Earlens Photon™
2 Processor
User Manual
1
Earlens Photon™2 Processor
User Manual
2
Welcome
Thank you for choosing the Earlens Light-Driven Hearing Aid. This user manual
is designed to show you how to use and care for your new Earlens Hearing Aid.
We encourage you to carefully read this entire booklet including the Warnings
and Precautions sections to achieve the maximum benet from your new
hearing technology.
If you have further questions that are not answered in this manual, please contact
your hearing professional or call the Earlens Concierge at 1
-844-234-LENS. You
should always access the most up-to-date version of the Earlens Light-Driven Hearing
Aid Patient Instructions for Use (IFU) at www.earlens.com/IFU. The IFU contains
detailed warnings, precautions, results from Earlens Hearing Aid clinical studies and
information regarding safe and eective EMC use.
3
Getting to Know Your Earlens Hearing Aid .........4
The Lens ...................................................................6
The Photon™2 Processor and Light Tip...............7
The Charger .............................................................8
Mineral Oil .............................................................10
Using your Earlens Hearing Aid .......................... 11
Turning the Processor On/O.............................11
Identifying Left or Right Device ...........................13
Putting on the Processor and Light Tip.............14
Removing the Processor and Light Tip..............16
Changing Volume and Program ........................17
Processor Alerts.....................................................22
Telephone and Cellphone Use ............................24
Charging and Battery Life ...................................26
Cleaning and Maintenance .................................. 27
Daily Care...............................................................27
Oiling Instructions.................................................29
Avoiding Moisture & Heat....................................32
Warranty................................................................33
Troubleshooting...................................................... 34
Warnings................................................................... 36
Precautions .............................................................. 38
Technical Information............................................ 42
Device Labeling Symbols ...................................... 44
Contents
4
Getting to Know Your Earlens Hearing Aid
The Earlens Hearing Aid uses a small Lens placed in your ear by a physician to
activate your natural hearing system.The behind-the-ear Photon™2 Processor
collects sound and transfers it to the Light Tip, which converts the sound signal
to non-visible light. The Lens collects this light and gently activates your natural
hearing system.
There are important components to your Earlens Hearing Aid that will be described
in this section: the Lens, the Processor, the Light Tip, the Charger and mineral oil.
The components that you will interact with include the Processor,
Light Tip, Charger and mineral oil.
5
1Sound enters the microphone on the Processor,
which transforms the sound and sends the
audio signal to the Light Tip.
2The Light Tip converts the audio signal into light
and then projects the light wave to the Lens, which
makes direct contact with the eardrum.
3When the Lens is activated by the light wave,
it vibrates the eardrum gently at dierent
frequencies—resulting in rich, natural sound.
1
2
3
6
The Lens
The Lens is driven by light waves that contain sound information. When the Lens
detects light waves, it gently activates your natural hearing system allowing you to hear
sound. To keep your Lens functioning properly, you must apply Earlens mineral oil
twice a week and avoid placing foreign objects in your ear (such as Q-tips, bobby
pins, and your ngernails).
7
The Photon™2 Processor and Light Tip
The Processor sits comfortably behind your ear. It collects and sends sound signals
to the Light Tip, which then converts the sound signals into non-visible light that is
projected by the emitter. The light from the emitter is collected by the Lens.
Light Tip
Processor
Microphones
Light Cable
Emitter
Vent
User Controls
8
The Charger
The Charger can hold one or two devices. It features a USB-based AC wall power
adaptor as its power source. The Charger includes an LED indicator display to let
you know the charging status of your Processor(s).
Micro-USB
Power Supply
Plug-in
Back View of Charger
Lid
Charging
Status
Indicators
Lid Release
Button
Front View of Charger
Slot Slot
