EasyPro PA90AD Betriebsanleitung

Rocking Piston Aeration Systems

Diused Aeration Systems

Installation • Operation

Maintenance Guidelines

Save this booklet for future reference!

Jolie Products, Inc

Thank you for your purchase!

This aeration system will be a great benet to the aquatic ecosystem in which

you are placing it. Please read though the following guidelines completely before

installation and operation of your aeration system.

Safety Warnings

• Use extreme caution when operating in winter. Danger due to thin ice can

cause drowning. Unseen currents can cause thin ice in areas long distances

away from diuser operation. Provide adequate warning for others using a

pond with a diused aeration system.

• The surface of the compressor will be hot during operation. This is normal —

be careful not to touch the compressor while it is running.

• Units must be connected to GFCI protected outlets.

• Avoid using extension cords to operate compressor.

• Keep children or pets away from operating units

• Always disconnect power when servicing system.

• Relieve pressure from system before servicing.

Operation

• All of our compressors are designed for continuous operation. It is not uncom-

mon for these compressors to run 24 hours per day for three to ve years. The

only maintenance required is replacement of wearable items (diaphram, piston

ring, vanes, etc.) when needed and keeping lter clean.

CAUTION: All compressors in these kits are designed for oil-free opera-

tion. Never oil or lubricate the compressors.

• In addition to adding oxygen to your pond, an aeration system creates a circu-

lation action. It takes hours for the maximum eect to be achieved, therefore

we recommend running these systems continuously so that maximum circula-

tion is sustained.

Summer Time Start Up

CAUTION: If you are installing this system at a time when your pond

is already stratied (warm on surface, cold on bottom), you should be

careful when rst starting the aeration system. If the stagnant water on the pond

bottom is stirred up too fast, a temporary increase in oxygen demand will occur

and, in rare cases, a sh kill could result. If your pond is severely stratied, you

should only run your system one to two hours the rst day. Each day after that,

increase the run time by one to two hours during the rst week, run continuously

after that. This will slowly mix the bottom water without a sudden depletion of

oxygen.

Jolie Products, Inc

Installation Precautions

• The air diuser should not be placed in the deepest part of the pond. Try to

locate the diuser at approximately

of the deepest point (a 15' deep

pond would have the diuser at approximately 10' to 12' deep). This allows

the deepest water to remain cool in the summer and stay warm in the winter.

• If you purchased your aeration system without weighted tubing, you will need

to supply small weights such as chimney bricks, pipe or rerod. Strap the

weights securely around the tubing to bring it to the bottom.

• If your pond freezes during the winter, be sure the tubing is buried leading

into the pond. If not, the ice can form around the tubing, kinking it or possibly

shearing it o.

CAUTION: Locate all utilities before digging to ensure safety of installer

and others.

Aeration System Details

Base Kit Maximum* Maximum Diffuser Cabinet

Part # Pond Size Depth Assembly Compatibility

PA34 1 acre 40' (1) EPMD1 SC18, SC22, SC25

PA34-2 1

1/2

acres 40' (2) EPMD1 SC18, SC22, SC25

PA66 3 acres 40' (3) EPMD2 SC18, SC22, SC25

PA86 4 acres 40' (4) EPMD2 SC22

PA90 4 acres 40' (2) EPMD4 SC22

*Factors such as pond depth and pond shape will aect maximum pond size

Note: Kits are available with multiple tubing options (non-weighted, quick sink, mix and match).

Part # column reects generic kit type.

Compressor Specications

Base Kit Maximum Operation Cost

Part # Compressor* Horsepower Cfm per 24 Hours**

PA34 ERP25 1/4 hp 2.5 37¢

PA66 ERP50 1/2 hp 5.2 $1.00

PA86 ERP75 3/4 hp 7.5 $1.38

PA90 ERP75 3/4 hp 7.5 $1.38

*Compressors all carry a two year warranty from date of purchase. See compressor instructions

for warranty details.

**Cost calculated at 9¢ per kwh, continuous operation at 10' depth. Actual operational cost will

depend on unique application.

Jolie Products, Inc

Compressor Placement

It is critical that the air compressors be protected from the weather. You will

need to provide a shelter for your compressor to protect it from rain, snow and

other harsh elements.

• Be sure your shelter is adequately ventilated.

• Be sure the compressor does not sit directly on the ground, as the vibration

from the motor will cause dust and dirt particles to be pulled into the motor

and may cause premature failure.

• If operating compressor in freezing climates do not place compressor in

“heated” buildings. Warm air holds more moisture. This warm air may conden-

sate and freeze in the colder outdoor line.

• Ensure that compressors are placed where they will not become ooded with

water.

• If possible, shaded areas are preferred.

• In areas with limited electrical supply, com-

pressors can be placed long distances from

the pond edge. A remote access valve as-

sembly can be fed from the compressor with

properly sized tubing.

Cabinet Placement

• If installing a Sentinel Deluxe Aeration System, place the cabinet on a level,

unobstructed base to ensure the compressor does not overheat.

• A post mounted cabinet should be kept free from high weeds and other ob-

structions.

Diuser Placement

The amount of surface area an aeration system will eectively cover is greatly

dependent on two factors - DEPTH and SHAPE. The deeper an air diuser is

located, the more boiling action it will create and a larger area will be aerated.

The diagram below shows how much surface area is eectively aerated per

air diuser at various depths. Ponds that are irregular or odd shaped will also

reduce size of aeration area — call our technical department for additional help.

Example:

Our PA34 pond aerator

would aerate only 1

of an acre if operated

in 4' deep water, while

aerating up to 1 acre

if operating in 12' - 16'

deep water.

The shape of a pond aects

the amount of diusers

needed. Irregular shaped

ponds often require multiple

diusers to adequately aerate

entire water column.



AirDiffuser

Jolie Products, Inc

General Assembly Instructions

1. Unpack the aeration system to ensure all parts were received. If a shortage

occurs, please notify EasyPro immediately.

2. Assemble diusers, detailed instructions included with each diuser assembly.

NOTE: Video walkthrough of diuser assembly and installation found at:

easypropondproducts.com/diuser-assembly

Diuser Assembly

1. Barbed check valve is designed to

be used with

" and

" tubing.

Remove end of barb if installing

tubing.

Cut barbed tting here

for 1/2" I.D. tubing

Check valve shown

here, do not remove.

4. Remove plug on the top of the base

and ll about half full (3 to 5 lbs.) with

sand, rock or gravel.

2. Slip hose clamp over barbed check

valve and push tubing tightly onto

the tting.

3. Use washer on both sides of base.

Insert bolt and tighten nut to clamp

down tubing and provide strain relief.

General Assembly Continued

3. Unroll the entire roll of tubing. It is recommended that the pond diuser be

installed at this point. This will allow you to trim any unused tubing before at-

taching to the compressor outlet assembly.

4. Connect the valved outlet assembly to the compressor. Once tubing is in

place and trimmed, attach the other end of the tubing to the exible hose on

the compressor.

5. Open the valves on the outlet assembly to their full open position. Plug the

compressor into a GFCI outlet and adjust each valve to equal the air ow to

each diuser. This corrects the dierence in air ow caused by a dierence in

operating depth and/or tubing lengths.

Jolie Products, Inc

Maintenance Guidelines

• Keep your compressor clean. Any excess dust and debris on motor or air

intake may signicantly shorten the life of the compressor.

• Diusers may need regular cleaning in certain water conditions. This may be

every two to ve years.

• Compressors may need to be rebuilt if running but no longer “pumping air.”

Contact your EasyPro dealer for compressor rebuild kits.

• If lines become frozen, a small amount of denatured alcohol can be run down

the frozen line to thaw it out. The small amount of alcohol will not harm sh or

biological processes in your pond.

After one or two years of operation, you will possibly notice a sudden drop in air

bubbles. This is a sign the compressor needs new piston cup or vanes. Rebuild

kits are available to restore like-new performance. Be sure to keep the air lter

clean. Filters can be washed in soapy water. Replacement lters are available.

Kit Replacement Compressor

Part # Compressor* Filter/Element Repair Kits

PA34 ERP25 ERPF1/ERPF12E ERP25K

PA66 ERP50 ERPF1/ERPF12E ERP50K

PA86 ERP75 ERPF2/ERPF12E ERP75K

PA90 ERP75 ERPF2/ERPF12E ERP75K

*Compressors all carry a two year warranty from date of purchase. See compressor instructions

for warranty details.

Troubleshooting

Compressor Troubleshooting

Low High Compressor Excess

Pressure Pressure Overheating Noise Cause and Solution

• • Dirty air lter, clean or replace

• Valves closed too much, open valves

• • Worn piston cup, rebuild compressor

• Plugged/frozen tubing, inspect and repair

• • Leaky tubing or check valve, inspect and repair

Compressor will not start • Wrong voltage, check power source

Compressor will not start • Miswired electrical components, check wiring

Diffuser Troubleshooting

Low High Uneven Burping

Air Flow Air Flow Air Flow Bubbles Cause and Solution

• • Leak in system, check connections and repair

• • • Manifold not set correctly, adjust placement

• Damaged or torn membrane, replace

• Compressor issue, see above

Jolie Products, Inc

Limited Warranty

This limited warranty is against any mechanical or material defects

for a period of (see below) from the date of purchase. Warranty only

covers properly installed and maintained units.

Compressors carry a two year warranty - covered by manufac-

turer’s warranty (consult owners manual for full details).

Air diusers have a ve year warranty.

Weighted tubing has a ve year warranty.

The limited warranty does not cover normal wear and tear, nor any

deterioration suered through overloading, improper use, negligence

or accident. Similarly, any modication made by the purchaser to the

product will cause the warranty to be null and void.

All returned items will be inspected to determine cause of failure

before warranty is approved.

Warranty does not cover any cost associated with the installation or

removal of the product subject to warranty claim.

An RA number must be obtained by calling EasyPro Pond Products

at 800-448-3873. It is your responsibility to pay the return shipping

charges. Be sure to include the RA number, original receipt (in the

form of an invoice or sales receipt), name, return address and phone

number inside of the package. No warranty claims will be honored

without the original receipt.

Ensure the product is properly packaged and insured for the re-

placement value. Damage due to improper packaging is the respon-

sibility of the sender.

The manufacturer or supplier shall not be held liable for any dam-

ages caused by defective components or materials of this product;

or for loss incurred because of the interruption of service; or any

consequential/incidental damages and expenses arising from the

production, sale, use or misuse of this product.

The manufacturer or supplier shall not be held liable for any loss of

sh, plants or any other livestock as a result of any failure or defect

of this product.

Jolie Products, Inc

Boost the Benets of Aeration

EasyPro’s benecial bacteria treatments are proven to work

in conjunction with aeration systems to improve the natural

biological balance and overall water quality. The bacteria

work along the pond bottom, breaking down organic matter

such as leaves, grass clippings, dead algae and sh waste.

(800) 448-3873 • Grant, Michigan • easypropondproducts.com

4-14

EasyPro bacteria

treatments are

Made in the USA.

“Safe for sh, pets,

wildlife and family!”

Base Kit Part #

Compressor Serial #

Please keep a copy for your records

EasyPro Pond-Vive

The natural, biological way to revive your pond

This special blend of benecial bacteria is designed to:

• Reduce oxygen demand and sludge buildup

• Eliminate excess nutrients and pond odors

• Improve water clarity

Available in 10 lb. and 25 lb. pails with 8 oz. water soluble packs

or as loose powder in bulk 100 lb. drums.

EasyPro Sludge Remover Pellets

Bacteria specically designed to reduce sludge on the

pond bottom

• Great for spot treating around docks and beach areas

• Available in 10 lb. and 25 lb. pails, one ounce of pellets

covers approximately 200-250 square feet of shoreline or

beach area

EasyPro Lake Colorant

Add EasyPro Lake Colorant to give your pond a beautiful look

• Available in blue or black one quart containers

• Nontoxic and compatible with most aquatic herbicides, wa-

ter can be used for swimming and irrigation once dispersed

• Concentrated formula, one quart treats one acre of

water 3' - 6' deep

Jolie Products, Inc

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere EasyPro Teichpumpe Handbücher

EasyPro

EasyPro EX11000 Handbuch

EasyPro

EasyPro EX8800 Handbuch

EasyPro

EasyPro Rocking Piston PA86A Betriebsanleitung

EasyPro

EasyPro Eco-Clear EPS1300 Gebrauchs- und Pflegehandbuch

EasyPro

EasyPro EX6750-2 Handbuch

EasyPro

EasyPro EX8500 Handbuch

EasyPro

EasyPro Spirit TLS1850 Bedienungs- und Wartungshandbuch

EasyPro

EasyPro TH Series Gebrauchs- und Pflegehandbuch

EasyPro

EasyPro PA34 Betriebsanleitung

EasyPro

EasyPro UWD16C Montageanleitung

EasyPro

EasyPro ETP05 Gebrauchs- und Pflegehandbuch

EasyPro

EasyPro LA5N Gebrauchs- und Pflegehandbuch

EasyPro

EasyPro Mag Drive Gebrauchs- und Pflegehandbuch

Beliebte Teichpumpe Handbücher anderer Marken

Oase

Oase PondJet Eco Bedienungsanleitung

Profi-pumpe

Profi-pumpe Rügen Bedienungsanleitung

HEISSNER

HEISSNER F540-00 Bedienungsanleitung

1A Profi Handels

1A Profi Handels OASIS 501R-1 Bedienungsanleitung

Biotop Garden

Biotop Garden D0060 Bedienungsanleitung

Profi-pumpe

Profi-pumpe JR-800LV Bedienungsanleitung

Sealey

Sealey WPP1100 Bedienungsanleitung

Pontec

Pontec PondoMax Eco 1500 Bedienungsanleitung

TIP

TIP WP 500-10 R Bedienungsanleitung

esotec

esotec Siena LED Bedienungsanleitung

Danner

Danner Pondmaster 1250 Bedienungsanleitung

Pond Boss

Pond Boss 52354 Bedienungsanleitung

TeichTip

TeichTip Sunsun Bio Pond Filter Set Bedienungsanleitung

Hozelock Cyprio

Hozelock Cyprio Cascade 5500 Bedienungsanleitung

Hozelock Cyprio

Hozelock Cyprio Aquaforce Series Bedienungsanleitung

HEISSNER

HEISSNER SPF 150-00 Bedienungsanleitung

AquaScape

AquaScape AQUAFORCE 4000-8000 Gebrauchsanweisung

Messner

Messner system-X 1501 Bedienungsanleitung
