EAW SB730P Handbuch

.78 X 82°

.78 .06

10X .40 THRU ALL

3.293

4.563

6.293

3.107

6.105

1.316 1.75

2X .25

2X .18 .06

.737 C

L

C

L

NOTES:

1. MATERIAL: ALUMINUM 6061-T6 .50 THICK.

2. COATING: DUPONT EFB-504-SO RAVEN BLACK POWDERCOAT, SHERWIN WILLIAMS POWDURA

EPOXY POWDER OR MORTON 10-7068 VISTA BLACK.

3. REMOVE BURRS AND BREAK SHARP EDGES.

4. PARTS TO BE CLEAN AND FREE OF GREASE AND DEBRIS.

5. EAW PART NUMBER AND CURRENT EAW REVISION TO BE STAMPED, LABELED, OR PERMANENTLY

MARKED WHERE SHOWN IN A CONTRASTING COLOR. LETTERS TO BE 1/8" TALL MINIMUM.

6. REFER TO EAW MATERIAL SPECIFICATION 480455 FOR LABELING AND SHIPPING REQUIREMENTS.

7. FABRICATOR REQUIRED TO SHIP CERTIFICATION OF MATERIALS WITH EACH LOT SHIPPED.

.50

2.75

SEE

NOTE 5

4X R .25

8.00

D

C

B

A

A

B

C

D

1

23

4

5

678

8765432 1

REVISIONS

REV DESCRIPTION APPR / DATE

SOLID WORKS

REV

DWG. NO.

TITLE:

APPROVALS ONE MAIN STREET WHITINSVILLE, MA 01588 USA

SCALE: 1:2SHEET 1 OF 1

B

EASTERN ACOUSTIC WORKS

DATE

STATUS

DRAWN:

MFG ENG:

DES ENG:

CHECKED:

UNLESS OTHERWISE SPECIFIED:

ALL DIMENSIONS ARE IN INCHES

TOLERANCE IN INCHES

.X .030 .XX .010 .XXX .005

FRACTIONS 1/32

ANGLES 1/2

(X.XX) = REF DIMS NO TOLERANCE IMPLIED

TSC = THEORETICAL SHARP CORNER

DIMENSIONS ACROSS CENTERLINES

TO BE SYMETRICAL

THIRD ANGLE PROJECTION

THIS DRAWING IS THE PROPERTY

OF EAW AND SHALL NOT BE COPIED,

REPRODUCED, OR USED AS THE

BASIS FOR MANUFACTURE OR SALE

OF APPARATUS WITHOU WRITTEN

AUTHORIZATION.

DO NOT SCALE DRAWING.

0006419 (A) BRACKET SPLAY 0° & 6° SB730P

ARELEASED TO PRODUCTION STATUS FROM

REV 5 WITH NO CHANGES.

PER DSRWHT4476 MFL 2/17/04

PRODUCTION

M. LEBLANC 7/29/03 BRACKET/SPLAY/0 & 6 DEGREE/

SB730P

0006419 A

RS 2-17-04

RS 2/17/04

2/17/04

2/18/04

TSD

MD
