Service Manual

Alpha / Delta Series

Indoor Units Outdoor Units

Alpha 7 CON 7 (Alpha)

Delta 7 GCN 7

Alpha 9 GCN 9 (Alpha)

Delta 9 DF ONG3-9 B1

ONG3-9 B2

Alpha 12 GCN 12 (Alpha)

Delta 12 DF ONG3-12 B1

ONG3-12 B2

Alpha 17 ONG3-14 B1

Alpha 17 ONG3-17 (Alpha)

Delta 17 DF ONG3-17

Delta 24 OU7-24C

JULY 2008

REFRIGERANT COOLING ONLY

R410A HEAT PUMP

SM ALPHA 1-E.3 GB

CONTENT

LIST OF EFFECTIVE PAGES

SM ALPHA 1-E.3 GB

LIST OF EFFECTIVE PAGES

Note: Changes in the pages are indicated by a “Revision#” in the footer of each effected page

(when none indicates no changes in the relevant page). All pages in the following list represent

effected/ non effected pages divided by chapters.

Dates of issue for original and changed pages are:

Original ....... 0 ........ 10 December 2004

Total number of pages in this publication is 169 consisting of the following:

Page

No.

Revision

No. #

Page

No.

Revision

No. #

Page

No.

Revision

No. #

Title ....................... 3

A ........................... 3

i............................. 3

1-1 - 1-2 ................ 3

2-1 - 2-13 .............. 3

3-1 ........................ 3

4-1 - 4-6 ................ 3

5-1 - 5-40 .............. 3

6-1 - 6-8 ................ 3

7-1 ........................ 3

8-1 - 8-5 ................ 3

9-1 ........................ 3

10-1-10-4 .............. 3

11-1....................... 3

12-1-12-32 ............ 3

13-1-13-2 .............. 3

14-1-14-49 ............ 3

Appendix -A ...........3

• Zero in this column indicates an original page.

*Due to constant improvements please note that the data on this service manual can be modiﬁed with out notice.

**Photos are not contractual

CONTENT

TABLE OF CONTENTS

SM ALPHA 1-E.3 GB

Table of Contents

1. INTRODUCTION ...................................................................................................1-1

2. PRODUCT DATA SHEET......................................................................................2-1

3. RATING CONDITIONS..........................................................................................3-1

4. OUTLINE DIMENSIONS .......................................................................................4-1

5. PERFORMANCE DATA & PRESSURE CURVES ................................................5-1

6. SOUND LEVEL CHARACTERISTICS ..................................................................6-1

7. ELECTRICAL DATA..............................................................................................7-1

8. WIRING DIAGRAMS .............................................................................................8-1

9. ELECTRICAL CONNECTIONS.............................................................................9-1

10. REFRIGERATION DIAGRAMS.............................................................................10-1

11. TUBING CONNECTIONS......................................................................................11-1

12. CONTROL SYSTEM .............................................................................................12-1

13. TROUBLESHOOTING ..........................................................................................13-1

14. EXPLODED VIEWS AND SPARE PARTS LISTS.................................................14-1

15. APPENDIX A .........................................................................................................15-1

1-1

INTRODUCTION

SM ALPHA 1-E.3 GB

1. INTRODUCTION

1.1 General

The new Alpha / Delta split wall mounted is based on the compact range. It comprise

the ST (cooling only) and RC (heat pump) models,

The indoor Alpha / Delta units are available as LED display types, featuring esthetic

design, compact dimensions, and low noise operation.

1.2 Main Features

The Alpha / Deltaseries beneﬁts from the most advanced technological innovations,

namely:

●R410A models

●Microprocessor control.

●Infrared remote control with liquid crystal display.

●Indoor large diameter cross ﬂow fan, allowing low noise level operation.

●Bended indoor coil with treated aluminum ﬁns and coating for improved

efﬁciency.

●High COP.

●Easy access to the interconnecting tubing and wiring connections, so that

removing the front grill or casing is not necessary.

●Refrigerant pipes can be connected to the indoor unit from 5 different optional

directions.

●Automatic treated air sweep.

●Easy installation and service.

●4M length tubing connection kit is provided in the outdoor unit (optional).

1.3 Indoor Unit

The indoor unit is wall mounted, and can be easily ﬁtted to many types of residential

and commercials applications.

It includes:

●Casing with air inlet and outlet grills.

●A large-diameter tangential fan.

●Bended coil with treated aluminum ﬁns.

●Motorized ﬂaps

●Multi-speed motor with internal protection

●Advanced electronic control box assembly

●Interconnecting wiring terminal block

●Mounting plate

CONTENT

1-2

INTRODUCTION

SM ALPHA 1-E.3 GB

1.4 Filtration

The Alpha / Delta series presents several types of air ﬁlters

●Easily accessible, and re-usable pre-ﬁlters (mesh)

●Pre-charged electrostatic ﬁlter (optional)

●Active carbon ﬁlter (optional)

1.5 Control

The microprocessor indoor controller, and an infrared remote control, supplied as

standard, provide complete operating function and programming. For further details

please refer to the Operation Manual, Appendix A.

1.6 Outdoor Unit

The Alpha / Delta outdoor units can be installed as ﬂoor or wall mounted units by using

a wall supporting bracket. The metal sheets are protected by anti- corrosion paint work

allowing long life resistance. All outdoor units are pre-charged. For further information

please refer to the Product Data Sheet, Chapter 2.

It includes :

●A Rotary compressor mounted in a soundproofed compartment :

●Axial fan.

●Outdoor coil with hydrophilic louver ﬁns for RC units.

●Outlet air fan grill.

●Service valves” ﬂare” type connection.

●Interconnecting wiring terminal block.

1.7 Tubing Connections

Flare type interconnecting tubing can be produced on site.

A connection pipe kit is provided in outdoor package.

For further details please refer to the Installation Manual, Appendix A.

1.8 Accessories

ASK (All Season Kit):

For low ambient working conditions in cooling, an ASK can be installed inside the outdoor

unit. This kit allows cooling operation down to outdoor temp of -10 ºC by gradually

controlling the outdoor fan speed motor.

1.9 Inbox Documentation

Each unit is supplied with its own installation and operation manuals.

CONTENT

2-1

PRODUCT DATA SHEET

SM ALPHA 1-E.3 GB

2. PRODUCT DATA SHEET

2.1 Alpha 7 / CON7 (Alpha)

Model Indoor Unit Alpha 7

Model Outdoor Unit CON 7 (Alpha)

Installation Method of Pipe Flared

Characteristics Units Cooling Only Cooling Heating

Capacity (1) Btu/hr 7000 7000 7300

kW 2.05 2.05 2.15

Power input (1) kW 0.68 0.68 0.63

EER (Cooling) or COP(Heating) (1) W/W 3.01 3.01 3.41

Energy efﬁciency class B B B

Power supply V/Ph/Hz 230V/Single/50Hz

Rated current A 3.0 3.0 2.8

Starting current A 15

Circuit breaker rating A 10

INDOOR

Fan type & quantity Crossﬂow x 1

Fan speeds H/M/L RPM 1150/950

Air ﬂow (2) H/M/L m3/hr 390/320

External static pressure Min-Max Pa 0

Sound power level (3) H/M/L dB(A) 50/44

Sound pressure level(4) H/M/L dB(A) 37/32

Moisture removal l/hr 0.8

Condenstate drain tube I.D mm 16

Dimensions WxHxD mm 680*250*180

Weight kg 7

Package dimensions WxHxD mm 740*250*310

Packaged weight kg 9.5

Units per pallet units 36

Stacking height units 9 levels

OUTDOOR

Refrigerant control Capillary tube

Compressor type, model Rotary,TOSHIBA,PA82X1C-4DZDE

Fan type & quantity Propeller(direct) x 1

Fan speeds H/L RPM 850

Air ﬂow H/L m3/hr 1200

Sound power level H/L dB(A) 61 62

Sound pressure level(4) H/L dB(A) 52 53

Dimensions WxHxD mm 610*235*490

Weight kg 27 27.5

Package dimensions WxHxD mm 720*550*360

Packaged weight kg 30/33.5(with kit) 30.5/34(with kit)

Units per pallet Units 12

Stacking height units 4 levels

Refrigerant type R410A

Refrigerant chargless distance Kg/m 0.72kg/7.5m

Additional charge kg 4m≤length≤10m,0.72kg; 10m<length≤15m,0.8kg

Connections between

units

Liquid line In.(mm) Ф1/4”(6.35)

Suction line In.(mm) Ф3/8”(9.53)

Max.tubing length m. Max.15

Max.height difference m. Max.7

Operation control type Remote control

Heating elements kW

Others

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

CONTENT

2-2

PRODUCT DATA SHEET

SM ALPHA 1-E.3 GB

2.2 Delta 7 R410A А2 DF / GCN 7 RC R410A A2

Model Indoor Unit Delta 7 R410A A2 DF

Model Outdoor Unit GCN 7 RC R410A A2

Installation Method of Pipe Flared

Characteristics Units Cooling Heating

Capacity (4) Btu/hr 7780 7850

kW 2.28 2.30

Power input (4) kW 0.62 0.67

EER (Cooling) or COP(Heating) (4) W/W 3.70 3.45

Energy efﬁciency class(SII) A A

Power supply

V 230

Ph 1

Hz 50

Rated current A 2.8 3.0

Power factor 0.95 0.95

Prated (IDU) W 30

Prated (IDU+ODU) W 890

Starting current A 15

Circuit breaker rating A 10

INDOOR

Fan type & quantity Crossﬂow x 1

Fan speeds H/M/L RPM 1050/-/900

Air ﬂow (1) H/M/L m3/hr 450/-/380

External static pressure Min Pa 0

Sound power level (2) H/M/L dB(A) 50/-/44

Sound pressure level(3) H/M/L dB(A) 37/-/31

Moisture removal l/hr 0.74

Condenstate drain tube I.D mm 16

Dimensions WxHxD mm 680x250x180

Net Weight kg 6

Package dimensions WxHxD mm 740x310x248

Packaged weight kg 8.5

Units per pallet units 32

Stacking height units 8 levels

OUTDOOR

Refrigerant control Capillary tube

Compressor type,model Rotary,Toshiba(GMCC),PA82X1C-4DZDE

Fan type & quantity Propeller(direct) x 1

Fan speeds H RPM 830

Air ﬂow H m3/hr 1450

Sound power level H dB(A) 60

Sound pressure level(3) H dB(A) 50

Dimensions WxHxD mm 830x545x245

Net Weight kg 31.5

Package dimensions WxHxD mm 870x600x320

Packaged weight kg 34

Units per pallet Units 12

Stacking height units 3 levels

Refrigerant type R410A

Refrigerant chargless distance kg(7.5m) 0.8kg

Additional charge 4m≤Length≤10m: +0g; 10mLength≤15m: +50g

Connections between

units

Liquid line In.(mm) 1/4"(6.35)

Suction line In.(mm) 3/8"(9.53)

Max.tubing length m. Max.15

Max.height

difference m. Max.7

Operation control type Remote control

Heating elements(Option) kW

Others

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

CONTENT

2-3

PRODUCT DATA SHEET

SM ALPHA 1-E.3 GB

2.3 Alpha 9 / GCN9 (Alpha)

Model Indoor Unit Alpha 9

Model Outdoor Unit GCN 9 (Alpha)

Installation Method of Pipe Flared

Characteristics Units Cooling Only Cooling Heating

Capacity (1) Btu/hr 9000 9000 9650

kW 2.64 2.64 2.83

Power input (1) kW 0.87 0.87 0.93

EER (Cooling) or COP(Heating) (1) W/W 3.03 3.03 3.04

Energy efﬁciency class BBD

Power supply V/Ph/Hz 230V/Single/50Hz

Rated current A 3.9 3.9 4.1

Starting current A 21.7

Circuit breaker rating A 10

INDOOR

Fan type & quantity Crossﬂow x 1

Fan speeds H/M/L RPM 1310/1100

Air ﬂow (2) H/M/L m3/hr 450/360

External static pressure Min-Max Pa 0

Sound power level (3) H/M/L dB(A) 53/49

Sound pressure level(4) H/M/L dB(A) 41/35

Moisture removal l/hr 1.2

Condenstate drain tube I.D mm 16

Dimensions WxHxD mm 680*250*180

Weight kg 7

Package dimensions WxHxD mm 740*250*310

Packaged weight kg 9.5

Units per pallet units 36

Stacking height units 9 levels

OUTDOOR

Refrigerant control Capillary tube

Compressor type,model Rotary,TOSHIBA,PA108X1C-4FZDE

Fan type & quantity Propeller(direct) x 1

Fan speeds H/L RPM 750

Air ﬂow H/L m3/hr 1370

Sound power level H/L dB(A) 59 61

Sound pressure level(4) H/L dB(A) 49 51

Dimensions WxHxD mm 830x245x545

Weight kg 32.5 33.5

Package dimensions WxHxD mm 880x320x610

Packaged weight kg 35/38.5(with kit) 36/39.5(with kit)

Units per pallet Units 9

Stacking height units 3levels

Refrigerant type R410A

Refrigerant chargless distance kg/m 0.85kg/7.5m 0.9kg/7.5m

Additional charge kg 4m≤length≤10m,0.85kg

10m<length≤15m,0.93kg

4m≤length≤10m,0.9kg

10m<length≤15m,0.98kg

Connections between

units

Liquid line In.(mm) Ф1/4”(6.35)

Suction line In.(mm) Ф3/8”(9.53)

Max.tubing length m. Max.15

Max.height difference m. Max.7

Operation control type Remote control

Heating elements kW

Others

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units). and EN 14511

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

CONTENT

2-4

PRODUCT DATA SHEET

SM ALPHA 1-E.3 GB

Units Coolin

Onl

Btu/hr 8870

kW 2.6

Sensible capacit

kW 1940

Moisture removal l/hr 0.98

kW 0.78

W/W 3.34

V/Ph/Hz

3.5

Fan speeds RPM

External static pressure Nom Pa

amp

(

)

(

)

WxDxH mm

watt

amp

RPM

m3/hr

RPM

watt

(

)

(

)

WxDxH mm

32 / 34.5

In.

(

)

In.

(

)

kW -

795*610*290 / 970*650*394

R410A

Running Current (Rated)

60 / -

730

0.45

41/-/35

supplied by others

0.13

53/-/49

Max.8

RC7 Remote control

680*250*180 / 740*310*248

9.5

Capillary tube

Flared

Max15

1.5

21°C/ 46°C

-9°C / 24°C

Power level (H/L)

Pressure level(3) (H/L)

Coil

49 / -

Weight

Air flow

3/8"(9.53)

Speed (H/L)

Motor Type

0.91kg/7.5m

4m＜L≤10m: +0g; 10m＜L≤15m: +80g

Sound

Add charge per mtr

Model Indoor unit

Outdoor unit

Cooling Temperature Operating Range (Min/Max)

Fan

Rows

Heating elements (Option) -

Max.tubing length

Connections between

units

Suction line

Max.height difference

Operation control type

Liquid line

Type

1/4"(6.35)

Others -

1750

33 / 35.5

Dimensions/(packaged)

Weight(packaged)

fixed RPM

Area

400

21°C DB (15 °C WB) / 32°C DB (23°C WB)

Sound

ONG3-9 R410A B1

Motor kW

10°C /27°C

Power level (H/M/L)

Pressure level(3) (H/M/L

Condenstate drain tube I.D

Airflow direction control

Air Filter

Cooling Temperature Operating Range (Min/Max)

Type

Model

Heating Temperature Operating Range (Min/Max)

Dimensions/(packaged)

Fin Spacing

Type

Blades

Motor output

Diameter

21.7

H/M/L

Fan type & quantity

Delta 9RC/ST fixed rpm R410A

Model

Centifugal x1

1310/-/1100

OUTDOOR

Compressor

Motor Speed

Refrigerant Chargless distance

Heating Temperature Operating Range (Min/Max)

Type

Control

Model

Running Current (Rated

)

3.35

Power supply 220-240V/Single/50Hz

INDOOR

Air flow (1)

3.8

Starting current

Circuit breaker rating

0.850

1940 -

Capacity (4)

Total 8870 9720

2.6 2.85

0.98

EER (Cooling) or COP(Heating) (4) 3.34

Heating

Delta 9RC/ST fixed rpm R410A

ONG3-9 R410A B1

Characteristics Cooling

Running Current (Rated) 3.5

Coil

Fin Spacing 1.5

Power input (4) 0.78

100

Rows

0.126Area

L/S -

125

Single Rotary

PA103X1C-4DZDE

3000

Propeller(direct) x 1

840/870

3.90/3.80

(1) Airﬂow in ducted units;at nominal external static pressure.

(2)Sound power in ducted units is measured at air discharge.

(3)Sound pressure level measured at 1-meter distance from unit.

(4)Rating conditions in accordance to AS 3823, ISO 5151 and ISO 13253 (for ducted units).

2.4 Delta 9 RC/ST ﬁxed RPM R410A / ONG3-9 R410A B1

CONTENT

2-5

PRODUCT DATA SHEET

SM ALPHA 1-E.3 GB

2.5 Delta 9 R410A B2 DF / ONG3-9 RC R410A B2 ISR

Model Indoor Unit Delta 9 R410A B2 DF ISR

Model Outdoor Unit ONG3-9 RC R410A B2 ISR

Installation Method of Pipe Flared

Characteristics Units Cooling Heating

Capacity (4) Btu/hr 9210 9890

kW 2.70 2.90

Power input (4) kW 0.75 0.83

EER (Cooling) or COP(Heating) (4) W/W 3.60 3.50

Energy efﬁciency class(SII) C C

Power supply

V 230

Ph 1

Hz 50

Rated current A 3.4 3.8

Power factor 0.95 0.95

Prated (IDU) W 30

Prated (IDU+ODU) W 1050

Starting current A 16.6

Circuit breaker rating A 10

INDOOR

Fan type & quantity Crossﬂow x 1

Fan speeds H/M/L RPM 1320/-/1100

Air ﬂow (1) H/M/L m3/hr 450/-/360

External static pressure Min Pa 0

Sound power level (2) H/M/L dB(A) 53/-/49

Sound pressure level(3) H/M/L dB(A) 41/-/35

Moisture removal l/hr 1.02

Condenstate drain tube I.D mm 16

Dimensions WxHxD mm 680x250x180

Net Weight kg 6

Package dimensions WxHxD mm 740x310x248

Packaged weight kg 8.5

Units per pallet units 32

Stacking height units 8 levels

OUTDOOR

Refrigerant control Capillary tube

Compressor type,model Rotary,Toshiba(GMCC),PA103X1C-4FZDE1

Fan type & quantity Propeller(direct) x 1

Fan speeds H RPM 780

Air ﬂow H m3/hr 1800

Sound power level H dB(A) 59

Sound pressure level(3) H dB(A) 49

Dimensions WxHxD mm 795x610x290

Net Weight kg 33

Package dimensions WxHxD mm 970x650x394

Packaged weight kg 35.5

Units per pallet Units 9

Stacking height units 3 levels

Refrigerant type R410A

Refrigerant chargless distance kg(7.5m) 0.95kg

Additional charge 4m≤Length≤10m: +0g; 10m≤Length≤15m: +50g

Connections between

units

Liquid line In.(mm) 1/4"(6.35)

Suction line In.(mm) 3/8"(9.53)

Max.tubing length m. Max.15

Max.height

difference m. Max.7

Operation control type Remote control

Heating elements(Option) kW

Others

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

CONTENT

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Electra Klimaanlage Handbücher

Electra

Electra LEX 25 DCI Bedienungsanleitung

Electra

Electra LS DCI Series Bedienungsanleitung

Electra

Electra DUO 9+9 ST Bedienungsanleitung

Electra

Electra WNG 25 DCI INV Bedienungsanleitung

Electra

Electra JKD DCI Series Bedienungsanleitung

Electra

Electra WNG 9 DCI INV Bedienungsanleitung

Electra

Electra EMD 27 Bedienungsanleitung

Electra

Electra ELSI-JYD009-H11 Bedienungsanleitung

Electra

Electra ELSI-JKD009-N11 Bedienungsanleitung

Electra

Electra WNG 25 DCI Series Bedienungsanleitung

Electra

Electra WNG 36 Bedienungsanleitung

Electra

Electra DELTA 18ST Bedienungsanleitung

Electra

Electra CN 25 DCI Bedienungsanleitung

Electra

Electra WMZ Series Bedienungsanleitung

Electra

Electra Multi Split DUO 50 DCI Bedienungsanleitung

Electra

Electra LEX 7 Bedienungsanleitung

Electra

Electra IOD 7 Bedienungsanleitung

Electra

Electra Alpha 9 SP R22 Bedienungsanleitung

Electra

Electra ELSI-JKD009-N11 Bedienungsanleitung

Electra

Electra DNG DC Series Bedienungsanleitung

Electra

Electra DELTA 25 Bedienungsanleitung

Electra

Electra WF 230 Handbuch

Electra

Electra DCI Light Commercial Series Bedienungsanleitung

Electra

Electra ELSI-JGF009-N11 Bedienungsanleitung

Beliebte Klimaanlage Handbücher anderer Marken

Spheros

Spheros CC 355 Bedienungsanleitung

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Bedienungsanleitung

Panasonic

Panasonic CS-E12HKEW Bedienungsanleitung

nedis

nedis ACMB1WT7 Bedienungsanleitung

Samsung

Samsung AR KV Series Leitfaden

Daikin

Daikin FCFV50A Bedienungsanleitung

Fujitsu

Fujitsu Inverter ASBA30JFC Bedienungsanleitung

Toshiba

Toshiba RAS-M10SMUV-E Bedienungsanleitung

Daikin

Daikin FXLQ20MAVE Bedienungsanleitung

Hitachi

Hitachi RAS-E24CAK Bedienungsanleitung

CIAT

CIAT Magister 2 Series Leitfaden

Bestron

Bestron AAC6000 Bedienungsanleitung

Hisense

Hisense 7K Technisches Handbuch

Frigidaire

Frigidaire FFRE0533S1E0 Bedienungsanleitung

Samsung

Samsung AS09HM3N Bedienungsanleitung

Frigidaire

Frigidaire CRA073PU11 Betriebsanleitung

Soleus Air

Soleus Air GB-PAC-08E4 Bedienungsanleitung

McQuay

McQuay MCK020A Bedienungsanleitung
