Q8 Barcode Label Printer
User’s Manual
Q8 User’s Manual
FCC Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment may generate, use and/or radiate radio frequency energy. If
not installed and used in full accordance with this User’s Manual,
interference to radio communications may occur. This equipment complies
with the limits for a Class A Information Technology Equipment pursuant to
Part 15 of the FCC Rules, which are designed to provide reasonable
protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area may also
cause interference. In such case the user, at his/her expense, will be required
to correct the interference using whatever means necessary.
Trademarks
EC Printer is a registered trademark by EC Electronics Limited.
Microsoft, Windows are registered trademarks by Microsoft Corporation.
Copyright
© 2011 by EC Electronics Limited. All rights reserved. Under the copyright laws,
this manual cannot be reproduced in any form without the prior written permission of
EC Printer No patent liability is assumed with respect to the use of the information
contained herein.
EC Printer Q8 Barcode Label Printer User’s Manual
1st edition Jan. 2012
i
Q8 User’s Manual
Disclaimer
This manual has been validated and reviewed for accuracy. The instructions and
descriptions it contains are accurate for the EC Printer Q8 Label Printer at the time of
this manual’s printing. However, succeeding printers and manuals are subject to
change without notice. EC Printer assumes no liability for damages incurred directly
or indirectly from errors, omissions or discrepancies between the printer and this
manual.
Although this manual describes and details many issues, which could possibly occur,
the manufacturer cannot warrant against unpredictable conditions during the printing
process. For problems such as the printer not working, lost or unclear print content,
etc., the manufacturer and resellers are responsible for correcting these issues
(according to EC Printer Printer Warranty Clauses). In no event shall the
manufacturer or the resellers involved be liable for any damages whatsoever
including without limitation; damages for loss of business profits, business
interruption, loss of business information, or other pecuniary loss arising from the use
of this product.
ii
Q8 User’s Manual
Important Safety Instructions
Only qualified and trained authorized EC PRINTER service providers should
attempt to disassemble or repair the printer. Incorrect disassembling of the
product or its power adaptor may cause an electronic short, human injury or
printer component damages.
Do not use a worn or damaged power cord as it could result in electric shock
and personal injury. If the power cord becomes damaged or frayed, replace it
immediately.
Be sure that the output of the power adapter is 24VDC and your power source
matches the rating listed on the power adapter. Ensure the power source is
grounded.
Do not insert anything into the ventilation slots or openings on the printer.
The printer and power adapter should never be operated in a location where
either one can get wet. Personal injury may result.
The Printhead becomes hot while printing. To protect from damaging the
Printhead and risk of personal injury, avoid touching it.
To obtain increased Printhead longevity and higher quality output, always use
quality labels, tags and thermal transfer ribbons. Check for quality supplies with
a EC PRINTER reseller.
Static electricity that accumulates on the surface of the human body or other
surfaces can damage or destroy the Printhead or electronic components in this
device. DO NOT touch the Printhead or the electronic components with bare
hands.
Place the printer on a flat, firm, solid surface.
Warnings:
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures (see
FCC Notice).
Static electricity that accumulates on the surface of the human body or other objects
can damage the print head or electronic components in the V6 printer. Observe
proper electrostatic safety precautions when handling.
Power off the printer when not in use for extended periods of time.
Never operate in a high temperature environment.
Follow all recommendations and setup instructions included in this manual.
iii
Q8 User’s Manual
iv
Contents
Preface....................................................................................................................... 1
Important Notice, Read Me First!........................................................................... 1
Chapter 1 Introduction............................................................................................. 2
Specifications...................................................................................................... 2
Specifications for Printer .................................................................................... 2
Specifications for Power Adapter............................................................. 3
Contents of Box........................................................................................ 3
Packing List.............................................................................................. 3
Chapter 2 Setup and Use.......................................................................................... 5
Setting up............................................................................................................ 5
Main Parts and Structures ................................................................................... 5
Connecting the Printer ........................................................................................ 8
Interface Connection ................................................................................ 8
Loading the Ribbon ............................................................................................ 9
Loading the Media.............................................................................................13
Standard Mode ........................................................................................13
Peel-off Mode..........................................................................................17
Cutting Mode ..........................................................................................20
Adjusting the Position of Media Sensor.............................................................21
Chapter 3: Operations and Settings.......................................................................25
Basic Operations .....................................................................................25
Power Switch ..........................................................................................25
The Front Panel.......................................................................................25
Indicator Lamps ......................................................................................25
Advanced Operations ..............................................................................26
DIP Switch Panel.....................................................................................28
Windows Driver and Bartender-Postek Software ..............................................29
Chapter 4: Maintenance..........................................................................................30
Cleaning the Printhead.......................................................................................30
Cleaning the Platen Roller .................................................................................31
Cleaning the Printer Interior ..............................................................................31
Chapter 5: Troubleshooting....................................................................................32
Error Indicators..................................................................................................32
Miscellaneous ....................................................................................................34
AppendixA: IO Interface Specifications...............................................................36
Appendix B: ASCII Table........................................................................................38
Preface/ImportantNotice Q8SeriesUser’sManual
Preface
Your EC PRINTER Q8 barcode label printer provides many outstanding
features to enjoy. The EC PRINTER Q8 is compact, versatile, and easy
to use. It supports both direct thermal and thermal transfer printing
methods, and employs an unparalleled print engine that reduces noise
and enhances durability.
This manual explains how to set up and begin using your EC PRINTER
Q8 printer. It also provides detailed information on configuring your Q8
printer, basic operations, maintenance and troubleshooting.
Please read this manual carefully and completely before using the EC
PRINTER Q8 printer.
1
Q8User’sManual ImportantNotice,ReadMeFirst!
1
Important Notice, Read Me First!
A thermal Printhead can be easily damaged due to its precision
construction. A Printhead damaged due to misuse is not covered under
the terms of the warranty. To ensure longevity of the Printhead, please
note the following:
DO NOT scrape, or use tools that might damage the Printhead
surface.
To protect from corroding the Printhead, DO NOT touch the
Printhead with bare hands.
DO NOT use thermal paper or thermal transfer ribbon, which
contains Na, K or Cl.
Keep Printhead away from any liquid or dampness.
Use a cotton swab dipped in anhydrous isopropyl alcohol to clean
the Printhead only.
Always use high-quality consumables:
-When the Printhead module is closed, pressure is placed
directly onto the Printhead; dirt such as paper scraps, sand, dust
and glue can scrape or damage the Printhead.
-The Printhead is also easily damaged by static electricity,
which may be generated by poor quality ribbons. Always
inspect consumables for quality before purchasing.
Q8 User’s Manual Chapter 1 Introduction
Chapter 1 Introduction
Specifications
Specifications for Printer
Mode Q8/200 Q8/300
Printing method Direct Thermal & Thermal transfer
Printing
resolution 203 dpi (8 dots/mm) 300 dpi (11.8 dots/mm)
Max printing
speed 4 ips (101.6 mm/s) 3 ips (76.2 mm/s)
Max printing
width 4.25″(108 mm) 4.17″(106 mm)
Max printing
length 157″(4000 mm) 79” (2000 mm)
Memory 2 MB FLASH ROM, 8 MB SDRAM
Media
Roll-feed, die-cut, continuous, tags, tickets in plain paper or
thermal paper
Width：4.33” (110 mm) max., 98“ (25 mm) min.
Supply roll: OD 5″(127 mm) max., ID 1″(25.4 mm) min.
Thickness: 0.003″～0.006″(0.08～0.15 mm), including liner
Ribbon
Wax, Wax/Resin, Resin
Ribbon roll: OD 1.5″(38 mm) max., ID 0.5″(12.7 mm)
core
Max width: 4.3” (110 mm); Max length: 360’ (110 M)
Fonts Five built-in ASCII fonts; Optional multiple language fonts
Bar Code Types
1D Barcode : Code 39, Code 93, Code 128/subset A,B,C,
Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on,
EAN-13/8/128, UCC-128, etc.
2D Barcode : MaxiCode, PDF417, Data matrix, etc.
Media sensor Reflective
Interfaces
R
S-232 Serial, USB
2
Chapter 1 Introduction Q8 User’s Manual
Power rating 24 VDC Power adapter
Weight 2.1 kgs
Dimensions W 8.3” (210 mm) x D 10” (255 mm) x H 5.9” (150 mm)
Operation
environment
Temperature: 32F ~ +104F (0C ~ 40C)
Relative humidity: 5% - 85% non condensing
Storage
environment
Temperature: -40F ~ +140F (-40C ~ 60C)
Relative humidity: 5% - 85% non condensing
Optional items Guillotine Cutter, Peeler Kit
Specifications for PowerAdapter
Input AC 100 ~ 240 V, 47 ~ 63 Hz
Output DC 24V, 2.5 A
Environment 32F ~ 104F (0C ~ 40C)
Contents of Box
Inspect the shipping carton(s) for possible shipping damage, if damage is discovered,
notify the shipping company to report the nature and extent of the damage.
Please check the items according to the Packing List. If there are any items missing,
notify your authorized reseller.
Packing List
1 Q8 Printer 1 pc
2 Quick Start Guide 1 pc
3 Power Adapter 1 pc
4 USB interface cable 1 pc
5 Media Spindle 1 pc
6 Media Roll Guides 2 pc
7 Warranty card 1 pc
8 CD-ROM pack 1 pc
9 Sample Media 1 pc
10 Sample Ribbon 1 pc
Note: CD-ROM pack includes the Q8 printer driver, Bartender-Postek software, Q8
User’s Guide and the Programming Manual.
3
Q8 User’s Manual Chapter 1 Introduction
Power Adapter
Printe
r
Ribbon
Media
Sample Media
4
CD-Rom Media Roll Guide
Quick Start Guide
Figure 1: Printer and Accessories
