Elan VSOS Bedienungsanleitung

100 WATT HIGH POWER STEREO

VOLUME CONTROL w/OVERRIDE

VMOS

100 WATT HIGH POWER MONO

VOLUME CONTROL w/OVERRIDE

VSOS

This ELAN Volume Control is NTRL certiﬁed to comply

with local building codes. Use Class 2 wiring and methods

per National Electrical Code NFPA70. Install in a Listed

electrical box.

ELAN HOME SYSTEMS INSTALLATION MANUAL

Contents

Introduction .......................................2

Features ..............................................2

Rough-In ............................................3

Wiring ..................................................4

VSOS ...................................................5

VMOS ..................................................5

Impedance Match Settings ................6

Impedance Match Switches ...................7

Page & Doorbell Level Adjustment ....8

Installation .........................................9

Operation ..........................................11

Troubleshooting ................................12

Speciﬁcations ...................................13

Warranty ..............................Back Page

ELAN HOME SYSTEMS

INSTALLATION MANUAL

Introduction

The ELAN VSOS High Power Stereo Volume Control w/

Override is a twelve-step stereo Volume Control with Variable

Impedance Match settings. The VMOS is a High Power mono

Volume control w/ Override conforming to the same speciﬁca-

tions (except stereo capability). This Volume Control is designed

to connect speakers to ampliﬁers with power ratings up to 100

Watts RMS. Based on proven technology, the VSOS/VMOS

provides a perfect solution when using multiple speakers in high

powered multi-room applications or when basic volume func-

tions are needed with a receiver or ampliﬁer.

Features

• High Power 100 Watts RMS Per Channel

• 1X/2X/4X/8X VSOS

• 2X/4X/8X/16X VMOS

• ELAN’s Patented Volume Control Override

• Limited Lifetime Warranty

• Twelve-Position Volume Steps

• Decora®Styling

• ELAN Quality

• PTC-Thermal Protection Circuit: When the PTC detects

problems such as, too much power crossed speaker wiring, or

improper impedance, the circuit will open, protecting the volume

control. When the problem has been corrected, the circuit will

close and resume operation.

ELAN HOME SYSTEMS INSTALLATION MANUAL

Rough-In

The VSOS/VMOS will ﬁt into the majority of single-gang boxes.

This Volume Control should not be mounted in the same rough-

in box as primary or mains volt devices, i.e. 110v, 240v--this can

cause undesirable noise in the speakers. High-wattage light

dimmers can also cause noise issues.

ALWAYS CHECK LOCAL BUILDING AND

FIRE CODES FOR LOW-VOLTAGE

DEVICE INSTALLATION AND WIRING

REQUIREMENTS.

IN RETROFIT APPLICATIONS, ALWAYS

CHECK FOR OBSTRUCTIONS SUCH AS

PIPES, CONDUIT, OR ELECTRICAL WIR-

ING BEFORE CUTTING DRYWALL.

ELAN HOME SYSTEMS

INSTALLATION MANUAL

Wiring

Wiring for the VSOS/VMOS consists of speaker wire and CAT5

(if using an ELAN Communications device such as a COM2 or

MAC24). The VSOS/VMOS can accommodate from 14 to 24

gauge speaker wire. Typical installations will use 16 or 18 gauge

stranded copper wire, while longer runs (greater than 80 feet)

should use 14 gauge wires. CAT5 cable should be used for

systems using ELAN’s Volume Control Override features. In-wall

runs should utilize twisted pair wiring. Please consult local build-

ing codes before attempting in-wall wire runs.

DO NOT REVERSE THE AMPLIFIER IN-

PUT AND SPEAKER OUTPUT CONNEC-

TIONS! THIS CAN RESULT IN DAMAGE

TO EQUIPMENT AND/OR PROPERTY.

ELAN HOME SYSTEMS INSTALLATION MANUAL

Impedance

Match Switch

To Speakers

From

Amplifier

PG/DB

Level

Adjust

Volume Control

Override

L6L5L4L3L2L1

R1R2R3R4R5R6

IMPED SWITCH IMPED SWITCH

1X 2X 4X 8X 1X 2X 4X 8X

RIGHT

VCO

LEFT

VCO

R+ R- SPK L- L+ VC+ VC- R+ R- AMP L- L+

PG/DB

Level

Adjust

Impedance

Match Switch

From

Amplifier

Volume Control

Override

Impedance

Match Switch

To Speaker

PG/DB

Level

Adjust

2X4X8X16X

1 2 3 4 5 6

OVERRIDE

VOLUME

VC+ VC- +AMP- -SPKR+

VSOS

VMOS

ELAN HOME SYSTEMS

INSTALLATION MANUAL

Impedance Match Settings

Switch settings on the VSOS/VMOS determine the Impedance

Match settings. See diagram for position of Override Jumpers.

Switch position depends on three things:

1. The minimum impedance rating of the amplifier being

used.

2. The number of speakers being connected to the

amplifier channel.

3. The nominal impedance of the speakers being utilized.

Once the above information has been determined, use the fol-

lowing equations to determine the correct Impedance Match set-

ting for each speciﬁc application. Two equations are necessary:

Impedance Rating of Speakers

# of Speakers Connected to Amp Channel

Minimum Impedance Rating of Amp

System Impedance

= System

Impedance

= Impedance Match

Switch Setting

8 Ohm Speaker

4 Speakers = 2 Ohm System Impedance

8 Ohm Stable Amp

2 Ohm System Impedance = 4 X Switch

ELAN HOME SYSTEMS INSTALLATION MANUAL

Impedance Match Switches

Most speakers are rated at 4, 6, or 8 ohms. If connecting

speakers of different impedances to an amplifier, an average

impedance must be determined; i.e. one pair of 4 ohm speakers

is the equivalent of 2 pair of 8 ohm speakers. All 6 ohm speak-

ers should be entered into the equation as 4 ohm speakers. All

volume controls connected to an amplifier channel should have

the same Impedance Match setting.

VMOS VSOS

Both Switches

MUST be in

Same Position

16X

Never create settings that cause the ampliﬁer to see an imped-

ance below its minimum impedance rating as this can cause

damage to the ampliﬁer.

ELAN HOME SYSTEMS

INSTALLATION MANUAL

Page & Doorbell Level Adjustment

When utilizing ELAN’s Page and Doorbell features, it will be

necessary to adjust the Page & Doorbell Volume level. Locate

the Page & Doorbell Volume jumpers as shown on the diagram

below. Each jumper MUST be set to the same position or dam-

age to the unit could occur. Test the Page and Doorbell functions

and monitor the audio levels. Adjust shunts higher to increase

Page & Doorbell volume, adjust lower to reduce volume.

MAX

MIN

VMOS VSOS

MAX

MIN

MAX

MIN

Both Jumpers

MUST be in

Same Position
