i129-411www.powercommander.com 2007 Honda CB600F - 1
2007 Honda CB600F
Installation Instructions
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
Parts List
1Power Commander
1USB Cable
1CD-ROM
1Installation Guide
1Power Adapter
2Power Commander Decals
2 Dynojet Decals
2 Velcro®Strip
1Alcohol Swab
1O2 eliminator
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition MUST be turned
OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
USB Port
Expansion Port
1Remove the seat.
2Remove both BLACK side panels.
3Remove or prop the fuel tank up.
4Lay the PCIII in the tail section and
route the PCIII harness towards the
front of the bike (Fig. A).
5Route the PCIII harness down the left
hand side of the bike.
Route the PCIII harness underneath
the frame crossover bracket (Fig. B).
Make sure the harness is routed so as
to not be damaged by the fuel tank.
6Attach the ground wire from the PCIII
to the negative side of the battery
(Fig. B).
Fig. AFig. B
i129-411 www.powercommander.com 2007 Honda CB600F - 2
PCIII harness
7Route the PCIII harness along the left
hand side of the frame spar as in
Fig. C.
Fig. C
PCIII harness
PCIII harness
PCIII ground wire
9Plug the connectors from the PCIII in-
line of the stock injectors and wiring
harness (Fig. E).
This picture only shows cylinder #1.
Repeat steps 8-9 for all 4 injectors.
PCIII harness:
ORANGE - cylinder #1
YELLOW - cylinder #2
GREEN - cylinder #3
BLUE - cylinder #4
Fig. E
8Unplug the stock wiring harness for
cylinders #2 and #3 (Fig. D).
Fig. D
i129-411 www.powercommander.com 2007 Honda CB600F - 3
Stock connector
Unplug
10 Locate the Throttle Position Sensor on
the left hand side of the throttle
bodies.
Unplug this connector (Fig F).
Fig. F
PCIII connectors
Unplug
11 Plug the connectors from the PCIII in-
line of the TPS and stock wiring har-
ness (Fig. G).
12 Locate the stock O2 sensor wiring
harness connection to the main wiring
harness. This connection is under-
neath the fuel tank on the right hand
side of the air box.
13 Plug the Dynojet O2 eliminator into
the main wiring harness. The stock
O2 sensor can be left disconnected or
removed from the exhaust if you have
a way to cap the exhaust.
14 Secure the PCIII to the tail section
using the supplied velcro. Make sure
to use the alcohol swab to clean both
surfaces before mounting.
15 Reinstall the fuel tank and seat.
Fig. G
i129-411 www.powercommander.com 2007 Honda CB600F - 4
Fig. H
PCIII connectors
Stock
connector
Fig. J
Dynojet O2
eliminator
Unplug
