DULUCK A104 Montageanleitung

DULUCK A104 - KNOW YOUR DEVICE

(KYD )

DULUCK A104

Let’s ... act smart

www.duluckos.com, Customer care:- +918083666333, Email:- [email protected] P.T.O.

PANEL SOFT-TOUCH-KEY’S DESCRIPTION

www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]

1.MIC hole

2.Lamp brightness control

3.Lamp on & off /lamp switch

4.Startup & Shutdown key/mode switch

5.Play/pause key

6.Volume level control

7.MIC hole

8.Microphone on-off key

9.Awakening / Networking key WPS button

10.Power adapter jack

11.digital clock display

Content in Box:-

• One Duluck Alexa enabled speaker,

• One USB power Adopter & USB charging cable

• User manual,

• Warranty card,

• Duluck Alexa enabled mini guide,

• Duluck smart controller information card.

PANEL SOFT-TOUCH-KEY’S FUNCTIONS

NOTE:- ALL THE KEY’S OF THE DULUCK-A104 DEVICE ARE SOFT-TOUCH KEYS.

1. MIC hole

Receive the spoken voice and then the host recognizes voice command

2. Lamp brightness control

Slide up to increase the lamp brightness and slide down to decrease the lamp brightness

3.Lamp on & off /lamp switch

Short press to turn on the lamp, Long press 3 seconds to enter multi-color lamp mode with circular gradient, and short press to switch multi-

color lamp color

4. Startup & Shutdown key/mode switch

Short press to switch BT mode/WIFI mode, long press 3 seconds to shut down/start up the device.

5. Play/pause key

Short press, for pause/play the music

Long press can turn digital clock On/Off

6. Volume level control

Slide up to increase the volume level. When the volume is at its maximum, the device will beep remind.

Slide down to decrease to volume level. When the volume is at its lowest, the last little lamp will ﬂash.

7. MIC hole

Receive the spoken voice and then the host recognizes voice command

8. Microphone on-off key

Short press to turn on/off the MIC and recognize the received voice.

9.Wake up/connect key (WPS)

Long press is to connect/conﬁgure the device to Wi-Fi internet and follow the instructions given by device as well as APP

Short press to wake-up the device & device is ready for taking voice command (Its just like saying wake-up command “Alexa”

(Some times, if the place is very-very noise and its hard for device to recognize the wake-up command, then user can activate the device by

soft touching this key and give voice instructions to device.)

10.Power adapter jack

Plug in the adapter to power the host

11.Digital clock display

Clock will show the time as per location entered in the device-setting module in your Amazon account. For correct information of local time

and other businesses, user must enter the device location and other input parameters in his Amazon-account in Amazon-APP.

Basic requirements:-

• Smart phone,

• Wiﬁ Network,

• Duluck-Alexa-Device,

• Power adopter

• Power source for power adopter 230V 60Hz.

Important:-

Connect your phone to the same wiﬁ network to which you want your Duluck- Alexa-Device to connect.

Download Amazon Alexa-APP from Apple/Google App store

Make/Signup your account and login ID. Memorize your user Id and Password of Amazon-Alexa-account.

Note:- Do not share your password with any one.

Download Duluck-APP from Apple/Google APP store

By copying the APP-Download link in Duluck website www.duluckos.com and open in cellphone browser

DULUCK A104 INSTALLATION & DEVICE SETTINGS

www.duluckos.com, Customer care:- +918083666333, Email:- [email protected] P.T.O.

To gain maximum use / utilization of Duluck-Alexa-speaker, kindly read the following booklets supplied with Duluck-Alexa-device. Or Check

www.duluckos.com and read “Alexa in our life”

Duluck-Alexa user mini guide.

Duluck-Alexa voice commands.

Duluck smart controllers.

Procedure:-

• Connect your phone to Wi-Fi network.

• Download Duluck-APP from Apple/Google APP store ( ) Or https://play.google.com/store/apps/details?id=com.wiﬁaudio.DULUCK

• By copying the APP-Download link in Duluck website www.duluckoverseas.com and open in cellphone browser

Connect the Power adopter supplied with device. When you hear the power-on prompt sound, enter the network conﬁguration state directly

or long touch the WPS ("Awakening/ Networking") key for 5 seconds, and the panel UI Led ring will keep rotating and running. Your Duluck

device will say “Entering setup mode.”

www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]

Long press Awakening / Networking key

button to enter the network conﬁguration

state mode.

First, check whether the phone has

WIFI on and connect to the router to

be connected.

Click the mobile desktop to enter the

APP

www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]

P.T.O.

Click

Press Duluck-APP icon on your

phone screen.

The APP will start searching the Duluck-Alexa-Devices near by and

you will see a radar searching the same.

To add New device press “ + “ on the right corner of the screen.

Press “Settings”

Press “Add Device”

Note:-

If some Duluck-Alexa enabled -Devices are already connected on the same wiﬁ network on which your phone is connected, then you will see

the following screen with number of devices written in the middle and after that, the app will display list of devices already connected to the

same wiﬁ network.

The app will take you to the Wiﬁ setting screen of your phone showing available Wiﬁ networks.

• Press “DULUCK model no. A104_XXXXX” in available wiﬁ list.

• Your speaker will say “You are now connected to your speaker”.

• Above screen’s will appear with list of available wiﬁ networks near your location

• Select the Wiﬁ network you wish to connect and enter password. Press “continue”

• After this, APP will take about 45 to 120 seconds and following screen will appear. When your speaker is connected to wiﬁ, it says

“Connected to Wiﬁ”

Note:- After completing the process of Wi connection, some times following screen will appear. Follow the instructions

mentioned on the screen. Make sure your phone & speaker both should be connected to same network.

www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]

Click

• This screen will appear with list of available wiﬁ networks near your location.

• Select the Wiﬁ network you wish to connect and enter password. Press “continue”

• After successful connection of your speaker with Wiﬁ you will see following screen.

• Press Name of the Duluck-Alexa-Device. Press top right corner arrow “>”.

Enter your custom name

and click conﬁrm

www.duluckos.com, Customer care:- +918083666333, Email:- [email protected] P.T.O.

Click

Wiﬁ

Setting

Click Next

Click

Custom

• Press “Switch account” and the app will take you to Amazon Alexa Account sign-in screen

• If you press skip, the device will automatically connect the Amazon account it was connected before.

After enter Amazon account and

password, please click sign in

Please select your lanuage

www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]

Enter Amazon account

and password

If you don’t

have an

Amazon

account,

please

create a new

Amazon

account

Click

Note:- If your Duluck Alexa enabled Device is ﬁtted with Duluck-Smart-Controllers then app will take you to the binding of device option

screen. Kindly follow the instructions on your smart phone screen and bind the device.

www.duluckos.com, Customer care:- +918083666333, Email:- [email protected] P.T.O.

Settings wheel

Click

If you don’t know

how to

set the lamp, please

click

“How

to enable skill”

Prompt

binding

success

After successful binding you will see the following screen with newly added Duluck-Alexa enabled -Device.

• Press “Speaker info” and in “Hotspot Status” options, Turn slider button “On”

• Press “Wi-Fi password” option and enter the password you want for your “Hotspot-Wiﬁ”. Now after this user can see the Wiﬁ name in

his smart phone wiﬁ list with the name written in SSID column

www.duluckos.com, Customer care:- +918083666333, Email:- [email protected]

Press-setting

icon “Wheel”

on the right

corner of your

device name.

Press Amazon-

Alexa settings.

Select your

language by

pressing

“Amazon

Alexa

language” and

set request

sound “On”.
