Dualit SOUP KETTLE Produktinformationsblatt

INSTRUCTION AND

GUARANTEE OF

THE SOUP KETTLE

2007.09.10_DSK1_ Manual.qxp 07/08/2008 14:37 Page 1

2007.09.10_DSK1_ Manual.qxp 07/08/2008 14:37 Page 2

IIMMPPOORRTTAANNTTSSAAFFEEGGUUAARRDDSS..........................................

KKNNOOWWIINNGGYYOOUURRSSOOUUPPKKEETTTTLLEE..........................

UUSSIINNGGYYOOUURRSSOOUUPPKKEETTTTLLEE........................................

SSEERRVVIICCIINNGG&&GGUUAARRAANNTTEEEE..........................................

CONTENTSINTRODUCTION

THE DUALIT SOUP KETTLE

Dualit soup kettle are constructed

from an aluminium water holder and

stainless steel inner liner, with longlife

heating elements that reach the

desired temperature quickly.

Lids are hinged and removable plus

soup kettles come with a set of

magnetic display cards.

Perfect for front of house serving of

soups, also ideal for foods such as

gravy or chilli.

2007.09.10_DSK1_ Manual.qxp 07/08/2008 14:37 Page 3

IMPORTANT SAFEGUARDS

READ ALL

INSTRUCTIONS

• To protect against risk of electrical

shock, do not immerse soup kettle

in water or other liquid

• Make sure the electrical outlet is

rated at the same voltage as that

stated on the bottom of the power

base

• Unplug from outlet when not in

use, before putting on or taking

off parts, and before cleaning

• Do not operate the soup kettle

with a damaged cord or plug or

after appliance malfunctions, or is

dropped or damaged in any

manner. Return appliance to the

nearest Authorized Service Centre

for examination, repair or electrical

or mechanical adjustment

• Do not use outdoors

• Do not operate on a inclined plane

• Do not let cord hang over edge of

table or counter

• Always operate with lid in place

• Keep kettle empty when not in use

• This is a WET HEAT ONLY

kettle, a small amount of

water is required between the

inner and outer liner in order

to operate. Do not overfill

• The food item must be heated

prior to using the soup kettle, the

kettle is designed to keep food

warm, not for cooking

• Do not operate kettle empty

• Parts and surfaces of the soup

kettle will get hot

• Do not operate kettle empty

• This appliance must be earthed

• Never move or carry the kettle

when unit is switched on, or

containing food

• This appliance is not intended for

use by persons (including children)

with reduced physical, sensory or

mental capabilities, or lack of

experience and knowledge, unless

they have been given supervision

or instruction concerning use of

the appliance by a person

responsible for their safety

• If the supply cord is damaged, it

must be replaced by the

manufacturer, its service agent or

similarly qualified persons in order

to avoid a hazard

• Leave a 40mm clearance round

the soup kettle

• The kettle must not be cleaned

with a high pressure jet

SAVE THESE

INSTRUCTIONS

2007.09.10_DSK1_ Manual.qxp 07/08/2008 14:37 Page 4

KNOWING YOUR SOUP KETTLE

1. Stainless steel liner

2. Lid with hinge

3. Collar

4. Main body

5. Temperature control

‘0’ = Off position

‘1 - 7’ = Serving

‘8 - 12’ = Extra hot

6. Neon indicator

PARTS AND CONTROLS

2007.09.10_DSK1_ Manual.qxp 07/08/2008 14:37 Page 5

OPERATING THE SOUP KETTLE

USING YOUR SOUP KETTLE

• Position main body on a clean and

level surface

• Place collar on top on main body

• Hold the hinge on the lip of the

collar, as shown on diagram

page 5

• Insert the stainless steel liner into

the main body

• Once assembled the liner will hold

the collar and lid in place

• Plug unit into correct electrical

socket

• This appliance is suitable for

WET HEAT OPERATION ONLY

Add a maximum of 750ml water

between the stainless steel liner

and internal aluminium container

in the main body. Refill if water

level reaches the ‘MIN’ mark

Never overfill with water and

under no circumstances should the

stainless steel liner float up, even

when empty. Remove any excess

water immediately

• Add your already heated food

items into the stainless steel liner

• Do not fill above the ‘MAX’ mark

located on the inside of the

stainless steel liner

• To turn on, rotate the temperature

knob clockwise off the ‘0’ setting

• The neon indicator will glow when

the unit is turned on

• Always operate the soup kettle at

the lowest possible temperture in

order to minimise electricity costs

• Rotate the temperature knob to

the desired setting:

1 to 7 - Use during serving periods

8 to 12 - Extra hot setting

• Attach the soup of the day label,

insert the name card into the

magnetic holder. Fix holder

anywhere on the exterior of the

main body

• To switch off, turn the dial to ‘0’.

Unplug from the wall socket to

isolate kettle from the electrical

supply

• Always keep the removable hinged

lid attached and in the closed

position when not serving

• Never move or carry the kettle

when unit is switched on, or

containing food

ASSEMBLING

2007.09.10_DSK1_ Manual.qxp 07/08/2008 14:37 Page 6

GUARANTEE

• Switch off, unplug and

un-assemble before cleaning

• Do not let the main body, flex or

plug get wet

• Wipe main body with damp cloth,

then dry

• Spilled food should be removed

immediately from all exterior

surfaces

• The stainless steel bain marie and

lid are machine washable

• The kettle must not be cleaned

with a high pressure jet

If your soup kettle fails wwiitthhiinnoonneeyyeeaarr

ffrroommddaatteeooffppuurrcchhaasseewe will repair or

replace it free of charge provided:

• You have not misused, neglected

or damaged it

• It has not been modified

• You supply your receipt showing

When you bought your soup kettle

The guarantee does not affect your

statutory rights.

If over one year, contact Dualit for

recommended repair agents.

Further advice on using your Dualit

soup kettle and other products in the

Dualit Range is available from:

Dualit Customer Help line on

+44 (0) 1293 652 500

(09:00 to 17:00 Monday to Friday)

Alternatively email: [email protected]

Dualit does not assume any

responsibility for incidental or

consequential damages.

CLEANING

SERVICING

YOUR NOTES

2007.09.10_DSK1_ Manual.qxp 07/08/2008 14:37 Page 7

DUALIT LIMITED COUNTY OAK WAY CRAWLEY WEST SUSSEX RH11 7ST

TELEPHONE: +44 (0)

1293 652 500

FACSIMILE: +44 (0) 1293 652 555

EMAIL: info@dualit.com WEB: www.dualit.com GB0907
