DW DW-BJBOLT4T-LX Bedienungsanleitung

State of the art hyper-optimized video management platform designed for ease, speed and efciency.

Blackjack®BOLT — Up to 16 2.1MP Cameras (1080p True HD Resolution)

DW-BJBOLT2T-LX DW-BJBOLT4T-LX DW-BJBOLT6T-LX DW-BJBOLT8T-LX DW-BJBOLT12T-LX DW-BJBOLT16T-LX

Blackjack BOLT-LX

Quick Start Guide

Tel: +1 (866) 446-3595 / (813) 888-9555

Technical Support Hours: 9:00AM – 8:00PM EST, Monday thru Friday

digital-watchdog.com

Attention: This document is intended to serve as a quick reference for initial set-up.

See the DW Spectrum full manual for more information on features and functionality.

Default Login Information for DW Spectrum®IPVMS

Username: admin Password: admin1234

WHAT’S IN THE BOX

BOLT Server 1 Set Recovery USB 1 Set Power Cable 1 Set

Quick Start

Guide 1 Set Keyboard and

Mouse 1 Set

NOTE: Download All Your Support Materials and Tools in One Place

1. Go to: http://www.digital-watchdog.com/support-download/

2. Search your product by entering the part number in the ‘Search by Product’ search bar. Results for applicable part numbers will

populate automatically based on the part number you enter.

3. Click ‘Search’. All supported materials, including manuals, Quick Start Guides (QSG), software and rmware will appear in the results.

BLACKJACK BOLT HARDWARE

SPECIFICATIONS BOLT

F5F4 F3

B1 AC Power Socket

B2 PS/2 Keyboard and PS/2 Mouse Port

B3 DVI-D Port

B4 HDMI Port

B5 USB 2.0 Ports

B6 Mic In (Pink)

B7 Line Out (Green)

B8 Line In (Blue)

B9 Ethernet Port to the Camera Network

B10 Ethernet Port to the Local Network

B11 USB 3.0 Ports

B12 D-Sub Port

F1 HDD LED

F2 Power Button / Power LED

F3 USB 2.0 Port

F4 Microphone Jack

F5 Headphone Jack

F6 Reset Button

WARNING For an optimal system conguration, it is recommended that a UPS (Uninterruptible Power Supply) be used to power the setup.

Dual monitors are not recommended due to CPU performance. To connect two monitors to the BOLT, go to the display setup to activate

the second monitor.

Front

B1 B2 B3 B4 B6B5

B12 B10B11

Back

Default Login Information for Pre-Installed DW Spectrum®IPVMS

Username: admin Password: admin1234

MODEL Blackjack BOLT

Maximum IP Cameras 16

Included IP Licenses 4

Form Factor Slim Desktop

Operating System Linux®Ubuntu®DW-BJBOLT - LX

CPU Intel® Quad Core N3150 Processor

Memory 4GB

NIC 2x Gigabit Ethernet (RJ45)

System Max Video Storage Rate (Mbps) 80 Mbps

Storage Maximum Hard Drives 2 x HDD

Maximum Storage 16TB

Video-Out Outputs True HD Output, DVI or D-Sub Port

Resolution HD 1080p

Pre-Loaded VMS Software DW Spectrum®IPVMS

Unlimited Remote Clients Cross Platform - Windows®, Linux®and Mac®

Mobile Apps iOS®and Android®

Keyboard & Mouse Included

Power 200W **

Operating Temperature and Humidity 41°F-104°F / 20-90% RH

Dimension (WxDxH) (inches) 3-7/8” x 14” x 10-3/8” (Standing)

10-3/8” x 14” x 3-7/8” (Desktop

Warranty 5 Year Limited

** UPS Recommended

SETTING UP THE BOLT

STEP 1: Connect peripherals, power and network

1. Connect a monitor, USB keyboard, USB mouse, and network cable to the camera network (B9 on the diagram).

* Cable for the Local Network should be connected after the IP settings are congured.

2. Connect the server to an appropriate power source. Recommended to use 750VA or higher UPS system.

Quick Start Guide

Camera Network POE Switch

Blackjack BOLT

Monitor

Keyboard Mouse

UPS System

3. Turn on the server if the server does not turn on automatically.

(Press the Power Button on the front of the BOLT. F2 on the diagram).

* Connecting the power cable to the live power source may turn on the server automatically

STEP 2: Set Date and Time

1. Update Date and Time by clicking on the time on the upper right-hand corner then click “Time & Date settings…”

2. If the server will be connected to the Internet, leave Set the Time to “Automatically from the Internet” and update the Location

to the correct Time Zone. Enter the nearest major city to select the correct Time Zone. If it shows multiple cities in the list,

select the correct city. (e.g., New York for EST, Chicago for CST, Denver for MST, and Los Angeles for PST)

3. Click X on upper left corner of the Time and Date window when done.

* Closing the window will automatically save the changes made.

Quick Start Guide

STEP 3: Congure Network

Please have the following information ready before starting the network conguration.

Camera Network Local Network (LAN)

IP Address

Netmask

Gateway Not Applicable

DNS Servers Not Applicable

* Camera Network and Local Network cannot be on the same network.

* Netmask is also known as Subnet Mask. Gateway is also known as Default Gateway.

Once you have all the information, double-click the Network icon on the Desktop

1. Select ‘Wired’ that has arrows pointing up and down from the list (If neither of the “wired” are showing arrows up and downs,

then make sure the network cable is connected to the PoE switch on the camera network from STEP 1)

2. Click ‘Options’ at the bottom of the window.

3. Click on the ‘IPv4 Settings’ tab.

4. From the drop-down menu, select connection type (“Method”) as Manual.

5. Click ‘Add’ next to Addresses.

NOTE The Blackjack BOLT’s network settings are set to DHCP as default.

NOTE If you are not sure what information to enter, contact your Network Administrator or Internet Service Provider

for the information.

6. Enter IP Address then press Tab on the keyboard to move to Netmask.

7. Ignore any populated values and enter the valid Netmask value, then press Tab on the keyboard to move to the Gateway.

8. Enter the Gateway address if required then press Enter on the keyboard.

* Gateway is not required on the camera network.

9. Click ‘Save’ to save the settings.

10. In the Network Settings main page, make sure the Wired Status is marked as “Connected”

or “Managed” with the IP Address displayed.

NOTE It must be the same network as the cameras and must not be the same network as the local network.

Contact your network administrator for more information.

Local Network

11. Select Wired with picture of network port and repeat 2 to 8 of STEP 3 Congure Network.

Quick Start Guide

STEP 1: Initial run from Blackjack®server

1. Open DW Spectrum®Client by double click on the DW Spectrum icon

2. Click on the precongured server.

Password : admin1234

12. Click on the DNS Servers eld box and enter DNS server address.

13. Click Save.

14. Connect a network cable from B10 Ethernet port on the diagram (page 2)

to the switch connecting to the local network.

15. Verify the network is Connected.

NOTE If you are not connecting to the Blackjack®from within the same network, you may be required to perform port forwarding on your

router to access the server. Contact your Network Administrator or Installer for additional information

SETTING UP DW SPECTRUM®MEDIA SERVER

B10

3. Enter password and click connect.

*Default password : admin1234 (case sensitive)

STEP 2: To rename the server

1. Right click on the server name listed on the Resources then click Server Settings.

Quick Start Guide

2. Go to General tab, then type in the new server name in the Name eld and click OK.

STEP 3: To check for update

1. Click on the menu then click System Administration.

2. Go to Updates tab. Click Update System if turned orange.

3. Click OK when update is completed.

*If you are on the latest version, it will say “You have the latest version installed” and the Update System button will be greyed out.
