DRAKE ACT1000 Bedienungsanleitung

Instruction Manual

ACT1000 Air-to-CableTranscoder

is a registered trademark of the R.L. Drake Holdings LLC

Rev: 20130116

1002564

CAUTION STATEMENTS .....................................................................................................................................2

IMPORTANT SAFETY INSTRUCTIONS ..............................................................................................................2

SPECIFICATIONS ................................................................................................................................................4

GENERAL DESCRIPTION / INSTALLATION AND MOUNTING / CONFIGURATION ........................................5

USAGE...................................................................................................................................................................6

WARRANTY ..........................................................................................................................................................7

Caution Statements:

Important Safety Instructions:

1. Read Instructions: All the safety and operating instructions should be read before the product is operated.

2. Retain Instructions: The safety and operating instructions should be retained for future reference.

3. Heed Warnings: All warnings on the product and in the operating instructions should be adhered to.

4. Follow Instructions: All operating and use instructions should be followed.

5. Cleaning: Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleansers. Use a damp cloth for cleaning.

6. Attachments: Do not use attachments that are not recommended by the product manufacturer as they may cause hazards.

7. Water and Moisture: Do not use this product near water—for example, near a bathtub, wash bowl, kitchen sink or laundry tub; in a wet basement;

or near a swimming pool; and the like.

Table of Contents, Caution, & Important Safety Instructions

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO

RAIN OR MOISTURE.

DO NOT OPEN THE CABINET, REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION

CORD RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO

PREVENT BLADE EXPOSURE.

ATTENTION: POUR PREVENIR LES CHOCS ELECTRIQUES, NE PAS UTILISER CETTE FICHE POLARISEE

AVEC UN PROLONGATEUR, UNE PRISE DE COURANT OU UNE AUTRE SORTIE DE COURANT,

SAUF SI LES LAMES PEUVENT ETRE INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A

DECOUVERT.

WARNING: TO PREVENT FIRE OR

ELECTRICAL SHOCK, DO NOT

EXPOSE TO RAIN OR MOISTURE

A product and cart combination should be moved

with care. Quick stops, excessive force and uneven

surfaces may cause the product and cart combination

to overturn.

The lightning flash with arrow head symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated "dangerous voltage" within

the product's enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to

persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the product.

3Important Safety Instructions (continued)

8. Accessories: Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child

or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with

the product. Any mounting of the product should follow the manufacturer's instructions, and should use a mounting accessory recommended by the

manufacturer.

9. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart

combination to overturn.

10. Ventilation: Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from

overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug,

or similar surface. This product should not be placed in a built-in installation such as bookcase or rack unless proper ventilation is provided or the

manufacturer's instructions have been adhered to.

11. Power Sources: This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type

of power supplied to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other

sources, refer to the operating instructions.

12. Grounding or Polarization: This product may be equipped with a polarized alternating-current line plug (a plug having one blade wider than the

other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing

the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized

plug. Alternate Warnings – If this product is equipped with a three-wire grounding- type plug, a plug having a third (grounding) pin, the plug will only fit

into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your

obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.

13. Outdoor Antenna Grounding: If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so

as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides

information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of

grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

14. Power-Cord Protection: Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against

them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

15. Lightning: For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it

from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

16. Power Lines: An outside antenna system should not be located in the vicinity of overhead power lines, other electric light or power circuits, where it

can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power

lines or circuits as contact with them may be fatal.

17. Overloading: Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

18. Object and Liquid Entry: Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out

parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

19. Servicing: Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards.

Refer all servicing to qualified service personnel.

20. Damage Requiring Service: Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a) When the power-supply cord or plug is damaged,

b) If liquid has been spilled, or objects have fallen into the product,

c) If the product has been exposed to rain or water,

d) If the product does not operate normally by following the operating instructions.

Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will

often require extensive work by a qualified technician to restore the product to its normal operation, e. If the product has been dropped or damaged

in any way, and f. When the product exhibits a distinct change in performance—this indicates a need for service.

21. Replacement Parts: When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer

or have the same characteristics as the original part. Unauthorized substitutes may result in fire, electric shock or other hazards.

22. Safety Check: Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the

product is in proper operating condition.

23. Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling only as recommended by the manufacturer.

24. Heat: The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that

produce heat.

DEMODULATOR SPECIFICATIONS

Input Frequency Range: 54-1002MHz

Channel plans supported: Standard CATV, HRC, IRC, Broadcast

Input Channel Bandwidth: 6MHz

Input RF Level Range: -33dBmV to +35dBmV, 8VSB

-22dBmV to +35dBmV, 64QAM

-17dBmv to +35dBmV, 256QAM

Input Impedance: 75 Ohms

Input Return Loss: >6dB, Broadcast mode; >12dB, CATV mode

Image Rejection: 80dB

Adjacent Channel Rejection: 40dB

Noise Figure: <9dB, Broadcast mode; <12dB, CATV mode

Demodulation Modes: 8VSB ATSC, 64QAM Annex B, 256QAM Annex B

Symbol Rates: 10.76Ms/s (8VSB); 5.057Ms/s (64QAM); 5.3606Ms/s (256QAM)

Specications

Specifications subject to change without notice or obligation.

PSIP Table Rewriting Supported

MGT/VCT Table Generation Supported

Temperature Rating 0-50C ambient

MODULATOR SPECIFICATIONS

Modulation Modes: 64, 256QAM ITU j.83 Annex B

16, 32, 64, 128, 256QAM ITU j.83 Annex A

Symbol Rates: 1-7Msps variable, with presets for Annex B

Frequency Coverage: 54-1002MHz

Channel Plans: Standard CATV, HRC, IRC, Broadcast

Max Output Power: +45dBmV max.

Min Output Power: +29.5dBmV

Phase Noise: -95dBc/Hz@10kHz offset

Broadband Noise: -75dBc@12MHz offset in a 6MHz bandwidth

MER: >40dB equalized

Channel Frequency Response: <1dB

Carrier Suppression: >40dB

I/Q Imbalance: <1 degree

Output Level Accuracy: ± 1dB

Spurious Emissions: <-60dBc

PSIP TABLE HANDLING

Form Factor Fits in Drake Digital RMT150 chassis

Dimensions 1.1"W x 3.4"H x 13.25"D

Weight 1lb 6oz

Power Requirements All power provided by the Drake® PS151 power supply. PS151 power requirement: 90-260VAC 150W

maximum with 10 transcoders.

General Description

The R. L. Drake® model ACT1000 is a commercial grade,

modular digital headend component providing 8VSB or

QAM input to QAM transmodulation and RF upconversion

in a single unit. Up to 10 ACT1000 modules, along with the

required PS151 power supply module, can be installed into

a single RMT150 rack mounting tray, occupying only 2 rack

units (3.5''). The ACT1000 supports ATSC 8VSB and ITU

j.83 Annex B 64QAM and 256QAM inputs, and outputs an

agile ITU j.83 Annex A or B QAM channel. The ACT1000

supports RF inputs from 54-1002MHz from an antenna

or cable feed. The modulator supports RF channels from

54-1002MHZ, and all Annex A and Annex B QAM modes up

to 256QAM, including all interleaver settings for Annex B. The

transcoder demodulates the desired digital channel, adapts

the bitrate from the input to output if necessary, and modulates

the entire multiplex of programs on the output channel.

PCR values are recalculated as required when the input

and output bit rates are not identical, and channel display

numbers (PSIP and MGT/VCT table entries) can be changed.

Installation and Mounting

Install the ACT1000 transcoders into the RMT150 rack

frame. Insert each ACT1000 into the frame until the ''F''

connector extends through the front panel hole, the LED is

aligned with the opening in the front panel, and the hook-

shaped projection near the rear of the ACT1000 engages

the rear of the frame. Secure the module into the frame

with the supplied nylon washer and 1/2'' ''F'' connector nut.

Connect the supplied power supply cable between the

ACT1000 and the frame-mounted PS151, ensuring that

the correct power supply port is used for the frame slot

location (slot 1 is the left-most slot, as viewed from the front).

Connect the ACT1000's input signal source to the front-

panel ''F'' connector. Connect the rearmounted output ''F''

connector to the output combiner as required for the system

configuration. Ensure that the PS151 is plugged into an AC

power source. When using the RMT150 rack frame, it is not

necessary to leave vertical airspace between the frame and

other equipment in the rack, unless other equipment in the rack

specifies minimum gaps. The transcoders and power supply

are designed to provide sufficient cooling and airflow, even

when mounted with adjacent RMT150 units above and below.

General Description/ Installation and Mounting/ Conguration

Configuration

The ACT1000 is controlled primarily via the Drake

model PS151 front-panel interface. The following menu

options are available for configuring the ACT1000

(menu name listed in bold, valid settings listed in italics:

· IN MODE: VSB-8, QAM-64B, QAM-256B – this configures

the input modulation mode that the ACT1000 will use

· IN PLAN: OTA, CATV, IRC, HRC – this selects the

channel plan for the receiver section (US off-

air, US standard cable, IRC, or HRC respectively)

· IN CHAN: 1-158 – this selects the input channel number;

the range varies depending upon the channel plan selected

· ENCODER: ITU-B, ITU-A – this selects the output modulator

QAM mode (ITU j.83 Annex B or Annex A, respectively); for

US cable applications, this should typically be set to ITU-B

· MODULAT: 256-QAM, 128-QAM, 64-QAM, 32-QAM,

16-QAM – this selects the output modulator QAM density;

only 256- and 64-QAM modes are available in Annex B

· INTERLV: All ITU interleave modes supported – this

allows the operator to choose a specific output interleave

mode, as necessary (Annex A mode only supports one

interleave mode, as only one is specified in the standard)

· CLOCK: PRESET, MANUAL – when set to MANUAL the

output symbol rate is continuously variable via the next

setting; when set to PRESET the symbol rate is fixed at

the appropriate bitrate for the modulation mode chosen

· BD RATE: 1.0000-7.0000 Ms/s – when the previous

setting is configured for MANUAL, this allows the output

symbol rate to be configured to an arbitrary symbol

rate. Note that some higher-bitrate symbol rates may

occupy more than 6MHz channel bandwidth, and that

very-low-bitrate symbol rates will not fill a 6MHz channel

· OUTPUT: NORMAL, STANDBY, CW – changes the

output mode to STANDBY (no output) or CW (a CW

pilot with the correct output power) from NORMAL

· RF OUT: 29.5-45.0dBmV – sets the

output power level of the modulator

· CH PLAN: OTA, CATV, IRC, HRC – sets the

output channel plan in use (US broadcast, US

standard cable TV, IRC, or HRC respectively)

· CHANNEL: 1-158 – sets the output channel number; the

range varies depending upon the channel plan selected

· PSIP: ORIGINAL, MODIFY, BASIC – the ACT1000 can

modify or insert PSIP tables as needed. ORIGINAL passes

the incoming PSIP tables unchanged. MODIFY will modify

the incoming PSIP tables to user-defined channel numbers,

and BASIC will insert newly-generated PSIP tables based on

user-defined settings; both of these settings must be used in

conjunction with the R. L. Drake Digital Headend Control

Program1,which allows the user to set the new values.

1version 3.8 or later must be used – the newest version can be downloaded from http://giant.rldrake.com/RLDrake_Digital_Headend_Control.zip

6Usage

Usage

After mounting the ACT1000 and wiring it to the

appropriate inputs and outputs, use the PS151 or PC

control program to configure the unit. Remember to

ensure that output levels are matched with all other

sources that will be combined into the final cable system

output. Once the unit is configured, the status of the

demodulator can be viewed via the PS151 front panel;

select the unit to monitor, and the display will show the

current state. The top display line will switch between the

unit ID of the ACT1000 and the current input channel,

and the bottom display line will show the current SNR.

If the demodulator is not locked to the input signal, the

bottom display line will show TUNELOCK to let the user

know that the ACT1000 is trying to tune in and lock to

the input.

The ACT1000 automatically saves all configuration

settings, and will restore them after power is restored after

loss. The firmware within an ACT1000 can be field

updated via the R. L. Drake Digital Headend Control

Program as well, by choosing Tools )Download from

the initial screen. This update process is fault-tolerant;

if the unit loses power during an upgrade, the process

can simply be restarted once power is restored.

To set PSIP data, the R. L. Drake Digital Headend

Control Program must be used. Once the software has

been configured to communicate with the ACT1000

(refer to the manual on the CDROM that shipped with

the Drake PS151 for more details), click View/Edit on

the ACT1000 in question, and then click on the PSIP

Setup button (see Figure 1). Once the PSIP Setup

window opens, the table information can be extracted

from the existing programs and modified, or new

information can be generated for program streams

that contain no PSIP information (see Figure 2).

Three Year Limited Warranty

R.L. DRAKE HOLDINGS LLC warrants to the original purchaser this product shall be free from defects in material

or workmanship for three (3) years from the date of original purchase.

During the warranty period R.L. DRAKE HOLDINGS LLC or an authorized Drake service facility will provide,

free of charge, both parts and labor necessary to correct defects in material and workmanship. At its option, R.L.

DRAKE HOLDINGS LLC may replace a defective unit.

To obtain such a warranty service, the original purchaser must:

1. Retain invoice or original proof of purchase to establish the start of the warranty period.

Notify R.L. DRAKE HOLDINGS LLC or the nearest authorized service facility, as soon as possible after

discovery of a possible defect, of:

a) the model and serial number,

b) the identity of the seller and the approximate date of purchase; and

A detailed description of the problem, including details on the electrical connection to associated

equipment and the list of such equipment.

Deliver the product to R.L. DRAKE HOLDINGS LLC or the nearest authorized service facility, or ship

the same in its original container or equivalent, fully insured and shipping charges prepaid.

Correct maintenance, repair, and use are important to obtain proper performance from this product. Therefore

carefully read the Instruction Manual. This warranty does not apply to any defect that R.L. DRAKE HOLDINGS

LLC determines is due to:

Improper maintenance or repair, including the installation of parts or accessories that do not conform

to the quality and specifications of the original parts.

2. Misuse, abuse, neglect or improper installation.

3. Accidental or intentional damage.

All implied warranties, if any, including warranties of merchantability and fitness for a particular purpose, terminate

three (3) years from the date of the original purchase.

The foregoing constitutes R.L. DRAKE HOLDINGS LLC'S entire obligation with respect to this product, and the

original purchaser shall have no other remedy and no claim for incidental or consequential damages, losses or

expenses. Some states do not allow limitations on how long an implied warranty lasts or do not allow the exclusions

or limitation of incidental or consequential damages, so the above limitation and exclusion may not apply to you.

This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

This warranty shall be construed under the laws of Ohio.

For Service, contact:

R.L. DRAKE HOLDINGS LLC

9900 Springboro Pike

Miamisburg, Ohio 45342. USA

Customer Service and Parts Telephone: +1 (937) 746-6990

Telefax: +1 (937) 806-1576

Web Site: http://www.rldrake.com

Warranty

R.L. Drake Holdings LLC

9900 Springboro Pike

Miamisburg, Ohio 45342. USA

Customer Service and Parts Telephone: +1 (937) 746-6990

Telefax: +1 (937) 806-1576

Web Site: http://www.rldrake.com

Inhaltsverzeichnis

Andere DRAKE Transcoder Handbücher

DRAKE

DRAKE SCT3860 Service-Handbuch

Beliebte Transcoder Handbücher anderer Marken

Blankom

Blankom BTR-6000 Bedienungsanleitung

TransLite

TransLite TL-A1000 Bedienungsanleitung

Sencore

Sencore OmniHub X Bedienungsanleitung

Blonder tongue

Blonder tongue Clearview 4:2 Bedienungsanleitung

Inline

Inline IN1501 Installationshandbuch

Inline

Inline in1503 Bedienungsanleitung

Cabletime

Cabletime MediaStar 700-485 Bedienungsanleitung

Sigma

Sigma TXN-2113 Bedienungsanleitung

Blonder tongue

Blonder tongue Clearview 4:2 SD Bedienungsanleitung

VGP

VGP Koryuu Transcoder Bedienungsanleitung

Kramer

Kramer Tools 482xl Bedienungsanleitung

Sencore

Sencore OmniHub XMINI Bedienungsanleitung

ASTRO

ASTRO U 224 Bedienungsanleitung

scope

scope Connexions CX5 Bedienungsanleitung

Hangzhou Dibsys Technologies Co., Ltd.

Hangzhou Dibsys Technologies Co., Ltd. Caster-T322 Bedienungsanleitung

scope

scope LARYNGOSCOPE Bedienungsanleitung

scope

scope Connexions CX5E Bedienungsanleitung

Kramer

Kramer FC-404NETxI Bedienungsanleitung
