EDIFIER X500 Bedienungsanleitung

X500

User's Manual

Multimedia Speaker

Made in China

Edifier Enterprises Canada Inc.

1 Sub Woofer 2 Volume Control

3 Bass Control

5 Power Indicator 6 Speaker Out

7 Power Switch 8 Satellite Speakers

9 User's Manual 10

4 Line In Port

Audio connecting cord

Overview

1

Welcome !

Very thanks for choosing Edifier multimedia speaker,it can

provide good sound for multimedia computer and home theater.

Before operating the system, please read this manual thoroughly

and retain it for future reference.

Overview

Operating

2

Operating

1

2

3 Playing the audio device

CONNECTING

Connect the satellite speakers to the output RCA on the

back panel of the Sub-woofer. Please note to match the color,

red to red and white to white.

Connect the subwoofer to theAudio device.

Using Audio connecting cord , connect the Line-input port

of the subwoofer to Line-out of the Audio Device (Such as the

computer, Discman, etc).

Plug the AC power plug into the wall outlet and turn on the

power switch, Now your speaker system is ready for Use.

Adjusting the volume control and Bass control , then you can

enjoy the music.

Total Power Output : RMS 6W x 2 + 12W(THD=10%)

Input Impedance: 10K Ohm

Input Sensitive: 450 mV

Bass Unit: 7" Aluminum coil, 4 Ohm

M 3" Paper coil, 4 Ohm

Tweeter Unit: 1"

Dimension(Subwoofer): 241(W) x 229(H) x 279(D)mm

Dimension(Satellite): 91(W) x 183(H) x141(D)mm

Gross Weight: About 6.9 Kg

id-range Unit:

PV membrane dome

SPECIFICATIONS

Notice

Edifier assumes noresponsibility for anyerrors that mayappear

in this manual.Information contained hereinis subject tochange

without notice.

Notice

Edifier and Edifier logo are owned by Edifier Enterprises Canada Inc.

and may be registered. And other brand names and trademarks are

the property of their owners.

WARNING

Toreduce the risk of electric shock ,Do not expose this apparatus

to rain or moisture.

Copyright 2005

All Rights Reserved.

Manual Edition 1.1,Jun. 2005

Printed in CHINA
