjiangqu, Hangzhoushi

Address code: 310051

DPtech LSW5602 Ethernet Switch Installation Manual

iii

Declaration

Hangzhou DPtech Technology Co., Ltd.

No Part ofthe manual can be extracted or copied by any company or individuals without written permission, and can

not be transmitted by any means.

Owing to product upgrading or other reasons, information in this manual is subject to change. Hangzhou DPtech

Technology Co., Ltd has the right to modify the content in this manual, as it is a user guides, Hangzhou DPtech

Technology Co., Ltd made every effort in the preparation of this document to ensure accuracy of the contents, but all

statements, information, and recommendations in this document do not constitute the warranty of any kind express

or implied.

DPtech LSW5602 Ethernet Switch Installation Manual

Table of Contents

CHAPTER 1 PRODUCT INTRODUCTION........................................................................................1-2

1.1 PRODUCT OVERVIEW ........................................................................................................................1-2

1.2 PRODUCT MODEL AND SPECIFICATION.............................................................................................1-2

1.3 FRONT PANEL AND REAR PANEL OF THE SWITCH ............................................................................1-5

1.3.1PRODUCT APPEARANCE OF THE LSW5602-44GT4GC SWITCH..........................................................1-5

1.3.2PRODUCT APPEARANCE OF THE LSW5602-44GT4GC-PWR SWITCH ................................................1-8

1.3.3PRODUCT APPEARANCE OF THE LSW5602-16GT8GC SWITCH........................................................ 1-11

1.3.4PRODUCT APPEARANCE OF THE LSW5602-16GT8GC-PWR SWITCH .............................................. 1-14

1.3.5PRODUCT APPEARANCE OF THE LSW5602-16GP8GC SWITCH ........................................................ 1-17

1.4 PORT INTRODUCTION ...................................................................................................................... 1-19

1.4.1 CONSOLE PORT............................................................................................................................... 1-19

1.4.2 10/100/1000BASE-T ETHERNET ELECTRICAL INTERFACE ............................................................... 1-20

1.4.3 SFP INTERFACE .............................................................................................................................. 1-21

1.4.4 COMBO PORT ................................................................................................................................. 1-24

1.5 INSERT CARD MODULE.................................................................................................................... 1-25

1.5.1 INTERFACE BOARD （LSW-1XGES）........................................................................................... 1-25

1.5.2 INTERFACE BOARD（LSW-2XGES）............................................................................................. 1-27

1.5.3 INTERFACE BOARD（LSW-2GEP）............................................................................................... 1-29

1.5.4 INTERFACE BOARD（LSW- 2XCX4）........................................................................................... 1-31

1.6 PRODUCT ASSEMBLY....................................................................................................................... 1-33

1.6.1PROCESSOR AND STORAGE ............................................................................................................. 1-33

1.6.2 INTERFACES ................................................................................................................................... 1-34

CHAPTER 2 INSTALLATION PREPARATION................................................................................2-1

2.1 GENERAL SAFETY RECOMMENDATIONS ...........................................................................................2-1

2.2 EXAMINING THE INSTALLATION SITE ...............................................................................................2-1

2.2.1 TEMPERATURE AND HUMIDITY REQUIREMENT .................................................................................2-1

2.2.2 CLEANLINESS...................................................................................................................................2-2

2.2.3 ESD REQUIREMENT..........................................................................................................................2-3

2.2.4 ANTI-INTERFERENCE REQUIREMENT................................................................................................. 2-3

2.2.5 LIGHTNING PROTECTION ..................................................................................................................2-3

2.2.6 GROUNDING REQUIREMENT ............................................................................................................. 2-4

2.2.7 WIRING CABLE REQUIREMENT .........................................................................................................2-4

2.3 LASER SAFETY...................................................................................................................................2-4

2.4 PREPARING TOOLS ............................................................................................................................2-4

DPtech LSW5602 Ethernet Switch Installation Manual

CHAPTER 3 DEVICE INSTALLATION.............................................................................................3-1

3.1 INSTALLATION PREPARATION...........................................................................................................3-1

3.2 INSTALLATION PROCEDURE ..............................................................................................................3-2

3.3MOUNTING THE SWITCH TO A SPECIFIC SITE ...................................................................................3-4

3.3.1 MOUNTING SWITCH ON WORKBENCH...............................................................................................3-4

3.3.2 MOUNTING SWITCH IN A 19-INCH RACK........................................................................................... 3-5

3.4 CONNECTING GROUNDING WIRES ....................................................................................................3-6

3.5 CONNECTING INTERFACE CABLE......................................................................................................3-7

3.5.1 CONNECTING CONFIGURATION PORT CABLE ....................................................................................3-7

3.5.2 CONNECTING ETHERNET MANAGEMENT PORT .................................................................................3-8

3.5.3 CONNECTING SERVICE PORT ............................................................................................................3-8

3.6 CONNECTING POWER CABLE ............................................................................................................3-8

3.6.1 CONNECTING ALTERNATING POWER CABLE.....................................................................................3-8

3.6.2 CONNECTING REDUNDANCY POWER CABLE..................................................................................... 3-9

3.7 VERIFY THE INSTALLATION...............................................................................................................3-9

CHAPTER 4 STARTING UP THE SWITCH AND UPGRADING SOFTWARE..............................4-1

4.1 STARTING UP THE SWITCH AT THE INITIAL BOOT ............................................................................4-1

4.1.1 SETTING UP A CONFIGURATION ENVIRONMENT ................................................................................4-1

4.1.2 BOOTING THE SWITCH...................................................................................................................... 4-5

4.1.3 STARTING PROCEDURE.....................................................................................................................4-6

4.2 DEFAULT LOGIN METHOD FOR WEB ................................................................................................4-7

CHAPTER 5 MAINTENANCE AND TROUBLESHOOTING............................................................5-9

5.1 DEALING WITH POWER SYSTEM FAILURES.......................................................................................5-9

5.2 DEVICE TROUBLESHOOTING .............................................................................................................5-9

5.2.1 NO DISPLAY ON THE TERMINAL ........................................................................................................5-9

5.2.2 GARBLED CHARACTERS ON THE TERMINAL..................................................................................... 5-10

DPtech LSW5602 Ethernet Switch Installation Manual

List of Figures

Figure1-1 LSW5602-44GT4GC front panel ............................................................................................................... 1-6

Figure1-2 LSW5602-44GT4GC front panel LED ...................................................................................................... 1-8

Figure1-3 LSW5602-44GT4GC rear view.................................................................................................................. 1-8

Figure1-4 LSW5602-44GT4GC-PWR front view...................................................................................................... 1-9

Figure1-5 LSW5602-44GT4GC-PWR front panel LED.......................................................................................... 1-11

Figure1-6 LSW5602-44GT4GC-PWR rear view ..................................................................................................... 1-11

Figure1-7 LSW5602-16GT8GC front view .............................................................................................................. 1-12

Figure1-8 LSW5602-16GT8GC front panel LED .................................................................................................... 1-13

Figure1-9 LSW5602-16GT8GC rear view................................................................................................................ 1-14

Figure1-10 LSW5602-16GT8GC-PWR front view.................................................................................................. 1-14

Figure1-11 LSW5602-16GT8GC-PWR front panel LED........................................................................................ 1-16

Figure1-12 LSW5602-16GT8GC-PWR rear view ................................................................................................... 1-16

Figure1-13 LSW5602-16GP8GC front view ............................................................................................................ 1-17

Figure1-14 LSW5602-16GP8GC front panel LED .................................................................................................. 1-19

Figure1-15 LSW5602-16GP8GC rear view.............................................................................................................. 1-19

Figure1-16 RJ45 pinout diagram................................................................................................................................ 1-21

Figure1-17 Ethernet cable diagram............................................................................................................................ 1-21

Figure1-18 LC connector diagram ............................................................................................................................. 1-23

Figure1-19 SC connector diagram ............................................................................................................................. 1-23

Figure1-20 Optical module diagram .......................................................................................................................... 1-24

Figure1-21 Front View of the DPtech LSW-1XGES ............................................................................................... 1-25

Figure1-22 Front view of the DPtech LSW-2XGES switch .................................................................................... 1-27

Figure1-23 DPtech LSW-2XGES operation status indicator................................................................................... 1-28

Figure1-24 Front view of the DPtech LSW-2GEP switch ....................................................................................... 1-29

Figure1-25 DPtech LSW-2GEP operation status indicator light ............................................................................. 1-30

Figure1-26 Front view of the LSW- 2XCX4 switch................................................................................................. 1-32

Figure1-27 Ethernet interface..................................................................................................................................... 1-35

Figure3-1 Switch installation procedure...................................................................................................................... 3-4

Figure3-2 Mounting device on the workbench ........................................................................................................... 3-5

Figure3-3 Mounting ear................................................................................................................................................ 3-5

Figure3-4 Mounting the device to a rack (To see the image clearly, we only snapshot the device) ...................... 3-5

Figure3-5 Fasten the switch.......................................................................................................................................... 3-6

Figure3-6 Diagram for connecting grounding wire（take LSW5602-44GTGGCas example）............................ 3-6

Figure3-7 Connecting ground cable to the ground row.............................................................................................. 3-7

Figure3-8 Diagram for the power cord connection（take LSW5602-44GTGGC as example）............................ 3-9

Figure4-1 Network diagram for configuring the device initial boot through console port ...................................... 4-1

Figure4-2 Setting up a new connection ....................................................................................................................... 4-2

Figure4-3 Setting the connection port.......................................................................................................................... 4-2

Figure4-4 Setting communications parameters........................................................................................................... 4-3

Figure4-5 Hyper Terminal............................................................................................................................................ 4-4

Figure4-6 Settings tab................................................................................................................................................... 4-5

DPtech LSW5602 Ethernet Switch Installation Manual

Figure4-7 Web management interface......................................................................................................................... 4-8

DPtech LSW5602 Ethernet Switch Installation Manual

Chapter1 Product Introduction

1-1

List of Tables

Table1-1 Console port properties 1-19

Table1-2 Gigabit Ethernet electrical interface properties 1-20

Table1-3 Attributes of the GbE optical interface 1-21

Table1-4 Relationship between two ports 1-24

Table1-5 10GE Ethernet optical interface attributes 1-26

Table1-6 GbE interface attributes 1-30

Table1-7 GbE interface attributes 1-32

Table2-1 Temperature/humidity requirement 2-2

Table2-2 Dust limit in the equipment room 2-2

Table2-3 Limit of harmful gases in the equipment room 2-2

Table4-1 Configure serial port properties 4-3

DPtech LSW5602 Ethernet Switch Installation Manual

Chapter1 Product Introduction

1-2

Chapter 1 Product Introduction

1.1 Product Overview

DPtech LSW5600 series switches are DPtech self-owned products aiming at enterprise network and

metropolitan area network of convergence layer or access layer’s devices, providing users with rich

service and routing features. Meanwhile, they also can be used to connect to data center’s server farm.

DPtech LSW3600 series switches provides line-speed Ethernet Layer 2 switching capacity with

10/100/1000M different accessing and process capacity enlarging the products application range.

1.2 Product Model and Specification

At present, the DPtech LSW5602 series commercial switches includes the followings:

LSW5602-44GT4GC

LSW5602-16GT8GC

LSW5602-16GP8GC

LSW5602-44GT4GC-PWR

LSW5602-16GT8GC-PWR

The specification of DPtech LSW5602 series is shown as following:

Item

LSW5602-44GT4GC

LSW5602-16GT8GC

LSW5602-16GP8GC

Dimension（W×D×H）

440mm*320mm*44mm

Weight

4.5Kg

5.0Kg

Management port

1 console port, on the front panel

GE port on front panel

44 Ethernet electrical

interfaces (RJ45).

4 1000Base-X Ethernet

optical interfaces (SFP).

24 10/100/1000Base-T

Ethernet electrical

interfaces (RJ45).

8 Ethernet electrical

interfaces (RJ45).

24 1000Base-X Ethernet

optical interfaces (SFP).

8 Ethernet electrical

interfaces (RJ45).

Last four

10/100/1000Base-T

Ethernet ports and

Last eight 10/100/1000Base-T Ethernet ports

and the corresponding SFP pot form Combo

port.

DPtech LSW5602 Ethernet Switch Installation Manual

Chapter1 Product Introduction

1-3

Item

LSW5602-44GT4GC

LSW5602-16GT8GC

LSW5602-16GP8GC

the corresponding

SFP pot form

Combo port.

Note: only one port can be used when two Combo ports form at the

same time.

supporting interface module

supported

There are two interface module at rear panel, you can select:

Dual ports GE SFP interface module expansion card: LSW-2GEP.

Short distance dual ports 10GE CX4 interface module expansion card:

LSW-2XCX4.

Dual ports 10GE SFP+interface module expansion card:

LSW-2XGES.

Single port 10GE SFP+interface module expansion card:

LSW-1XGES.

Input voltage

Alternating

current

Rated voltage range: 100V～240V AC, 50/60H

RPS input

interface

Rated voltage range: 12V DC

None

Incoming current

Alternating

current

Rated current: 1.5A

Direct current

Rated current: 10A

None

Power input interface type and

number

1 AC input interface

1 RPS input interface

1 AC input

interface

1 RPS input

interface

2 AC input interface

Maximum power

150W

Heat dissipation

Adopt 3 fans to dissipate heat.

Work environment temperature

0℃～45℃

Work environment relative

humidity(non-condensation ）

10%～95%

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere DPtech Schalten Handbücher

DPtech

DPtech LSW5003 Series Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
