Elecrow CrowView Bedienungsanleitung
FHD Mechanical Clamping Display
User Manual
★Compatible with 13”~16.5” laptop.
Copyright 2023 ELECROW All rights reserved.
Equipped with 14 inch FHD display
Lightweight and portable design.
Compatible with multiple devices or game consoles.
Supports use as a secondary display for 13~16.5 inch laptops.
Supports full-featured USB-C port signal input.
Compatible with HDMI.
For more information, please visit www.elecrow.com.
PRODUCT BRIEF
Meeting users' demand for an extension of the visual work-
space and improving work efficiency, CrowView, developed
by Elecrow, comes out after research and testing.
Part List
1
Parts Description
2
Buttons and Interfaces
3
Display Setting
4
Connection Method
5
Placement Method
6
PC Setting
7-8
Menu Button Functions
9
Menu Setting
10-12
13
Parameters
CONTENTS
1
Power Adapter (5V-2A)×1
Detachable Clip×1
Velcro Tie×2
USB-C to USB-C Cable×1
USB-A to USB-C Cable×1 HDMI to Mini HDMI Cable×1
PART LIST
User Manual×1
CrowView×1
Please do not use non-standard accessories to ensure safety and the product's lifespan.
Any damage or injury caused by the use of non-standard accessories is not covered by the warranty.
Thanks for purchasing Elecrow product.
Please check that the following items are complete when opening the box.
The
Detachable Clip
is installed on the product in advance.
The wireframe drawing is for reference only, please refer to the actual product in the box.
Product specifications or manuals are subject to change without notice.
2
PARTS DESCRIPTION
Lower Buckle
Clamp Clasp
Detachable Clip
Telescopic Snap①
①
②
②
③
③
④
④
The telescopic snap can flexibly adjust the clamping width.
To disassemble the clip, press the left and right buckles and pull out. When installing, make sure to
push it firmly into place.
The right clamp clasp needs to be turned up when in use and inward when not in use.
Attach the clip to the lower buckle to position the screen on the left side of the computer.
3
BUTTONS AND INTERFACES
Status Lamp description:
Green light: normal operating; Flashing red light: power on, no signal input; Solid red light: sleep mode.
Exit UpDown Menu
Support Feet
USB-C (Full-featured)
Headphone Jack
Status Lamp
Mini HDMI
The inward flipping angle should not be too small, otherwise it may cause damage.
Press the support feet button to extend and stabilize the foot, supporting the computer screen.
4
DISPLAY SETTING
Please take out the Elecrow product and unfold it.
Press the support feet button to extend and stabilize.
( For specific connection, please see the next page
"Connection Method".)
After assembly, please adjust the alignment of the screens on both sides.
Laptops larger than 8mm thick may cause clip damage.
01
03
04
02 Lift up the right clamp clasp, adjust the telescopic snap
to the appropriate size, and clip it onto the notebook.
Use a suitable cable to connect CrowView to your laptop.
5
CONNECTION METHOD
Suitable for PCs with Full-featured interface (USB 3.1)
Full-featured USB-C and computer
HDMI plus power supply mode connection
Suitable for computer equipment with HDMI interface or insufficient power
supply
6
PLACEMENT METHODPLACEMENT METHOD
Left clampingRight clamping
Place upright
Face-to-face
Place separately Storage status
It is recommended that CrowView clamp it on the right side of the computer, and the
support frame is used for better results.
7
WINDOWS
1. Enter the display settings ( > > > )
4. If the screen is inverted, click the screen,
find "Display Orientation" in "Zoom & Local",
and adjust it in the drop-down menu. To
enlarge the screen, adjust it from the drop-down
menu in the "Change the size of text, apps, etc."
option.
2. You can drag the screen to rearrange it alone.
Screen
12
Rearrange displays
Identifying Detection
Select one of the displays below to change its settings. Long press (or select) a monitor, and
then rearrange it by dragging.
Multi-Display
Copy these displays
Expand these displays
Display only on 1
Display only on 2
Connect to wireless display
Advanced Display Settings
PC SETTINGS
3. If you need to set different display modes for
multiple screens, please click 1/2 (click " "
at the bottom of the screen to recognize the
corresponding screen) After selecting the
corresponding monitor, go to the "Multi-display
Settings" menu to set accordingly. (Copy: same
screen display; Extension: Extended Display)
Identifying
