iii

VigorSwitch FX2120

L2+ Managed Switch

Quick Start Guide

Version: 1.0

Firmware Version: V3.7.0

(For future update, please visit DrayTek web site)

Date: April 27, 2022

VigorSwitch FX2120 Quick Start Guide

Rack Mount Kit (brackets) DAC Cable

The type of the power cord depends on the country that the switch will be installed.

UK-type Power Cord EU-type Power Cord

USA/Taiwan-type Power Cord AU/NZ-type Power Cord

If any of these items is found missing or damaged, please contact your local supplier

for replacement.

LED Status Explanation

On (Red) An alert for system failure due to overheating or wrong voltage.

Blinking The system is (TBD)

Monitor

Off The device is in normal condition.

On (Green) The switch finishes system booting and the system is ready.

Blinking (Green) The switch is powered on and starts system booting.

SYS

Off The power is off or the system is not ready / malfunctioning.

On The device is powered on.

PWR Off The device is powered off or failed.

On (Blue) The device is connected with 10Gbps.

On (Green) The device is connected with 1000Mbps.

Blinking The system is sending or receiving data through the port.

Port 1 ~ 12

SFP LNK/ACT

Off The port is disconnected or the link is failed.

Interface Description

RST Factory reset button.

Press it to reboot the system. (<5 seconds)

Press it to reset the system with factory default settings. (5~20 seconds)

Port 1 ~ 12 Port 1 to Port 12 can be used for fiber connection.

Console Used to perform telnet command control.

Console

SFP LNK/ACT, Port 1 to Port 12

12V DC Input

1. Insert the connector into the slot (port 1~12 of this switch).

2. Pull the release latch to remove it.

-M

The switch can be installed easily by using rack mount kit.

1. Fasten the rack mount kit on both sides of the

VigorSwitch using specific screws.

2. Then, install the VigorSwitch (with rack mount

kit) on the 19-inch chassis by using other four

screws.

Before configuring the switch, perform the following steps:

1. Set up a physical path between the switch and a PC. Insert one end of the

DAC cable connector into the slot (port 1~12 of this switch); and insert the

other end of the DAC cable into the slot on the network card on your PC.

If a PC directly connects to the switch, you have to setup the same subnet mask for

PC and the switch. Default values of the managed switch are listed as follows:

IP Address 192.168.1.224

Subnet Mask

255.255.255.0

DHCP Client Enabled (On)

Username admin

Password admin

2. After configuring correct IP address on your PC, open your web browser and

access switch's IP address.

The home page of VigorSwitch will be shown as below:

If the switch cannot work correctly after trying many efforts, please contact your

dealer for further help right away. For any questions, please feel free to send

e-mail to [email protected].

Web registration is preferred. You can register your Vigor device via

https://myvigor.draytek.com.

Due to the continuous evolution of DrayTek technology, all switches will be

regularly upgraded. Please consult the DrayTek web site for more information on

newest firmware, tools and documents. https://www.draytek.com

GPL Notice This DrayTek product uses software partially or completely licensed

under the terms of the GNU GENERAL PUBLIC LICENSE. The author of

the software does not provide any warranty. A Limited Warranty is

offered on DrayTek products. This Limited Warranty does not cover

any software applications or programs.

To download source codes please visit:

http://gplsource.draytek.com

GNU GENERAL PUBLIC LICENSE:

https://gnu.org/licenses/gpl-2.0

Version 2, June 1991

For any question, please feel free to contact DrayTek technical

support at

[email protected] for further information.

EU Declaration of Conformity

We DrayTek Corp. , office at No.26, Fushing Rd, Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan,

declare under our sole responsibility that the product

Product name: 12 ports x 10Gb SFP Switch

Model number: VigorSwitch FX2120

Manufacturer: DrayTek Corp.

Address: No.26, Fushing Rd, Hukou, Hsinchu Industrial Park,

Hsinchu 303, Taiwan.

is in conformity with the relevant Union harmonisation legislation:

EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU and RoHS 2011/65/EU with reference

to the following standards

Standard Version / Issue date

EN 55032 2015+AC:2016 class A

EN 61000-3-2 2014 Class A

EN 61000-3-3 2013+A1:2019

EN 55035 2017

EN 62368-1 2014 +A11:2017 (Second Edition)

EN IEC6300:2018 2018

Hsinchu June 24, 2021 Calvin Ma / President

(place) (date) (Legal Signature)

Declaration of Conformity

We DrayTek Corp. , office at No.26, Fushing Rd, Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan,

declare under our sole responsibility that the product

Product name: 12 ports x 10Gb SFP Switch

Model number: VigorSwitch FX2120

Manufacturer: DrayTek Corp.

Address: No.26, Fushing Rd, Hukou, Hsinchu Industrial Park,

Hsinchu 303, Taiwan.

is in conformity with the relevant UK Statutory Instruments:

The Electromagnetic Compatibility Regulations 2016 (SI 2016 No.1091), The Electrical Equipment

(Safety) Regulations 2016 (SI 2016 No.1101), and The Restriction of the Use of Certain Hazardous

Substances in Electrical and Electronic Equipment Regulations 2012 (SI 2012 No. 3032) with reference

to the following standards:

Standard Version / Issue date

EN 55032 2015+A1:2016 class A

EN 61000-3-2 2014

EN 61000-3-3 2013+A1:2019

EN 55035 2017

EN 62368-1 2014+A11:2017

EN IEC 63000:2018 2018

Hsinchu 24th June, 2021 Calvin Ma / President

(place) (date) (Legal Signature)
