Draytek Vigor167 Bedienungsanleitung

Vigor167

35b VDSL2 Modem

Quick Start Guide

Version: 1.0_UK

Region: United Kingdom & Ireland

Firmware Version: V5.1

For updates and support, visit www.draytek.co.uk

Date: March 17, 2022

Note: Product specification is subject to continuous evolution which may

not always be reflected in current documentation. For the formal specification

and details of the supported features of your product, please refer

only to the web site at www.draytek.co.uk

iii

Intellectual Property Rights (IPR) Information

Copyrights

by copyright. No part may be reproduced, transmitted, transcribed, stored in

a retrieval system, or translated into any language without written permission

from the copyright holders.

Trademarks

The following trademarks are used in this document:

⚫Microsoft is a registered trademark of Microsoft Corp.

⚫Windows 8, 10 and Explorer are trademarks of Microsoft Corp.

⚫Apple and Mac OS are registered trademarks of Apple Inc.

⚫Other products may be trademarks or registered trademarks of their

respective manufacturers.

Safety Instructions and Approval

Safety

Instructions

⚫Read the installation guide thoroughly before you set up the modem.

⚫The modem is a complicated electronic unit that may be repaired only be

authorized and qualified personnel. Do not try to open or repair the modem

yourself.

⚫Do not place the modem in a damp or humid place, e.g. a bathroom.

⚫Do not stack the modem on top of other electronics.

⚫The modem should be used in a sheltered area, within a temperature range of 0

to +40 Celsius.

⚫Do not expose the modem to direct sunlight or other heat sources. The housing

and electronic components may be damaged by direct sunlight or heat sources.

⚫Do not deploy the cable for LAN connection outdoor to prevent electronic shock

hazards.

⚫Keep the package out of reach of children.

⚫When you want to dispose of the modem, please follow local regulations on

conservation of the environment.

Warranty

We warrant to the original end user (purchaser) that the modem will be free from any defects in

workmanship or materials for a period of two (2) years from the date of purchase from a

DrayTek authorized dealer in the UK/Ireland. Please keep your purchase receipt in a safe place

as it serves as proof of date of purchase. During the warranty period, and upon proof of

purchase, should the product have indications of failure due to faulty workmanship and/or

materials, we will, at our discretion, repair or replace the defective products or components,

without charge for either parts or labour, to whatever extent we deem necessary tore-store the

product to proper operating condition. Any replacement will consist of a new or re-manufactured

functionally equivalent product of equal value, and will be offered solely at our discretion. This

warranty will not apply if the product is modified, misused, tampered with, damaged by external

factors, used with unapproved accessories or subjected to abnormal working conditions.

Warranty applies to hardware only, not software or firmware. Defects which do not significantly

affect the usability of the product will not be covered by the warranty. We reserve the right to

revise the manual and online documentation and to make changes from time to time in the

contents hereof without obligation to notify any person of such revision or changes.

EU Declaration of Conformity

We DrayTek Corp. , office at No.26, Fu Shing Road, HuKou County, Hsin-Chu Industry Park, Hsinchu

300, Taiwan , R.O.C., declare under our sole responsibility that the product

⚫Product name: 35b Modem

⚫Model number: Vigor167

⚫Manufacturer: DrayTek Corp.

⚫Address: No.26, Fu Shing Rd, HuKou, HsinChu Industrial Park, Hsinchu 303,

Taiwan

⚫Importer: SEG, 11 Capital Business Park, Borehamwood, Herts, WD6 1GW

is in conformity with the relevant Union harmonisation legislation:

EMC Directive 2014/30/EU , Low Voltage Directive 2014/35/EU , ErP 2009/125/EC and RoHS

2011/65/EU with reference to the following standards

Standard

Version / Issue date

EN 55032

2012+AC:2016 class B

EN 61000-3-2

2014 Class A

EN 61000-3-3

2013

EN 55024

2010+A1:2015

EN 62368

2014+A11:2017

EC No. 1275/2008

2008

Hsinchu 30th December, 2020 Calvin Ma / President .

(place) (date) (Legal Signature)

Join the UK mailing list

Users in the UK & Ireland can sign up to our mailing list which goes out

approximately 4 times per year with products news, updates, hints &

tips and offers. For details, please visit www.draytek.co.uk/list

Firmware & Tools Updates

Due to the continuous evolution of DrayTek technology and emerging

risks, router firmware updates may be issued.

Please consult the DrayTek web site for more information on newest

firmware, tools and documents: www.draytek.co.uk (For UK/Ireland)

*The external power supply used for each product will be model dependent.

Manufacturer

CWT

APD

Address

No. 222, Sec.

2, Nankan Rd.,

Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan Rd.,

Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan Rd.,

Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan Rd.,

Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan Rd.,

Lujhu

Township,

Taoyuan

County 338,

Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

Model identifier

2ABB012F UK

2ABB018F UK

2ABL024F UK

2ABL030F UK

2ABN036F UK

WA-12M12FG

WB-18D12FG

WA-24Q12FG

WA-36A12FG

2ABB012F EU

2ABB018F EU

2ABL024F EU

2ABL030F EU

2ABN036F EU

WA-12M12FK

WB-18D12FK

WA-24Q12FK

WA-36A12FK

Input voltage

100~240V

Input AC frequency

50/60Hz

Output voltage DC

12.0V

Output current

1.0A

1.5A

2.0A

2.5A

3.0A

1.0A

1.5A

2.0A

3.0A

Output power

12.0W

18.0W

24.0W

30.0W

36.0W

12.0W

18.0W

24.0W

36.0W

Average active

efficiency

84.9%

86.2%

87.6%

87.8%

89.8%

83.7%

85.4%

88.6%

88.2%

Efficiency at low load

10%

73.6%

78.0%

81.3%

83.3%

83.7%

74.5%

80.5%

86.4%

85.4%

No-load power

consumption

0.07W

0.10W

0.07W

0.10W

For more updates & information, please visit www.draytek.co.uk. The external power supply used for each

product will be model dependent.

1. Package Contents................................................................................................. 1

2. Panel Explanation................................................................................................. 2

3. Hardware Installation ........................................................................................... 3

3.1 Network Connection...............................................................................................................3

3.2 Wall-Mounted Installation .......................................................................................................4

4. Software Configuration........................................................................................ 5

5. Getting Further Help............................................................................................. 8

5.1 Additional Feature Setup........................................................................................................8

5.2 Keep up to date with our mailing list .......................................................................................8

5.3 Firmware Updates..................................................................................................................9

5.4 Security & Router Best Practice..............................................................................................9

Take a look at the package contents. If there is anything missing or damaged,

please contact DrayTek or your DrayTek reseller immediately.

Modem

Quick Start Guide

RJ-11 to RJ-45 Cable

RJ-11 to RJ-11 Cable

The type of the power adapter depends on the country that the modem will be

installed. * The maximum power consumption is 4.5 Watt.

UK-type Power Adapter

LED

Status

Explanation

ACT

Off

The system is not ready or is failed.

Blinking

The system is ready and can work normally.

P1/P2

A normal connection is through its corresponding

port.

Off

LAN is disconnected.

Blinking

Data is transmitting (sending/receiving).

DSL

xDSL connection synchronized.

Blinking

xDSL connection is synchronizing.

Interface

Description

PWR

Connecter for a power adapter.

ON/OFF

ON/OFF: Power switch.

Factory Reset

Restore the default settings. Usage: Turn on the modem. Press

the button and keep for more than 10 seconds. Then the modem

will restart with the factory default configuration.

P2-P1

Connecter for local networked devices.

DSL

Connecter for accessing the Internet through xDSL.

Note

Remove the protective film from the modem before use to ensure

ventilation.

This section will guide you through the installation of the modem hardware.

Once it is connected, proceed to the next section for final setup.

Before starting to configure the modem, you must connect your devices

correctly.

1. Connect the DSL interface to the MODEM port of your building’s splitter or

microfilter, with a DSL line cable.

(splitter)

2. Connect the LAN port to your computer with a RJ-45 cable.

3. Connect one end of the power adapter to the Power port of this device.

Connect the other end to the wall outlet of electricity.

4. Power on the modem.

5. Check the POWER, ACT, LAN, DSL and INTERNET LEDs to assure network

connections.

(For the detailed information of LED status, please refer to section 2.)

-M

Vigor167 has keyhole type mounting slots on the underside.

1. Drill the holes on the wall according to the recommended instruction.

2. Fit screws into the wall using the appropriate type of wall plug.

Note

The recommended drill diameter shall be 6.5mm (1/4”).

3. Once the mounting holes have been drilled and the wall-plugs & screws

inserted, the modem can be hung onto the screw heads. This provides a

secure mounting point for the modem.

Andere Handbücher für Vigor167

Inhaltsverzeichnis

Andere Draytek Modem Handbücher

Draytek

Draytek Vigor 120 Bedienungsanleitung

Draytek

Draytek Vigor 130 Bedienungsanleitung

Draytek

Draytek Vigor 160 Series Bedienungsanleitung

Draytek

Draytek Vigor 318 Bedienungsanleitung

Draytek

Draytek Vigor120 Series Bedienungsanleitung

Draytek

Draytek Vigor160 Series Bedienungsanleitung

Draytek

Draytek Vigor 160 Series Bedienungsanleitung

Draytek

Draytek Vigor2832 Series Bedienungsanleitung

Draytek

Draytek Vigor122 Bedienungsanleitung

Draytek

Draytek Vigor167 Bedienungsanleitung

Draytek

Draytek Vigor 120 Bedienungsanleitung

Draytek

Draytek Vigor 120 Bedienungsanleitung

Draytek

Draytek Vigor122 Bedienungsanleitung

Draytek

Draytek Vigor167 Bedienungsanleitung

Draytek

Draytek Vigor167 Bedienungsanleitung

Draytek

Draytek Vigor120 Series Bedienungsanleitung

Draytek

Draytek Vigor3900 Series Bedienungsanleitung

Draytek

Draytek Vigor120 Series Bedienungsanleitung

Draytek

Draytek Vigor130 Bedienungsanleitung

Draytek

Draytek Vigor130 Bedienungsanleitung

Draytek

Draytek Vigor130 Bedienungsanleitung

Draytek

Draytek Vigor 130 Bedienungsanleitung

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Zte

Zte WiMAX Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Zte

Zte MF823 Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
