Electro-Voice FRi+ 181S Bedienungsanleitung

KeyFeatures:

• Unequalized flat response to 42 Hz

• Usable bass output to 32 Hz

• 16 threaded suspension points

• Available in black, white and

unfinished

• Arrays with FRi/FRi+ full-range systems

• High sensitivity, 100 dB below 100 Hz

• Paintable Enclosure

FRi+181S

Vented 18-inch

Subwoofer

Speaker System

General Description:

The FRi+181 is designed for applications where extended low

frequency response is desired in an FRi/FRi+ installation. It is

a trapezoidal enclosure identical in height, appearance and

suspension to the FRi/FRi+ full-range systems. An 18" LF

transducer is centrally mounted in a large optimally-vented

enclosure for efficient deep-bass response that requires only

minimal equalization. These professional fixed install

speakers deliver a broad range of performance options

including multiple rotatable horn patterns, matching sub-

woofer, full-range systems with easily switchable passive or bi-

amp operation, and EV’s world renowned transducer

technology for response that is smooth and linear. The FRi/

FRi+ Series is an economical and flexible solution for the

most demanding installations.

Same height full-range and sub-woofer systems allow the

installer to construct arrays covering the most demanding

acoustical environments while maintaining an aesthetic and

uniform installation. The structural integrity of the FRi/FRi+

cabinets allows for vertical arrays up to 2 boxes in height. All

FRi/FRi+ systems are available in weather resistant black

Futura, white, and unfinished. Performance my be further

enhanced by bi-amping or tri-amping with the Electro-Voice

Dx-38 Digital Sound System Processor.

Technical Specifications:

esnopseR.qerF

:)Bd3-(zH071-zH73

egnaR.qerF

:)Bd01-(zH071-zH82

LPSdetaluclaCxaM

:)kaeP(Bd231

:egarevoClatnoziroHlanoitceridinmO

:egarevoClacitreVlanoitceridinmO

:gnildnaHrewoPkaePW0061,suounitnoCW004

ytivitisneSFL

:m1/W1,Bd001

:recudsnarTFLsmho8,revirD)mm754("81tm81LD

:qerFgninuTerusolcnEzH63

ssaP-iHdednemmoceR

:ycneuqerF

.nimtco/Bd21,zH23

revossorCdednemmoceR

:ycneuqerF

zH08

:srotcennoCspirtSreirraB

:lairetaMerusolcnEdoowylPhcriBylp-31

:noisnepsuSstnioPdedaerhT"8/3x61

:ellirGleetSAG61

:cepSlatnemnorivnE42PI925CEI

:)DxWxH(miD"0.62x"3.82x"0.13

)mm066x917x787(

:)hcae(thgieWteN)gk5.54(sbl001

:thgieWgnippihS)gk7.74(sbl501

1 Half Space measurement.

Block Diagram:

Frequency Response (Full/Half Space) :

Dimension Drawings:

PerformanceMatch:

• FRi+122/64 - 301217-000, 301217-001, 301217-002

• FRi+122/66 - 301219-000, 301219-001, 301219-002

• FRi+122/94 - 301218-000, 301218-001, 301218-002

• FRi+152/64 - 301210-000, 301210-001, 301210-002

• FRi+152/66 - 301212-000, 301212-001, 301212-002

• FRi+152/94 - 301216-000, 301216-001, 301216-002

• FRi-122/64 - 1152-3362, 1152-3337, 1152-3359

• FRi-122/85 - 1152-3392, 1152-3384, 1152-3385

• FRi-152/64 - 1152-3363, 1152-3336, 1152-3360

• FRi-152/85 - 1152-3393, 1152-3386, 1152-3387

FRi+181SPart Numbers:

• FRi+181S (Unfinished) - 1152-3364

• FRi+181S (Black) - 1152-3340

• FRi+181S (White) - 1152-3361

12000 Portland Avenue South, Burnsville, MN 55337

Phone:952/884-4051, Fax:952/884-0043

www.electrovoice.com

Part Number 38110-164 Rev A

U.S.A. and Canada only. For customer orders, contact Customer Service at:

800/392-3497 Fax: 800/955-6831

Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:

+ 49 9421-706 0 Fax: + 49 9421-706 265

Other International locations. For customer orders, contact Customer Service at:

+ 1 952 884-4051 Fax: + 1 952 736-4212

For warranty repair or service information, contact the Service Repair department at:

800/685-2606

For technical assistance, contact Technical Support at: 866/78AUDIO

Specifications subject to change without notice.

Beamwidth:

Directivity:

Unfinished Black White

SideFront

Top

Impedance:
