ElectroFlip PETRACK Bedienungsanleitung

PeTrack

User Guide

The PeTrack will help keep track of your pet on-demand with your mobile phone. There are

various

features, please take your time to follow through step by step to get familiar with your

device and

eventually you’ll become a pro. Once up and online and with your understanding the

PeTrack will ensure

safety for your pet for many dog years to come.

All information and instructions included in this User Guide are current as of November 2016.

However, due to the fluid nature of advancing technology, some characteristics may change or

need

modifications in the future. Should you encounter any problems or have any further

questions about

your purchase, please visit our website www.ElectroFlip.com and contact us

through our Contact Us

page. To download the large PDF digital version of this guide visit:

http://www.ElectroFlip.com/UserGuides/PeTrack.pdf

This document is a property of ElectroFlip LLC (www.ElectroFlip.com).

No unauthorized reproduction is allowed.

TABLE OF CONTENTS

KEEP IN MIND .......................................................................................................................................3

PRODUCT INFORMATION......................................................................................................................3

PeTrack Diagram .............................................................................................................................................3

GETTING STARTED .............................................................................................................................4

Locate/Buy Prepaid GSM SIM Card ...............................................................................................................4

Activate and Load Your SIM Card with Funds................................................................................................5

Installing the SIM Card ................................................................................................................................5

Charging and Clip Assembly...........................................................................................................................6

Buckle Locking Clip ......................................................................................................................................6

Turn On/Off ....................................................................................................................................................7

Low Power Setting .........................................................................................................................................8

ON-DEMAND TRACKING .......................................................................................................................8

TRACKING WITH APPS...........................................................................................................................9

Tracking by Mobile App ..................................................................................................................................9

TBPT App TALK/TEXT-Based Tracking.................................................................................................................. 10

TBPT App Setup (Android Only)..............................................................................................................10

How to Start Tracking w/ TBPT App..................................................................................................... 11

Geo-Fence Setting (TBPT App Only) .......................................................................................................12

i-Server TEXT/GPRS/Data Live-Based Tracking ............................................................................................ 13

APN (Access Point Name) Setup.......................................................................................................... 13

Add and Delete Device............................................................................................................................14

Display and Hide the Device ...................................................................................................................14

Change Picture Icon ................................................................................................................................... 14

Checking GPS Status................................................................................................................................16

History Route ..........................................................................................................................................16

GPS and LBS Signal ..................................................................................................................................17

Parameter Settings..................................................................................................................................17

App Settings ............................................................................................................................................18

TROUBLESHOOTING............................................................................................................................18

This document is a property of ElectroFlip LLC (www.ElectroFlip.com).

No unauthorized reproduction is allowed.

KEEP IN MIND

The PeTrack can be worn by your pet at all times. That said, the PeTrack is waterproof

and dirt

proof however it should not be submerged for long periods of time. Remember

to close/seal

the charging port with its rubber door and use the mini screw plugs

provided.

Charge the device as soon as you receive a low battery notification. Also please

remember to always power cycle (turn off then on) the PeTrack after disconnecting from

your

charger. If you do not intend to use it at the moment, power it off.

The PeTrack must not be located or operating in conjunction with any other collar

antenna or transmitter. This will cause interference with the PeTrack. More than one

PeTrack

is fine.

The PeTrack is designed for the outdoors, it cannot be used indoors or your GPS tracking

results

will be poor.

PRODUCT INFORMATION

PETRACK DIAGRAM

This document is a property of ElectroFlip LLC (www.ElectroFlip.com).

No unauthorized reproduction is allowed.

Important Note: Please see Page 5 for the correct GSM SIM Card size.

GETTING STARTED

LOCATE/BUY PREPAID GSM SIM CARD

You will need a simple Prepaid GSM SIM Card (Standard Size, see Page 5 for correct

size. SIM

Cards by default come in multiple sizes, its important you use the largest size

card they offer.)

You can get a prepaid or pay-as-you-go SIM card from T-Mobile local stores and its resellers. You

can also go to the link below.

https://prepaid-phones.t-mobile.com/pay-as-you-go

To check for T-Mobile network coverage: http://www.t-mobile.com/coverage-map.html

You could also get prepaid SIM card from the following alternative providers:

USMobile

https://www.usmobile.com/shop/product/Triple-Cut-GSM-SIM-Card

Ting

https://ting.com/rates

Net10

http://www.net10wireless.com/#/plans/pay-as-you-go

This document is a property of ElectroFlip LLC (www.ElectroFlip.com).

No unauthorized reproduction is allowed.

The PeTrack is like a sophisticated cellular phone, you will now need a SIM card / cellular

provider

for this device in order for it to notify you of its whereabouts at any given time.

This allows your

PeTrack to send you text messages of its location.

Fortunately the use of GPS satellites is free, but the use of GSM cellular phone towers

is not.

However the GSM cost is negligible considering the PeTrack only requires text

messages to

inform you of its location. (Only a Basic Talk and Text plan is required)

If you’re not sure what provider to use or where to locate a Prepaid GSM SIM Card,

contact

the vendor you purchased your PeTrack from and they can quickly locate an

economical

GSM carrier for your area.

ACTIVATE AND LOAD YOUR SIM CARD WITH FUNDS

Once you have a SIM Card handy, ensure you’ve activated it through the SIM Card’s

carrier’s

website. Alternatively you can call them to activate it. They may ask you if you

want to buy a

phone or what phone it is for, etc… You simply tell them you would like to activate and fund your

SIM card; you do not need any other hardware.

Reload/Recharge/Fund/Put Money On to the SIM CARD. There are various names for

this;

however they all have the same meaning, after activation you will need to put

funds on

your new SIM card in order for it to work. Depending on the plan you selected,

the cost will vary

but most are very economical. Only select a plan according to what

you believe your needs

will be. We recommend a simple low cost Pay As You Go plan, so

this way you’re not paying for a

subscription.

INSTALLING SIM CARD

Please first make sure that the GSM SIM card you are using is already activated, has a phone

number

from the cellular carrier, and funding is loaded on the SIM card, so it’s ready to use.

This device only

works with a specific size SIM card. The correct size to use is a Full Size /

Standard SIM Card, not a

micro-SIM or nano-SIM size (see example on next page).

This document is a property of ElectroFlip LLC (www.ElectroFlip.com).

No unauthorized reproduction is allowed.

Steps to Install the SIM Card:

Loosen 4 screws with the screw driver included.

Remove the back cover and insert the SIM card into the slide slot with the gold-plated

contacts facing downwards.

Put the cover back with the USB side and gently and evenly tighten 4 screws back in.

Insert the 4 waterproof plugs over the screws.

CHARGING and CLIP ASSEMBLY

Charging

Connect the PeTrack to the AC Adapter via the USB

cable. For the first two charges, charge overnight

help condition the battery.

REMEMBER: Once the PeTrack is fully charged you will see the Red LED turn off. Once

disconnected from the charging cable, power cycle before using the PeTrack.

Clip Assembly

Put the collar included (or your own) through the

clip.

BUCKLE LOCKING CLIP

Assemble the PeTrack and the clip according to the arrow mark on both sides. Turn

counterclockwise to lock it (VERY IMPORTANT). Please refer to the images on the next page.

This document is a property of ElectroFlip LLC (www.ElectroFlip.com).

No unauthorized reproduction is allowed.

RUBBER SUPPORT BANDS

If your pet is commonly active or just likes to scratch or rub his collar. We highly recommend

using

the support bands for as an extra precaution to prevent the PeTrack from

twisting/unlocking and

falling off.

TURN ON/OFF

On the back of the PeTrack are 3 LED’s you will not see them as they’re covered by the

waterproof casing. Pay close attention to the back of the unit to help identify their location and

the

PeTrack’s state. The Power button is located on the side of the unit, opposite to the

charging

port. Please remember to watch the YouTube video in the example below.

ON – Press and hold the power for 5 seconds. Three LED lights will all flash at the same time,

for a split

second. The PeTrack is now ON and will continue to blink slowly every 15-30 seconds.

OFF – Press and hold the power for 10 seconds. Three LED lights will blink in sequential order.

It is now

powered OFF.

Here is a YouTube example of this:

http://bit.ly/1Oqed1E

This document is a property of ElectroFlip LLC (www.ElectroFlip.com).

No unauthorized reproduction is allowed.

REMEMBER: Your PeTrack will fall asleep automatically after sitting still for more than 3

minutes,

if you’re trying to setup your APN, or call it, or text it, or just getting it to respond, you

need to either

physically shake the unit every minute while you’re outside or it needs to be attached to an active pet

which is outside. Otherwise you’ll have no response, as it’s completely

dependent on motion detection to

conserve its battery power.

LOW POWER SETTING

When the device is in low power, it will send an SMS alert to the notification phone number you

configure on the PeTrack (not the PeTrack’s / SIM Card number, but your personal mobile phone

number).

To set this alert, please follow the steps below.

Send the following Text message to your PeTrack:

515#0000#15554443333

In place of 1 put your country code if outside the United States, then the mobile phone

number

of the phone you want the alert sent to.

(Country Code + Area Code + 7 Digit Number)

REMEMBER: Your PeTrack will fall asleep automatically after sitting still for more than 3

minutes,

if you’re trying to setup your APN, or call it, or text it, or just getting it to respond, you

need to either

physically shake the unit every minute while you’re outside or it needs to be

attached to an active

pet which is outside. Otherwise you’ll have no response, as it’s completely

dependent on motion

detection to conserve its battery power.

ON-DEMANDTRACKING

The following is an explanation on how to use your PeTrack without having to download

anything, such as a mobile App. A major benefit to using this method of tracking alone (without

a mobile

app) is that the battery will last longer per charge. Also note this method of tracking

only requires

This document is a property of ElectroFlip LLC (www.ElectroFlip.com).

No unauthorized reproduction is allowed.

TALK\TEXT for your PeTrack’s SIM card.

From your personal cellular phone, call your PeTrack (this number would be the new

number for your new SIM card) and allow it to ring until it hits either “The User’s

Voicemail is not yet setup” or your Voicemail, then hang up.

You will receive a text message within a minute or two. You will get one of the two

responses:

Response 1: When GPS reception is good. This is an accurate update.

#GMSP340Ahttp://maps.google.com/?q=25.070310N,121.592933E150113081012

IMEI=357852039494938 S=15.8 C=254 SAT=12 V=4.42 CSQ=99 M=A0 SN=96381

Response 2: When GPS reception is poor/off it will provide your LBS, which is NOT

very

accurate. It’s more of an update in the general area.

#LMSP340A http://www.map110.com/?x=030.94&y=119.14 150113081012

IMEI=357852039494938 V=4.42 CSQ=99 GPS=ON M=A0 SN=96381

Your cellular phone will have a hyperlink highlighted, simply click it and you will be asked

to open

it with your internet browser or Google maps, either or is fine.

REMEMBER: Your PeTrack will fall asleep automatically after sitting still for more than 3

minutes,

if you’re trying to setup your APN, or call it, or text it, or just getting it to respond, you

need to either

physically shake the unit every minute while you’re outside or it needs to be

attached to an active

pet which is outside. Otherwise you’ll have no response, as it’s completely

dependent on motion

detection to conserve its battery power.

TRACKING WITH APPS

There are two ways of tracking your pet using PeTrack Mobile Apps; you can either track

through

TBPT App (TALK/TEXT only) or i-Server App (TEXT/GPRS only). It all depends on your

preference, need,

and smartphone type.

TRACKING BY MOBILE APP

Selecting an APP is a matter of the smartphone technology you have and personal preference.

Try one

or the other, and find what suits you best. Download the TBPT App or i-Server App

from your Google

Play App Store (Android) and Apple App Store (iPhone) or through the direct

links:

This document is a property of ElectroFlip LLC (www.ElectroFlip.com).

No unauthorized reproduction is allowed.

Android Phone TBPT App (TALK/TEXT Only)

https://play.google.com/store/apps/details?id=tracker.sms.tbpt&feature=search_result#

?t=W251bGwsMSwyLDEsInRyYWNrZXIuc21zLnRicHQiXQ

Android Phone i-Server (TEXT/GPRS/DATA Only)

https://play.google.com/store/apps/details?id=leo.tracker.i_server_for_340

iPhone i-Server (TEXT/GPRS/DATA Only): Search for i-Server within the Apple App

Store on

your phone. Alternatively you can download it from this user guide directly to

your iPhone by

using your phone and clicking on our i-Server logo here:

REMEMBER: Make sure to setup Access Point Name (APN) first before installing i-Server. Refer

topage13

fortheinstructions.

TBPT APP TALK/TEXT BASED TRACKING

Special Note: Some features might have been added or removed and icons may differ. We

update our

Apps frequently for improvements. However the concept and function of this

application are the

same.

TBPT APP SETUP (Android Only)

Here is a YouTube demonstration of the TBPT App setup:

http://youtu.be/3O4-dcQvPmo

1. Add a device. 2. Please dial the SIM card number

manually and hang up the phone after

hearing the ringtone.

This document is a property of ElectroFlip LLC (www.ElectroFlip.com).

No unauthorized reproduction is allowed.

Inhaltsverzeichnis

Beliebte Fitness-Tracker Handbücher anderer Marken

Fitbit Zip

Fitbit Zip ace 2 Bedienungsanleitung

Brigmton

Brigmton BSPORT-B2-N-A-R Bedienungsanleitung

Marea Smart

Marea Smart B57004 Bedienungsanleitung

Misfit

Misfit SHINE Bedienungsanleitung

Yamaha

Yamaha BODIBEAT Bedienungsanleitung

Fitbit Zip

Fitbit Zip Fitbit Zip Bedienungsanleitung

Seaver

Seaver CEEFIT Bedienungsanleitung

Garmin

Garmin vívosmart HR Gebrauchsanweisung

Sky

Sky HEALTHBAND Bedienungsanleitung

iHealth

iHealth Edge Bedienungsanleitung

Holux

Holux Impulse 8050 Bedienungsanleitung

Fitbit Zip

Fitbit Zip Charge HR Bedienungsanleitung

Garmin

Garmin Vivosport Bedienungsanleitung

Xiaomi

Xiaomi Mi Smart Band 6 NFC Bedienungsanleitung

Microsoft

Microsoft Band Bedienungsanleitung

HTC

HTC UA Band Bedienungsanleitung

FitBand

FitBand F1 Bedienungsanleitung

Huawei

Huawei Band 4 Bedienungsanleitung
