Quick Setup Guide I DX-SP211
2-Way Indoor/Outdoor Multipurpose Speakers
Package contents
• 2-way indoor/outdoor speakers (2)
• Mounting brackets (2)
• Knobs (4)
• Mounting screws (8)
• Adhesive-backed cushions for mounting brackets (4)
• Adhesive-backed cushioned feet for speakers (8)
Setting up your speakers
Installing the brackets (optional)
You can connect the speakers to wall-mount brackets for
elevated wall positioning.
Note: If you are positioning the speakers on a shelf or other
surface, attach the provided cushioned feet to the bottom
of each speaker.
1Secure the wall-mount brackets onto the wall where you
want to mount the speakers. If the location is backed by
wall studs, you can use the wood screws provided. If the
location is backed by only dry wall (gypsum board or
other wall material), use wall anchors (not included).
2Attach the provided mounting bracket cushions on the
inside of the brackets so they protect the bracket screw
holes.
3Slide a speaker into each mounting bracket.
4Line up the screw holes (one on top, one on bottom),
then screw a knob into each hole to secure the speaker
to the bracket. You can loosen the knob to adjust the
direction the speakers are pointing.
Connecting the speakers
For best performance, you must connect the speaker wires
correctly. All two-conductor wire is marked in some way to
help you do this. One side will be marked with a colored
stripe, a raised rib, or a dierent-color conductor. Use the
marked side for the“red” connections.
1Connect the red speaker terminals to the red (+)
amplier terminals.
2Connect the black speaker terminals to the black (-)
amplier terminals.
To verify connections:
1Switch your amplier to MONO and place your speakers
close to each other.
2Adjust the balance control so that only one speaker is
playing.
3Listen to the bass level and adjust the balance control so
that both speakers are playing. If the bass decreases
when both speakers are playing, one of the speakers is
connected incorrectly, and the positive (+) and negative
(-) terminals should have the speaker cables reversed.
Adjusting volume
• If you hear distortion, immediately reduce the volume.
Permanent speaker damage can occur within seconds.
Distortion indicates that the amplier or speaker is
operating beyond its design limits. Do not ignore
distortion just because the volume control is not all the
way up. Most ampliers deliver full power when the
volume control is set near the middle of its range. Using
loudness, bass boost, treble boost, or an equalizer can
produce full output at even lower settings, so distortion
is the only true indicator that damage is imminent.
• Almost any speaker can be used with almost any
amplier, but almost any speaker can be damaged by
almost any amplier (despite either unit’s power rating).
Dynex’s power recommendations are accurate only if
our assumptions concerning the amplier, the type of
music, and the conditions of use are correct. Our most
important assumption is that the volume is never set
above the point of distortion.
Positioning your speakers
The performance of your new Dynex speakers, as with any
high-quality system, is inuenced by their placement in
your listening room.
Consider these guidelines as you select the speaker positions:
• Place the speakers so that they face your listening area.
Ideally, the grill fronts (front of the speakers) should be
“aimed” towards ear level.
• If you are installing your speakers outdoors, select
locations facing your listening area that are protected
from rain and snow, and out of direct sunlight.
Maintaining your speakers
• Maintain the nish of your speakers by wiping the
surface with a damp cloth.
• To clean the grilles, you can vacuum them or gently tap
them.
Specications
Design..................................................Weather resistant, 2-way
Woofer.........4" (10 cm) dynamic with polypropylene cone
Tweeter...................................... 2" (5 cm) polycarbonate cone
Impedance ...........................................................8 ohm nominal
Eciency..............................................................84 dB @ 1W-1m
Frequency response............................................. 90 Hz-20 KHz
Amplier power* (min/max) ...........................................5-40W
Enclosure ...........................................................Cast polystyrene
(mounting brackets included)
Product Net Weight..........................................2.09 lbs. (.95 kg)
with bracket..................................................... 2.32 lbs. (1.05 kg)
Product dimensions ................ 7.4" × 4.6" × 4.3" (H × W × D)
(18.7 cm × 11.7 cm × 11 cm)
with bracket............................... 8.6" × 4.6" × 5.3" (H × W × D)
(21.9 cm × 11.7 cm × 13.6 cm)
*Power recommendations are based on amplier volume
never being set above the point of audible distortion.
90-day limited warranty
For complete warranty, visit www.dynexproducts.com.
Contact Dynex:
For customer service, call 800-305-2204
www.dynexproducts.com
