User's

Guide

PC6010

Quick Reference Guide

To use any function:

1. When the keypad is idle, it displays the time and

date:

12:00 2000/01/01

Enter Your Code

Enter your access code to go to the main menu.

2. The keypad prompts you with questions about

which function you want to choose. See the

appropriate section for information on each

function.

3. Press to select a function

Press to skip to the next function.

4. Answer or to each of the

questions until you are finished.

Remember: If you want to start over, press

at any time.

If you are viewing a list of items, the keypad

displays a flashing

when there is more

information. Use to see each item in the

list.

Main Menu:

This is the order of the prompts in the main menu.

For more information on each prompt, refer to the

page number indicated.

Users will see only the prompts they have access to.

Prompt Page No.

Do You Want To

Turn Areas On? ........................ 6

Do You Want To

Turn Areas Off? ...................... 10

Do you want to

Delay Auto-Arm? ...................... 15

End of basic user prompts

Activate

Door Strike? ...................... 16

Do You Want to

Reset Detectors? ...................... 16

End of advanced user prompts

End of List

View List Again?

To return to the beginning of the prompts, press

To return to the start screen, press .

This manual is for Basic and Advanced users. Each of these types of user can access a different set of

functions. The and symbols next to the title of each procedure show which users can

access that function.

Each user should read all the sections that describe the functions they can access. All users should

read pages i, and 1-2, for important information on security system operation.

See the

Glossary on page 2

to learn more about

words used in this

manual.

Table of Contents

Glossary 2

1 About Your Security System 3

1.1 Using This Manual ................................................................................................................................................ 3

1.2 Understanding Your Security System .................................................................................................................. 3

1.3 Remote Monitoring .............................................................................................................................................. 4

2 Turning Your Area(s) ON and OFF 5

2.1 Entering Your Access Code ................................................................................................................................... 5

2.2 Turning All Your Areas ON ................................................................................................................................... 6

2.3 Turning Some of Your Areas ON ......................................................................................................................... 7

2.4 Turning Area(s) ON - "Attempt Failed" Message ............................................................................................... 8

2.5 Turning All Your Areas OFF ................................................................................................................................ 10

2.6 Turning Some of Your Areas OFF ...................................................................................................................... 11

3 Silencing and Clearing Alarms & Faults 12

3.1 Turning Off the Bells/Sirens ............................................................................................................................... 12

3.2 Clearing the Alarms ............................................................................................................................................ 13

3.3 Viewing and Clearing Fault Conditions ............................................................................................................ 14

4 Automatic Arming 15

5 Other Functions 16

5.1 Unlocking Doors ................................................................................................................................................. 16

5.2 Resetting Detectors ............................................................................................................................................ 16

Index inside back cover

Access code: A four- or six-digit code that allows you to turn areas on or off, and to use other

system functions.

Alarm: When a zone is violated (e.g. a smoke detector detects smoke, a motion detector

senses movement, a door with a contact is opened), it triggers an alarm.

Intrusion alarm: An alarm triggered by an intrusion detector (e.g. motion detectors, glassbreak

detectors, door/window contacts). Usually occurs when the system is turned on.

Fire alarm: An alarm triggered by fire, smoke or heat detectors. Fire alarms may be

triggered at any time, whether the system is on or off.

Area: A group of zones that can be turned on or off together. See Zone.

Auto-arming: When the system turns on one or more areas at a preset time of the day.

Central Station: If remote monitoring is enabled, your system will send alarms, faults and

emergency messages to the central station. The central station will then notify the local

authorities, if necessary.

Detector: A part of the system that can detect problems and report them to the control panel

(e.g. a motion detector can tell the control panel if there is movement in a protected area).

Entry time: A timer programmed by your installer. The timer begins counting down when

you enter an area that is on. You must enter an access code to turn the area off before the

timer runs out, or an alarm will be triggered.

Entry/exit doors: Your installer will program the doors you usually use to enter or exit the

premises as entry/exit doors. These doors have entry and exit times. Your installer will usually

place keypads near the entry/exit doors for easy access to system functions.

Exit time: A timer programmed by your installer. The timer begins counting down when you

turn your system on, to allow you a period of time in which to leave the premises. At the

end of the exit time the system will be turned on.

Fault: The control panel continuously checks the system for conditions that may reduce its

effectiveness. If the control panel finds one of these conditions (fault), it will indicate this at

the keypad(s) to alert you to the problem.

Main Menu: The first set of options available after you enter your access code starting with

"Do you want to turn areas on?", or "Your areas are ON/OFF... Exit Now?".

Security System: The main control panel, detectors, devices and keypads, which together

provide security monitoring of an area.

Start Screen: What the keypad displays before you enter your access code:

12:00 2000/01/01

Enter Your Code

Zone: A part of the premises monitored by a detector (smoke detector, door/window contact,

motion detector, glassbreak detector, etc.).

Glossary

[120]

Your DSC security equipment has been designed to give you the greatest possible flexibility

and convenience. The liquid crystal display (LCD) keypad guides you through each operation

with easy-to-understand prompts. With unique sound sequences, the keypad signals

faults and other indications of system status.

Read this manual carefully to become familiar with the features that have been

implemented on your system. All users of this system should be instructed in the features

available to them.

1.1 Using This Manual _______________________________________________________________

There are 4 possible types of users of an PC6010 security system. Each of the 4 user types

can access different levels of features.

This manual describes how to use the features that are available to Basic and Advanced

users. These features may also be available to Supervisor and Master users. For information

on additional functions which are available to Supervisor and Master users, please refer

to the Maintenance Manual.

Each user type has access to a different set of system functions. Each procedure indicates

which users will be able to access it, with a graphic similar to the following:

1.2 Understanding Your Security System ___________________________________________

Your security system is made up of a control panel, keypads and various detectors

and sensors.

Control Panel

The control panel is the “brain” of your security system. It controls and monitors all the

keypads and sensors, and communicates with the central station (if remote monitoring is

turned on). The control panel will be mounted out of the way, in a utility closet or in a

basement. The metal cabinet contains the system electronics, fuses and stand-by battery.

There is normally no reason for anyone but the installer or service professional to have

access to the control panel.

Keypads

You can access system functions with your keypad(s), described in the User Guide. Each

keypad has a sounder. The keypad has a liquid crystal display (LCD) which shows system

messages. The keypad can send commands to the system and show the current system status.

You installer will mount the keypad(s) inside your premises, close to the entry/exit door(s).

S E C T I O N 1

About Your Security System

Zones and Areas

The security system has several zones (monitored areas). Each of these zones will be

connected to a sensor (motion detectors, glassbreak detectors, door contacts, etc.). If a

sensor goes into alarm, the keypad displays a message.

Your installer may have divided the system into different areas. Each area includes one or

more zones, and can be turned on and off independently of other areas. Your installer

should explain to you which areas have been programmed, and which zones belong to

which areas.

Access Codes

As a user of the system, you will be assigned a 4- or 6-digit access code. You can use your

access code to turn areas on and off, and to access other system functions.

Your access code may not allow you to use certain system functions. For instance, if your

code is only allowed to turn on area 1, you will not be able to turn on other areas.

1.3 Remote Monitoring _____________________________________________________________

The system can send alarms, troubles and emergency messages over telephone lines to a

central station. If you accidentally initiate an alarm, immediately call the central station to

prevent an unnecessary response.

NOTE: Your installer must enable monitoring for it to work.

IMPORTANT NOTICE

A security system cannot prevent emergencies. It is only intended to alert you and – if included – your

central station of an emergency situation. Security systems are generally very reliable but they may not

work under all conditions and they are not a substitute for prudent security practices or life and property

insurance. Your security system should be installed and serviced by qualified security professionals who

should instruct you on the level of protection that has been provided and on system operations.

This section describes how to turn your areas of the system ON and OFF. You will only be

able to turn on or off the areas which have been assigned to you. All users should read

this section carefully.

Remember - you can return to the start screen at any time by pressing .

However, pressing will not prevent areas from being turned on. To remain

in, or to re-enter areas, you must enter your access code and turn the areas off.

2.1 Entering Your Access Code ______________________________________________________

Before you can use any system features, you need to enter your access code. The keypad

always displays the start screen first:

1. 12:00 2000/01/01

Enter Your Code Enter your access code using the number pad.

If you enter a valid code, the keypad gives 3 short beeps, and the keypad displays the

next prompt. For example, the keypad may display:

Do You Want To

Turn Areas On? Go to step 4 (if the code is valid).

If the Code is Not Valid

2. If you enter a code that is not valid, the keypad gives one long beep, and the system

prompts:

Code Not Valid

Please Try Again

After 2 seconds, the keypad goes back to the start screen:

12:00 2000/01/01

Enter Your Code

3. Enter your code. If you enter a valid code, the keypad gives 3 short beeps, and the

system prompts:

Do You Want To

Turn Areas On?

If the Code is Valid

4. Answer or to each of the keypad prompts until you have

finished. Refer to the procedures in this manual for more information on each prompt.

S E C T I O N 2

Turning Your Area(s) ON and OFF

Step

2.2 Turning All Your Areas ON ______________________________________________________

This procedure explains how to turn on all the areas that you have access to. Before you

turn areas on, you should check that they are not occupied, and that all zones are closed

(i.e. doors and windows are closed, there is no motion in the area).

1. 12:00 2000/01/01

Enter Your Code Enter your access code.

2. Keypad displays:

Do You Want To

Turn Areas On? To confirm, press .

3. Keypad displays:

Turn ON All

Your Areas? To confirm, press .

4. The keypad beeps 3 times, the ON light turns on and the keypad displays:

All Your Areas Please Leave

Are Turning On then, Now... 120

5. The keypad counts down the exit time (the number in the lower right-hand corner

shows how much time is left). Leave the area through your entry/exit door. The area

will turn on after the exit time expires.

NOTE: Pressing will not prevent the area from being turned on. To remain

in, or to re-enter the area, you must enter your access code and turn the area off.

Attempt Failed

When you are trying to turn areas on, if you see the message

Attempt Failed

View Problems?

one or more zones may be open, or have problems. See section 2.4 for instructions.

Step

2.3 Turning Some of Your Areas ON _________________________________________________

This procedure explains how to turn on some of the areas that you have access to. Before

you turn any areas on, you should check that they are unoccupied, and that all the zones

are closed (i.e. doors and windows are closed, there is no motion in the area).

1. 12:00 2000/01/01

Enter Your Code Enter your access code.

2. Keypad displays:

Do You Want To

Turn Areas On? To confirm, press .

3. Keypad displays:

Turn ON All

Your Areas? Press .

4. The keypad displays a list of each area you have access to. For example:

Turn ON Area?

Area 1

If you do not want to turn on an area, press . The keypad displays the

next available area.

If this is an area you want to turn on, press . The keypad displays:

Area 1

is Turning On

NOTE: After you turn on the area you are in, you will not be able to turn on any more

areas from this keypad. The keypad beeps 3 times, the ON light turns on and the keypad

displays:

Please Leave

Now... 120

The keypad counts down the exit time. Leave the area through your entry/exit door.

5. If you come to the end of the list (and you haven't turned on the area you are in), the

keypad displays:

End of List

Exit Now?

To return to the beginning of the list of available areas, press .

To return to the start screen, press .

If you

need to turn on

the area you are

in, make sure

you turn it on

LAST!

2: Turning Your Area(s) ON and OFF

Step

2.4 Turning Area(s) ON - "Attempt Failed" Message ________________________________

If you see the message "Attempt Failed" when you have tried to turn your area(s) on, one

or more zones may be open, or may have a fault. If possible, make sure that all of the

zones are closed when you turn an area on.

WARNING: Turning on areas with open zones reduces your security protection. If a zone

in your area is not working, or you cannot close it, call a Supervisor or Master user

immediately, so that the problem can be resolved.

1. Use procedures 2.2 or 2.3 to try to turn on all or some of your areas.

2. Keypad displays:

Turn On All Turn On Area?

Your Areas? OR Area 1

To confirm either of these options, press .

3. The keypad displays:

Attempt Failed

View Problems? To see a list of open zones, press .

4. The keypad displays a list of the zone(s) that are open, or that have faults, and the

area(s) they are in. Use the keys to view each open zone. When you come to

the end of the list, the keypad displays:

End of List

Turn On Anyway?

5. Check Open Zones

If you want to go and check that the listed zones are closed, press .

The keypad displays:

System Will Not

Turn Areas On!

Close all doors and windows, or stop motion in each zone that was listed, then go

back to step 2. If all the zones are secure, you will be able to turn on the selected

area(s) as described in procedures 2.2 and 2.3. continued next page...

Step

Andere Handbücher für Maxsys PC6010

Inhaltsverzeichnis

Andere DSC Sicherheitssystem Handbücher

DSC

DSC PC1000 Bedienungsanleitung

DSC

DSC PC1550 Bedienungsanleitung

DSC

DSC Digital Security Control PC158O Bedienungsanleitung

DSC

DSC WS4965 Bedienungsanleitung

DSC

DSC Power 832 Bedienungsanleitung

DSC

DSC PG9929 Bedienungsanleitung

DSC

DSC PowerSeries PC1404 V1.1 Bedienungsanleitung

DSC

DSC PowerSeries Neo HS2064 E Bedienungsanleitung

DSC

DSC Voice Assisted Security Control Escort 4580 Bedienungsanleitung

DSC

DSC neo HS2016 Bedienungsanleitung

DSC

DSC PowerSeries Neo HS2128 E Bedienungsanleitung

DSC

DSC Power 832 Bedienungsanleitung

DSC

DSC PowerSeries Bedienungsanleitung

DSC

DSC WS900 Bedienungsanleitung

DSC

DSC POWER 608 Bedienungsanleitung

DSC

DSC Escort5580 Voice Assisted Security Control Bedienungsanleitung

DSC

DSC PC1616; PC1832; PC1864 Bedienungsanleitung

DSC

DSC PowerSeries PC1832 Bedienungsanleitung

DSC

DSC Maxsys PC6010 Bedienungsanleitung

DSC

DSC ALEXOR Bedienungsanleitung

DSC

DSC IMPASSA Bedienungsanleitung

DSC

DSC Classic PC580 Bedienungsanleitung

DSC

DSC Power 832 Bedienungsanleitung

DSC

DSC IMPASSA Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung
