EcoQuest Ecobox Bedienungsanleitung

Think Outside. Inside.

user guide

welcome

Congratulations on your new ecobox.

Your ecobox comes with a detachable power cord (US71059) and remote control

(US71058).

________________________________________ ________________________________________

EcoQuest Business Owner Name Phone Number

rear coverfront grill

control pad

side grills

power in

carry handle

introduction

Meet your ecobox!

up to 1500 square feet of coverage

6.5” high x 6.5” wide x 7” deep weighs 2 pounds 32

placement

Where to put your ecobox?

For best results, place your ecobox as high

up as possible, with at least 2 inches of

clearance on either side.

You can also place your ecobox in trouble

areas for extra effectiveness.

caution

Do not operate ecobox near heat sources, open ﬂame, or combustible vapors or gases. 5

power supply

15 volts DC 20 watts power consumption

30 watts power consumption (away mode) 3-speed fan

Plug power supply into the back of the ecobox and into a standard wall outlet.

led information

Green LED solid = normal mode

Green LED blinking = bulb absence/failure

Green LED ﬂash = remote or keypad command received

Red LED solid = away mode (returns to normal mode after 2 hrs or user input

is detected, whichever comes ﬁrst)

Red LED blinking = supply voltage is greater than 18VDC or less than 12VDC

Green & Red LED

control pad

The control pad is conveniently located on the right side of your ecobox.

on/off power

+ fan speed

- fan speed

away mode

caution

Away Mode is intended for unoccupied spaces only. Please be sure all people and pets have vacated

the area when Away Mode is in use.

Operating your ecobox.

remote control

The ecobox remote control gives you the convenience of control from anywhere

in the room. Before use, remove paper tab from the bottom of the remote. When

replacing battery, choose a 3 Volt lithium cell CR2025.

on/off power

away mode

+ fan speed

- fan speed

puriﬁer plate

US71061

power cord

US71059

RCI cell

US71060

remote control

US71058

parts

Replacement parts.

If your unit fails to operate properly or you have questions, contact your EcoQuest

Business Owner for further assistance. Contact EcoQuest at:

EcoQuest International, 310 T. Elmer Cox Drive, Greeneville, TN 37743

800.989.2299 or visit www.EcoQuest.com for additional support. 98

side grills

US71070

every month every year every 3 years part numbers

clean front grill

clean side grills

clean puriﬁer plate

replace RCI cell US71060

replace puriﬁer plate US71061

maintenance

Caring for your ecobox.

caution

Always unplug the power cord from the back of your ecobox before servicing. Removing cover may

expose ultraviolet light source. To protect against eye damage, always unplug before servicing.

upkeep

Periodically, vacuum the grills or

wipe the front grill with a soft towel.

You can wash the two side grills in

warm water and let dry completely

before reinstalling (replace if

necessary). Wipe down the outside

with a damp (not wet) cloth.

Reassemble when ﬁnished.

1110
