DREYER SYSTEM EDITION G Bedienungsanleitung
MANUAL
Kiosk Printer EDITION G
Version: English
Printer Mechanism made by
Page: 2
Revision Description Name Date
00 First Issue HL 2018-01-24
Revision Index
Manual EDITION G Revision Index
Page: 3
Table of Contents
Revision Index..........................................................................................................................................................2
Recommendations .................................................................................6
Power requirement...................................................................................................................................7
Paper quality .............................................................................................................................................7
Maintenance..............................................................................................................................................7
USB Version ............................................................................................8
Pin Assignment and Settings..................................................................9
Back...................................................................................................................................................................9
Front................................................................................................................................................................10
Top ..................................................................................................................................................................11
Technical Data ......................................................................................12
Technical Data for Printer Mechanism..........................................................................................................12
Technical Data Controller Board...................................................................................................................13
Settings ................................................................................................14
Standard Settings...........................................................................................................................................14
Parameter Settings.........................................................................................................................................15
Communication Interface Settings...............................................................................................................15
Error Modes ..........................................................................................16
Error Mode A......................................................................................................................................................16-17
Error Mode C and R................................................................................................................................................18
External Sensors...................................................................................19
Near End Sensor.............................................................................................................................................19
Paper-Jam Sensor..........................................................................................................................................19
Manual EDITION G Table of Contents
Page: 4
Table of Contents
Additional Settings ...............................................................................20
Recalibration Mode ........................................................................................................................................20
Formfeed to Blackmark Mode.......................................................................................................................20
Autofeed Mode ...............................................................................................................................................20
Blackmarks...........................................................................................21
Control Commands (Overview) ............................................................22
Text Attributes ................................................................................................................................................22
Graphic............................................................................................................................................................23
General Commands ................................................................................................................................. 24-25
Special Commands .................................................................................................................................. 26-27
Parameter Settings................................................................................................................................... 28-29
Barcode and other Printing Options.............................................................................................................30
Control Command Sequences..............................................................31
Text Attributes .......................................................................................................................................... 31-32
Graphic...................................................................................................................................................... 33-34
General Commands ................................................................................................................................. 35-37
Special Commands .................................................................................................................................. 38-41
Parameter Settings................................................................................................................................... 42-44
Barcodes and other Printing Options..................................................................................................... 45-48
Appendix A ...........................................................................................49
Character Codes of Code 128 – Printable Characters in Code A.................................................................49
Character Codes of Code 128 – Printable Characters in Code B.................................................................50
Character Codes of Code 128 – Printable Characters in Code C.................................................................51
Manual EDITION G Table of Contents
Page: 5
Table of Contents
Appendix B ...........................................................................................52
Character Set CP 437......................................................................................................................................52
Character Set ISO-8859 (all variations).........................................................................................................52
Character Set ISO-8859-1...............................................................................................................................53
Character Set ISO-8859-2...............................................................................................................................53
Character Set ISO-8859-5...............................................................................................................................53
Character Set ISO-8859-7...............................................................................................................................54
Character Set ISO-8859-8...............................................................................................................................54
Character Set ISO-8859-9...............................................................................................................................54
Character Set ISO-8859-13.............................................................................................................................55
Appendix C ...........................................................................................56
Run Length Encoding (RLE) – Sample Code........................................................................................... 56-57
Appendix D ...........................................................................................58
Creating Logos.......................................................................................................................................... 58-59
Appendix E............................................................................................60
Instructions to Update Firmware and how to Create a Logo......................................................................60
Appendix F............................................................................................61
Technical Drawings ........................................................................................................................................61
Imprint .................................................................................................62
Manual EDITION G Table of Contents
Page: 6
Recommendations
General:
• To prevent voltage damage, the power supply cable may only be removed when the power is off
• While working on the Printer:
- make sure that ESD regulations are respected
- that only trained personnel has access to
• The attempt to repair will result in the loss of warranty claims
Manual EDITION G Recommendations
Page: 7
Power requirement
Power consumption for thermal printers is fairly high. To ensure good printing result it is recommended to
use a power supply that can provide at least 7.5 A peak (@26.4V). Recommendations are based on meas-
urements at the worst case condition of 26.4V supply voltage while printing a blackline.
Insufcient power supply will cause poor printing quality and may result in a reset of the controller board.
The power supply cable should provide adequate cross section and should be as short as possible.
Paper quality
It is recommended to use approved paper only. Low quality paper can signicantly reduce the life time of
printing head and auto cutter.
Maintenance
Regular cleaning is strongly recommended. To clean the thermal head please use a cotton swab and Iso-
propanol. Using cleaners or chemicals other than Isopropanol may result in the damage of the printer. No
cleaning can signicantly reduce the life time of the printing head.
Cleaning with cotton swab
Manual EDITION G Recommendations
Cleaning Thermal Head
Thermal Head
Page: 8
USB Version
WHQL-certied USB drivers as well as further drivers for the usual operating systems are available on re-
quest or can be found at the webpage of the USB-controller's manufacturer:
http://www.ftdichip.com/FTDrivers.htm
After the installation of the driver it is possible to communicate with the printer either over a virtual COM-
port (the set Baudrate does not matter) or via a software API, which is realized as a DLL and available for C/
C++, C#, VB and Delphi. Whenever possible, the DLL should be used.
Further information for the API are included in the driver package.
The programmed serial number of the USB-controller is '8U00060A'.
Manual EDITION G Recommendations
Page: 9
Pin Assignment and Settings (Back)
Manual EDITION G Pin Assignment and Settings
Pin 1 Pin 1
Connector for Paper Near End
Sensor (Option)
Connector/Mate Connector
JST (S3B-ZR-SM4-TF)/(ZHR-3)
Pin Name Description
1VCC + 5.0 VDC
2 GND Ground
3 INPUT Sensorsignal, int.
Pullup 47kΩ
ST 6
USB I/F
ST 1
Connector for Supply Voltage
Connector/Mate Connector
JST (S4B-XH-SM4-TB)/(XHR-4)
Pin Name Description
1 VDD + 24.0 VDC
2 VDD + 24.0 VDC
3 GND Ground
4 GND Ground
ST 9
Connector for the Serial I/F
Connector/Mate Connector
JST (S4B-ZR-SM4-TF)/(ZHR-4)
Pin Name Description
1TXD Output, RS232 Level
2RTS Output, RS232 Level
3RXD Input, RS232 Level
4 GND Ground
ST 10
Pin 1
ST 6 ST 9 ST 10 ST 1
Page: 10
Pin Assignment and Settings (Front)
Manual EDITION G Pin Assignment and Settings
Pin 1 Pin 1 Pin 1
ST 2 ST 4 ST 7 ST 3
Connector for Presenter Sensor
(Option)
ST 3
Connector for Presenter Motor
(Option)
ST 2
Connector for Paper Near End
Sensor (Option)
Connector/Mate Connector
JST (S3B-ZR-SM4-TF)/(ZHR-3)
Pin Name Description
1VCC + 5.0 VDC
2 GND Ground
3 INPUT Sensor Signal, int.
Pullup 47kΩ
ST 4
Expansion Port (optional)
ST 7
