Electro-Voice ZX3 Bedienungsanleitung

The new Electro-Voice ZX3 offers an unprecedented level of

lightweight, 12” two-way loudspeaker performance for the widest

variety of portable and installed applications.

At ﬁrst we thought ZX3 would set the new standard for its class. Since

Electro-Voice is no stranger to industry standards, we were conﬁdent

this would be the case. However, once you hear ZX3, we think you’ll

agree… it’s actually in a class of its own.

Featuring the new DVX3121 12-inch woofer, ZX3 continues the

groundbreaking innovation of the Electro-Voice DVX high-performance

woofer design program. No other 12” woofer can touch it. Our ND2

neodymium compression driver completes this no-compromise

approach to maximum sonic performance and reliability.

In addition to the highest performance drivers available, a complete

range of optional accessories, including the CB3 array kit, MB3

wall/ceiling mount bracket, HA-3 handle adapter (for use with the

VSA-1 strong arm mount), and TCA-1 truss clamp adapter, allow

ZX3 to be easily and precisely conﬁgured in multiple box arrays,

mounted on truss or tripods, deployed as monitors, or used as

system mains with a subwoofer.

Speciﬁcations

Frequency Response (-3dB) 58 - 15000 Hz

Frequency Response (-10dB) 48 - 20000 Hz

Sensitivity 1W/1m 97 dB

System Power Handling (continuous/program/peak) 600/1200/2400 Watts

Low Frequency Power Handling (continuous/program/peak) 500/1000/2000 Watts

High Frequency Power Handling (continuous/program/peak) 40/80/160 Watts

Coverage (hor. x ver.) 90° x 50° or 60° x 60°

LF Transducer DVX3121

HF Transducer ND2

Enclosure Material Polypropylene

Color Black or White

Permanent Outdoor Use PI version (IP55) black or white

Speaker Type Full range

Weight Net 19.8 kg ( 43.65 lbs )

Bosch Communications Systems

Telex Communications, Inc.

12000 Portland Ave South,

Burnsville, MN 55337, USA

USA–Ph: 1-800-392-3497

Fax: 1-800-955-6831

PA#20693

SSK-1 CB5

HA3 HDC-3

EBK-3

Housed in a stylish yet rugged injection molded enclosure, ZX3 is

available in a weatherized version and in either black or white ﬁnish.

ZX3 is also available with 90° x 50° or 60° x 60° horn dispersion

patterns, 45° or 55° monitor angles, passive or bi-amp operation,

and seven M8 rigging points.

A solution for all your small-format sound reinforcement needs, ZX3

introduces a new era in 12” two-way performance.

Key features:

• Weight:19.8kg(43.7lbs)

• 97dBsensitivity1W@1m

• MaxSPL:131dB

• Continuouspowerhandling(passivemode)600watts

• Continuouspowerhandling(bi-ampmode)LF500watts,

HF 40 watts

• Dimensions:614mmx398mmx363mm

(24.17 in x 15.65 in x 14.3 in)

• NL4ortwoconductorSJOcableandglandnut

(weatherized versions)

• SevenM8riggingpoints,twosinglestudttings
