Ecologic Mart Book Light Bedienungsanleitung

https://ecologicmart.com Page 1

BOOK LIGHT –MUSIC STAND LIGHT

USER’S MANUAL

Version 4.0 September 2018.

https://ecologicmart.com Page 2

Table of Contents

Introduction.......................................................................................................................................................................3

How to Use the lamp.....................................................................................................................................................4

Charging Process........................................................................................................................................................4

Turning On and Light Intensity .............................................................................................................................4

Choose Color Temperature ....................................................................................................................................5

Ways of Use..................................................................................................................................................................5

Battery Management.....................................................................................................................................................6

Low Battery Alarm......................................................................................................................................................6

Check the Status of the Battery Charge.............................................................................................................6

Recommendations.....................................................................................................................................................6

When the Battery Dies ..................................................................................................................................................7

Replace the battery....................................................................................................................................................7

Use the lamp without battery................................................................................................................................7

Luminosity and Battery Life.........................................................................................................................................8

Luminosity.....................................................................................................................................................................8

Battery Lasting.............................................................................................................................................................9

Technical Specifications............................................................................................................................................. 10

Troubleshooting........................................................................................................................................................... 10

LAMP DOES NOT TURN ON................................................................................................................................ 10

LIGHT TOO DIM ....................................................................................................................................................... 10

Warnings ......................................................................................................................................................................... 11

EYES .............................................................................................................................................................................. 11

WATER ......................................................................................................................................................................... 11

HEAT............................................................................................................................................................................. 11

GARBAGE.................................................................................................................................................................... 11

REUSE........................................................................................................................................................................... 11

STORAGE .................................................................................................................................................................... 11

Gratefulness ................................................................................................................................................................... 12

Other Products from Ecologic Mart...................................................................................................................... 13

https://ecologicmart.com Page 3

Introduction

First of all, THANK YOU for your purchase, we want to have an excellent relationship

with you and we have started putting all our love in the development of a durable and

useful product.

In this manual you will find answers to most of the questions that normally arise,

however, if you can not satisfy your need you can write to [email protected],

we are always ready to serve you.

https://ecologicmart.com Page 4

How to Use the lamp

For an adequate use of the lamp we will show different parts of the process such as

charging, use and care.

Charging Process

The battery may arrive empty; it is recommended that you make a full charge before the

first use.

The charging process is done as follows:

1. Connect the USB cable to the AC adapter or another

5V USB source (radio, USB port, solar charger, power

bank).

2. Connect the micro USB connector to the base of the

lamp (the connector does not enter 100%, do not

worry).

3. The charging process is shown by the blue indicators.

4. 1 flashing LED indicates that the load is between 0

and 25%.

5. 1 stable LED and the second flashing indicates that

the load is between 25 and 50%.

6. 2 stable LEDs and the third flashing indicates that the load is between 50 and

75%.

7. 3 stable LEDs and the fourth flashing indicates that the load is between 75 and

100%.

8. 4 stable LEDs indicate that the charge is complete.

IF YOU ARE USING THE LAMP WHILE CHARGING AND FLICKER BOTHERS YOU,YOU CAN TURN OFF

THE INDICATORS BY PRESSING THE SIDE SWITCH.

Turning On and Light Intensity

Each head has a separate switch, so you can have different light levels and light colors in

each one.

https://ecologicmart.com Page 5

To turn on the light and change the intensity press the

switch, you will see how it goes from one light level to

another. The states you will find are: Low, Medium, High and

Off.

Choose Color Temperature

This model of lamp includes three types of light that are

given when using different LEDs; You can choose between

warm, natural or cool light.

To change the light color you must:

a. Switch on the lamp (press the switch).

b. Then press the switch and hold it for 3 seconds, you will see that the color

changes.

c. Repeat the previous step until you get comfortable with the color that you

like the most.

THE COLOR YOU SELECT WILL BE REGISTERED IN THE MEMORY FOR THE NEXT TIME YOU USE THE

LAMP.

Ways of Use.

There are three ways to use your lamp:

a. Place it on the desk or night table

supported on its base.

b. Holding the book, stand or headboard. Use

the clip that opens up to 1 1/2 inches.

c. Hang it from a hook, screw or lace using

the hole in the base of the lamp.

https://ecologicmart.com Page 6

Battery Management

Low Battery Alarm

When the battery is nearly exhausted the first blue

LED will flash to remind you to connect the lamp.

Check the Status of the Battery Charge

At any time you can know how much charge the

battery has, to do this press the side switch, the blue

LEDs will show like this:

•1 LED on: Charge between 0 and 25%.

•2 LEDs on: Charge between 25 and

50%.

•3 LEDs on: Charge between 50 and

75%.

•4 LEDs on: Charge between 75 and 100%.

•After 5 seconds they will automatically turn off.

Recommendations

•When Charging: Lithium ion chemistry prefers partial discharge to deep

discharge, so it's best to avoid taking the battery all the way down to zero.

Since lithium-ion chemistry does not have a "memory", you do not harm

the battery with a partial discharge. In other words, you can connect

whenever you want without having to wait until it is drained out.

•Avoid heat, which degrades the batteries.

•Dispose properly (please visit www.call2recycle.org).

•Lithium batteries are ruined if stored for a long period of time without

charge. Try to keep the battery with at least 50% of the charge, if you stop

using the lamp for a few months the battery can retain its integrity much

better.

https://ecologicmart.com Page 7

When the Battery Dies

All Lithium batteries die at any time, the average duration time is 3 years or 1,000 charge

and discharge cycles.

Our lamp is ready for this event and offers you two ways to continue enjoying

your light.

Replace the battery

1. Buy a battery type 103040

with Micro JST 1.25mm 2-

Pin male connector. You

do not need tools, the

battery compartment will

be easily opened.

2. Gently remove the current

battery by pulling on the

cable.

3. Gently insert the battery connector into the receiver at the base, it is important

that the red wire is on the left or, the same, the pins are facing up. (please look at

the image)

Use the lamp without battery

If it is difficult or very expensive to find a new battery, we have included a cable of 2

meters long that allows you to read comfortably while the lamp is connected to a USB

port.

https://ecologicmart.com Page 8

Luminosity and Battery Life

Luminosity

SINGLE ARM LAMP (Lumens)

LEVEL/COLOR

COOL

WARM

NATURAL

HIGH

38.4

28.8

67.2

MEDIUM

19.2

14.4

33.6

LOW

3.84

2.88

6.72

Maximum 67 Lm (high level natural light)

Minimum 2.8 Lm (low level warm light)

DOUBLE ARM LAMP USING BOTH* ARMS AT

THE SAME LEVEL (Lumens)

LEVEL/COLOR

COOL

WARM

NATURAL

HIGH

19.2

57.6

MEDIUM

9.6

28.8

LOW

1.92

5.76

*NOTE THAT IF YOU USE A SINGLE ARM OF

THE TWO-ARM LAMP YOU WILL HAVE HALF

THE BRIGHTNESS.

Maximum 96 Lm (2 arms on high level natural

light)

Minimum 0.96 Lm (1 arms on low level cool

light)

https://ecologicmart.com Page 9

Battery Lasting

SINGLE ARM LAMP (Hours)

LEVEL/COLOR

COOL

WARM

NATURAL

HIGH

6.53

8.71

3.73

MEDIUM

13.06

17.41

7.46

LOW

65.29

87.06

37.31

Maximum 87 hours (low level warm light)

Minimum 3.73 hours (high level natural light)

DOUBLE ARM LAMP USING BOTH* ARMS AT

THE SAME LEVEL (Hours)

LEVEL/COLOR

COOL

WARM

NATURAL

HIGH

6.53

4.35

2.61

MEDIUM

13.06

8.71

5.22

LOW

65.29

43.53

26.12

*NOTE THAT IF YOU USE A SINGLE ARM OF

THE TWO-ARM LAMP YOU WILL HAVE TWICE

THE BATTERY LIFE.

Maximum 130 hours (1 arm on low level cool

light)

Minimum 2.61 hours (2 arms on high level

natural light)

https://ecologicmart.com Page 10

Technical Specifications

•Battery Type: Li-Ion 1200mAh 103040 JST 2-Pin Male Connector 1.25mm.

•Battery Size: 4*3*1cm

•Single arm lamp has 7 LEDs (3 yellow and 4 white)

•Double arm lamp has 10 LEDs (6 yellow and 4 white)

•Charging Sources:

•Included adapter 1.0A Slot

•Adapters manufactured by other brands from 250mA –5VDC

•Standard USB outputs from equipment such as laptops, car stereos, power banks,

solar chargers and other devices.

•Weight :

•DOUBLE ARM Lamp + Accessories Weight: 4.9 oz = 137 gr.

•SINGLE ARM Lamp + Accessories Weight: 4.4 oz = 125.6gr

•Arm’s Length: 9 inches

•Clip Effective Maximum Aperture: 1 ½ Inches

•UL Listed Adapter:

•Input AC 100-240v 50/60Hz 0.5A - Output DC 5V –1000mA

•USB Cable: USB Male to Micro USB Male 78 Inches = 2 Meters Long.

Troubleshooting

LAMP DOES NOT TURN ON

•The first is to try charging, when the battery is receiving charge, the

charging indicators must show progress like was explained before.

•If the indicators do not show the progress but the lamp works when it is

connected by cable, then the battery no longer works.

•On the contrary, if the lamp does not work when it is connected, then the

problem is in the cable or the adapter, it will be necessary to try charging

using another cable and / or another charger.

LIGHT TOO DIM

Please connect the lamp to allow battery charge, keep in mind that the battery does not

last forever, it is possible that life is ended and you have to replace it.

In any case, we are here to help; please send e-mail to amazon@ecologicmart.com

referring the order number of your purchase.
