INSTRUCTION GUIDE FOR XENIO 700
Contents
INTRODUCTION 4
WHAT’S IN THE BOX 5
XENIO TIME CLOCK INSTALLATION 6-9
CONFIGURE WIFI SETTINGS (OPTIONAL) 10-11
CONNECT VIA ETHERNET/NETWORK CABLE 12
HOST PC SETTINGS 13-14
EXPORTING TIME LOGS INTO USB 15-16
ADDING EMPLOYEES 17-20
Adding an Employee’s Fingerprint 17-18
Adding a Smart Card to an Employee 19
Adding a Pin Number to an Employee 20
ASSIGNING ADMINISTRATOR/MANAGER LEVEL 21-22
HOW TO PROPERLY CLOCK IN/OUT 23-26
Fingerprint 23
Smart Card 24
Pin Number 25-26
SYSTEM SETTINGS 27-28
This instruction guide covers the
configuration for the following model:
XENIO 700
Manual Version 1.0
©Easy Clocking 2018
4
5
What’s in the box
4x 4x 1x
POWER ADAPTER
A) B) C)
WALL MOUNT
XENIO
SCREWS WALL
ANCHORS
WALL MOUNT
SCREW
XENIO
INSTRUCTION
GUIDE
INSTRUCTION GUIDE FOR XENIO X700
Installation
6
2
4x
Insert Wall Anchors (B)
into the 4 holes that you
marked in Step 1.
1
Using a pencil, mark 4
screw holes on the wall.
7
4
3
*When connecting to your network via ethernet:
Run the cables (ethernet cable not provided)
inside or outside of the wall
4x
Align your Wall Mount with the 4 Wall Anchors (B)
and secure the mount to the wall with the 4
Screws (A) provided.
8
5
6
** Network cable is not required when using Wi-Fi
Connect your ethernet cable to an ethernet
wall jack, router, or switch. Insert the Power
Adapter to an electrical receptacle.
Attach the other end of the ethernet cable and
the Power Adapter to the Xenio.
** When connecting power
to the Xenio via POE, DO NOT connect the provided power adapter.
9
7
8
1x
Attach the Xenio to the Wall Mount,
Secure the Xenio to the Wall Mount by
fastening the Wall Mount Screw (C),
Configure Wifi Settings (optional)
1. Open the Xenio Time Clock Menu
Tap
2. Select Wi-Fi
3. Enable the Wi-Fi option on the Time Clock
To enable Wi-Fi, switch the Wi-Fi option
from OFF to ON located at the top of the screen.
4. Select your Wireless network from the list.
If the network is secured, you will need to input
your security key/password to successfully connect.
If the network is open (no security key/password,)
the device will connect automatically.
Tap
Wi-Fi 1
Wi-Fi 3
Wi-Fi 4
connected
open
secured
Wi-Fi 2
secured
CONNECT
10
