DSC PowerSeries Neo Bedienungsanleitung

Chapter 1

1.0 Quick Reference

The PowerSeries Neo Alarm System uses shortcut keys to access options or features on all models of keypads. When using an

LCD keypad, the PowerSeries Neo Alarm System additionally uses a menu based navigation system. The scroll keys can be used

to [Scroll] through the list of options contained within the current menu. For more information on keypads see: 2 “Understanding

your Keypad”. Lookup detailed information on any of the listed actions using the accompanying Section number.

Note:Some features must be enabled by installer.

Note:Bypass Groups are not permitted in UL listed installations.

Note:[*] - If configured by installer.

Status

Lights Function Keys Function

Keys

Status

Lights

Emergency

Keys

Emergency

Keys

Ready - Indicates system normal. Must be on to arm system. All zones

must be secured or bypassed and the system disarmed for this light to

activate.

Stay

Arm

Fire Alarm

Armed- Indicates system is armed. If the Ready light and the Armed

light are both on, an Exit Delay is in progress.

Away

Arm

Medical

Alarm

Trouble - On indicates a system malfunction or tamper. Flashing indic-

ates that the keypad has a low battery condition. Follow the instructions

displayed or enter [*][2] to view trouble. Correcting the trouble turns

off the indicator.

Chime Panic Alarm

AC Power - Indicates AC Power is present. The AC Power light will

turn off when AC is absent.

Reset

Sensors

 

  Quick

Exit

 

Action Press Section

Arming and Disarming

Away Arm for 2 seconds + [Access Code*] 3.1.2

Stay Arm for 2 seconds + [Access Code*] 3.2

Night Arm When armed in stay mode [*][1] + [Access

Code*]

3.3

Disarm [Access Code] 3.1

No-Entry Arming [*][9] + [Access Code*] 3.4

Quick Arm/Quick Exit [*][0] 3.5

Abort Arming Sequence [Access Code] 

Bypassing - All bypass commands begin with [*][1] + [Access Code*]

Bypass Individual Zones [3 Digit Zone #] 3.7.1

Bypass All Open Zones [9][9][8] 3.7.1

Recall Last Bypass [9][9][9] 3.7.1

Clear Bypass [0][0][0] OR [Scroll] Bypass Options + [*]

+ [Scroll] Clear Bypasses + [*]

3.7.1

Program Bypass Group [3 digit zone #s] + [9][9][5] OR [3 digit

zone #s] + [Scroll] Bypass Options + [*] +

[Scroll] Prg Bypass Group + [*]

3.8

Load Bypass Group [9][9][1] OR [Scroll] Bypass Options + [*]

+ [Scroll] Bypass Group + [*]

3.8

Common Functions

Set Time and Date [*][6] [Master Code] + [0][1] 8.2

Turn Chime ON/OFF [*][4] + [Access Code*] OR 10.1

Change Brightness [*][6] [Master Code] + [1][2] + 8.8

Change Contrast [*][6] [Master Code] + [1][3] + 8.8

- 4 -

Chapter 1

Action Press Section

Add/Delete User [*][5] + [Master Code] + [Access Code] +

7.0

Reset Smoke Detectors OR [*][7][2] 5.2

View Troubles [*][2] + [Access Code*] + 8.15

View Alarms [*][3] + [Access Code*] + 5.1.5

Perform System Test [*][6] + [Master Code] + [0][4] + 4.4

Buzzer Volume [*][6] + [Master Code] + [1][4] + 8.10

- 5 -
