Glass and cup washer for

bars

EN Installation manual *

*Original instructions 59566V001- 2021.07

Installation diagram

Ø = 40

Ø = 20

Ø = 40

Ø = 20

795*

880**

210*

290**

635*

715**

* = Short version

** = Small version

EI = Power supply entry

CWI = Cold water Inlet pipe with ⌀=3/4″ G fittings

XD = Inlet pipe for detergents

EQ = Equipotential screw

D = Drain pipe with internal diameter:

⌀= 40 mm (Only for model with free-fall drainage)

⌀= 20 mm (Only for model with drain pump)

Foreword

Read the following instructions, including the warranty terms before installing and using the machine.

Visit our website www.electroluxprofessional.com and open the Support section to:

Get hints & tips of your product, service and repair information

The installation, use and maintenance manual (hereinafter Manual) provides the user with information necessary for correct and

safe use of the machine (or “appliance“).

The following must not be considered a long and exacting list of warnings, but rather a set of instructions suitable for improving

machine performance in every respect and, above all, preventing injury to persons and animals and damage to property due to im-

proper operating procedures.

All persons involved in machine transport, installation, commissioning, use and maintenance, repair and disassembly must con-

sult and carefully read this manual before carrying out the various operations, in order to avoid wrong and improper actions that

could compromise the machine's integrity or endanger people. Make sure to periodically inform the user regarding the safety regu-

lations. It is also important to instruct and update personnel authorised to operate on the machine, regarding its use and

maintenance.

The manual must be available to operators and carefully kept in the place where the machine is used, so that it is always at hand

for consultation in case of doubts or whenever required.

If, after reading this manual, there are still doubts regarding machine use, do not hesitate to contact the Manufacturer or the au-

thorised Service Centre to receive prompt and precise assistance for better operation and maximum efficiency of the machine.

During all stages of machine use, always respect the current regulations on safety, work hygiene and environmental protection. It

is the user's responsibility to make sure the machine is started and operated only in optimum conditions of safety for people, ani-

mals and property.

IMPORTANT

• The manufacturer declines any liability for operations carried out on the appliance without respecting the instructions

given in this manual.

• The manufacturer reserves the right to modify the appliances presented in this publication without notice.

• No part of this manual may be reproduced.

• This manual is available in digital format by:

– contacting the dealer or reference customer care;

– downloading the latest and up to date manual on the web site;

• The manual must always be kept in an easily accessed place near the machine. Machine operators and mainte-

nance personnel must be able to easily find and consult it at any time.

Contents

A SAFETY INFORMATION.........................................................................................................................6

A.1 General information ......................................................................................................................6

A.2 General safety .............................................................................................................................6

A.3 Personal protection equipment ........................................................................................................7

A.4 Transport, handling and storage ...................................................................................................... 7

A.5 Installation and assembly ............................................................................................................... 8

A.6 Water connection..........................................................................................................................8

A.7 Electrical connection .....................................................................................................................8

A.8 Machine cleaning and maintenance..................................................................................................9

A.9 Service.......................................................................................................................................9

A.10 Disposal of packing..................................................................................................................... 10

A.11 Machine disposal........................................................................................................................ 10

B GENERAL INFORMATION .................................................................................................................... 10

B.1 Introduction ............................................................................................................................... 10

B.2 Definitions................................................................................................................................. 10

B.3 Machine and Manufacturer’s identification data ................................................................................. 10

B.4 How to identify the technical data ................................................................................................... 11

B.4.1 How to interpret the factory description .................................................................................. 11

B.5 Type reference........................................................................................................................... 11

B.6 Responsibility ............................................................................................................................ 11

B.7 Copyright.................................................................................................................................. 12

B.8 Keeping the manual .................................................................................................................... 12

B.9 Recipients of the manual .............................................................................................................. 12

C TECHNICAL DATA............................................................................................................................... 12

C.1 Main technical characteristics........................................................................................................ 12

C.2 Characteristics of power supply cable ............................................................................................. 12

C.3 Characteristics of power supply ..................................................................................................... 12

D TRANSPORT, HANDLING AND STORAGE .............................................................................................. 13

D.1 Introduction ............................................................................................................................... 13

D.2 Transport: Instructions for the carrier............................................................................................... 13

D.3 Handling................................................................................................................................... 13

D.3.1 Procedures for handling operations....................................................................................... 13

D.3.2 Shifting ........................................................................................................................... 13

D.3.3 Placing the load................................................................................................................ 13

D.4 Storage .................................................................................................................................... 13

D.5 Unpacking ................................................................................................................................ 13

E INSTALLATION AND ASSEMBLY ........................................................................................................... 13

E.1 Introduction ............................................................................................................................... 13

E.2 Customer responsibilities ............................................................................................................. 13

E.3 Characteristics of the installation place............................................................................................ 14

E.4 Positioning................................................................................................................................ 14

E.5 Disposal of packing..................................................................................................................... 14

E.6 Plumbing connections ................................................................................................................. 14

E.7 Plumbing circuits ........................................................................................................................ 15

E.8 Electrical connections.................................................................................................................. 15

E.9 Safety devices ........................................................................................................................... 15

E.10 Detergent/rinse aid dispensers and prearrangements......................................................................... 16

E.10.1 Hoses connection to detergent and rinse aid containers ............................................................ 16

F CONTROL PANEL DESCRIPTION .......................................................................................................... 16

F.1 Control panel description.............................................................................................................. 16

G COMMISSIONING ............................................................................................................................... 17

G.1 Preliminary checks, adjustments and operational tests ....................................................................... 17

H TROUBLESHOOTING.......................................................................................................................... 18

H.1 General troubleshooting............................................................................................................... 18

A SAFETY INFORMATION

A.1 General information

To ensure safe use of the machine and a proper understanding of the manual it is

necessary to be familiar with the terms and typographical conventions used in the

documentation. The following symbols are used in the manual to indicate and identify the

various types of hazards:

WARNING

Danger for the health and safety of operators.

WARNING

Danger of electrocution - dangerous voltage.

CAUTION

Risk of damage to the machine or the product.

IMPORTANT

Important instructions or information on the product

Equipotentiality

Read the instructions before using the appliance

Clarifications and explanations

A.2 General safety

• The machine must not be used by people (including children) with limited physical,

sensory or mental abilities or without experience and knowledge of it, unless instructed

in its use and supervised by those responsible for their safety.

– Do not let children play with the machine.

– Keep all packaging and detergents away from children.

– Cleaning and user maintenance shall not be made by children without supervision.

• For suitable personal protection equipment, refer to chapter “A.3 Personal protection

equipment“.

• Several illustrations in the manual show the machine, or parts of it, without guards or

with guards removed. This is purely for explanatory purposes. Do not install the machine

without the guards or with the protection devices deactivated.

• Do not remove, tamper with or make illegible the safety, danger and instruction signs

and labels on the machine.

• Do not remove or tamper with the machine’s safety devices.

• Before carrying out any machine installation, always consult the installation manual,

which gives the correct procedures and contains important information on safety.

• Unauthorized personnel must not enter the work area.

• Remove any flammable products or items from the work area.

• Machine positioning, installation and disassembly must be carried out by the specialised

personnel in conformity with the current safety regulations, regarding the equipment

used and the operating procedures.

A.3 Personal protection equipment

Summary table of the Personal Protection Equipment (PPE) to be used during the various

stages of the machine's service life.

Stage Protective

garments

Safety

footwear

Gloves Glasses Safety

helmet

Transport —● ○ —○

Handling ● ● ○ — —

Unpacking ○ ● ○ — —

Installation ○ ● ●1— —

Normal use ● ● ●2○—

Adjustments ○ ● — — —

Routine

cleaning

○ ● ●1ˉ3○—

Extraordi-

nary

cleaning

○ ● ●1ˉ3○—

Maintenance ○ ● ○ — —

Dismantling ○ ● ○ ○ —

Scrapping ○ ● ○ ○ —

Key:

●PPE REQUIRED

○PPE AVAILABLE OR TO BE USED IF NECESSARY

—PPE NOT REQUIRED

1. During these operations, gloves must be cut-resistant. Failure to use the personal protection equipment by

operators, specialized personnel or users can involve exposure to damage to health (depending on the model).

2. During these operations, gloves must be heatproof and suitable for contact with water and the substances

used (refer to the safety data sheet of the substances used for the information regarding the required PPE).

Failure to use the personal protection equipment by operators, specialised personnel or users can involve

exposure to chemical risk and cause possible damage to health (depending on the model).

3. During these operations, gloves must be suitable for contact with chemical substances used (refer to the

safety data sheet of the substances used for information regarding the required PPE). Failure to use the

personal protection equipment by operators, specialized personnel or users can involve exposure to chemical

risk and cause possible damage to health (depending on the model).

A.4 Transport, handling and storage

• Due to their size, the machines cannot be stacked on top of each other during transport,

handling and storage; this eliminates any risks of loads tipping over due to stacking.

• Do not stand under suspended loads during loading or unloading operations.

Unauthorized personnel must not enter the work area.

• The weight of the appliance alone is not sufficient to keep it steady.

• For machine lifting and anchoring, do not use movable or weak parts such as: casings,

electrical raceways, pneumatic parts, etc.

• Do not push or pull the machine to move it, as it may tip over. Use proper tool to lift the

machine.

• Machine transport, handling and storage personnel must be adequately instructed and

trained regarding the use of lifting systems and personal protection equipment suitable

for the type of operation carried out.

A.5 Installation and assembly

• Follow the installation instruction supplied with the machine.

• Do not install a damaged machine. Any missing or faulty parts must be replaced with

original parts.

• Do not make any modifications to the parts supplied with the machine.

• Disconnect the machine from the power supply before carrying out any installation

procedure. Connect the machine to the power supply only at the end of the installation.

• The machine is not suitable for installation outdoors and/or in places exposed to

atmospheric agents (rain, direct sunlight, freeze, humid and dusty location, etc.).

• Do not install the machine over 2000 meters above sea level.

• Make sure that the floor where you install the machine is flat, stable, heat resistant and

clean.

• If available, make sure to install the accessory to fix the machine to the floor.

• Use a ladder with suitable protection for work on machines with high accessibility.

A.6 Water connection

• The plumbing connections must be carried out by a specialised personnel.

• The machine is to be connected to the water mains using the new supplied hose-sets.

Do not use old hose sets.

• Always use a new set of joints if you remove and re-install the water inlet pipe to the

machine.

• Before connection to new pipes, pipes not used for a long time, where repair work has

been carried out or new devices fitted (water meters, etc.), let the water flow until it is

clean and clear.

• The operating water pressure (minimum and maximum) must be between:

– 1.8 bar [180 kPa] and 3 bar [300 kPa];

• Make sure that there are no visible water leaks during and after the first use of the

machine.

• Install an approved dual check valve upstream according to the regulation of the

installation country.

A.7 Electrical connection

• Work on the electrical systems must only be carried out by a specialised personnel.

• Make sure that the electrical information on the rating plate agrees with the power supply.

• Make sure to install the machine in accordance with the safety regulations and local

laws of the country where used.

• If the power cable is damaged it must be replaced by the Customer Care Service or in

any case by specialised personnel, in order to prevent any risk.

• The machine must be correctly earthed. The manufacturer is not responsible for the

consequences of an inadequate earthing system.

• If present, connected the machine to the equipotential protection circuit .

• To protect the power supply of the machine against short circuits and/or overloads,

install a thermal fuse or a suitable automatic thermal magnetic circuit breaker, ADS

(Automatic Disconnection of Supply).

• To protect the power supply of the machine against current leakages, install a high-

sensitivity manual reset RCD (Residual Current Device), suitable for overvoltage

category III.

• For protection against indirect contacts (depending on the type of supply provided for

and connection of earths to the equipotential protection circuit ) refer to point 6.3.3 of

EN 60204-1 (IEC 60204-1) with the use of protection devices that ensure automatic cut-

off of the supply in case of isolation fault in the TN or TT systems or, for IT systems, the

use of isolation controllers or differential current protection devices to activate automatic

power disconnection (an isolation controller must be provided for indicating a possible

first earth fault of a live part, unless a protection device is supplied for switching off the

power in case of a such a fault. This device must activate an acoustic and/or visual

signal which must continue for the entire duration of the fault). For example: in a TT

system, a residual current device with cut-in current (e.g. 30 mA) coordinated with the

earthing system of the building where the machine is located must be installed ahead of

the supply.

• On all rack type dishwasher, make sure to install an emergency switch at the infeed and

outfeed. For all additional modules installed later, move the emergency switch at the

ends of the equipment.

• For all the additional modules installed later, make sure that the power cable supply is

properly sized.

A.8 Machine cleaning and maintenance

• Refer to “A.3 Personal protection equipment“ for suitable personal protection equipment.

• Put the machine in safe conditions before starting any maintenance operation.

Disconnect the machine from the power supply and carefully unplug the power supply

cable, if present.

• Depending on the model and type of electric connection, during maintenance operations,

the cable and plug must be kept in a visible position by the operator carrying out the work.

• Do not touch the machine with wet hands or feet or when barefoot.

• Do not remove the safety guards.

• Use a ladder with suitable protection for work on machines with high accessibility.

• Respect the requirements for the various routine and extraordinary maintenance

operations. Non compliance with the instructions can create risks for personnel.

• Contact with chemical substances (e.g. detergent, rinse aid, scale remover, etc.) without

taking appropriate safety precautions (e.g. personal protection equipment) can involve

exposure to chemical risk and possible damage to health. Therefore always refer to the

safety cards and labels on the products used.

Repair and extraordinary maintenance

• Repair and extraordinary maintenance have to be carried out by specialised authorised

personnel. The manufacturer declines any liability for any failure or damage caused by

the intervention of an unauthorized technician by the Manufacturer and the original

manufacturer warranty will be invalidated.

A.9 Service

• Only original spare parts can ensure the safety standards of the appliance.

A.10 Disposal of packing

• Dispose of each packaging items respecting the current regulation in the country of

installation.

A.11 Machine disposal

• Work on the electrical equipment must only be carried out by a specialised personnel,

with the power supply disconnected.

• Dismantling operations must be carried out by specialised personnel.

• Make the appliance unusable by removing the power cable and any compartment

closing devices, to prevent the possibility of someone becoming trapped inside.

• Refer to “A.3 Personal protection equipment“ for suitable personal protection equipment.

• When scrapping the machine, the “CE“ marking, this manual and other documents

concerning the appliance must be destroyed.

IMPORTANT

Save these instructions carefully for further consultation by the various

operators.

B GENERAL INFORMATION

B.1 Introduction

Given below is some information regarding the intended use of

this appliance, its testing, and a description of the symbols

used (that identifies the type of warning), the definitions of

terms used in the manual and useful information for the

appliance user.

B.2 Definitions

Listed below are the definitions of the main terms used in the

manual. It is advisable to read them carefully before use.

Operator machine installation, adjustment, use,

maintenance, cleaning, repair and trans-

port personnel.

Manufacturer Electrolux Professional SpA or any other

service centre authorised by Electrolux

Professional SpA.

Operator for

normal

machine use

an operator who has been informed and

trained regarding the tasks and hazards

involved in normal machine use.

Customer

Care service

or specialised

technician

an operator instructed/trained by the

Manufacturer and who, based on his

professional and specific training, experi-

ence and knowledge of the accident-

prevention regulations, is able to appraise

the operations to be carried out on the

machine and recognise and prevent any

risks. His professionalism covers the

mechanical, electrotechnical and elec-

tronics fields.

Danger source of possible injury or harm to health.

Hazardous

situation

any situation where an operator is

exposed to one or more hazards.

Risk a combination of probabilities and risks of

injury or harm to health in a hazardous

situation.

Protection

devices

safety measures consisting of the use of

specific technical means (guards and

safety devices) for protecting operators

against risks.

Guard an element of a machine used in a specific

way to provide protection by means of a

physical barrier.

Safety device a device (other than a guard) that elimi-

nates or reduces the risk; it can be used

alone or in combination with a guard.

Customer the person who purchased the machine

and/or who manages and uses it (e. g.

company, entrepreneur, firm).

Emergency

stop device

a group of components intended for the

emergency stop function; the device is

activated with a single action and pre-

vents or reduces damage to persons/

machines/property/animals.

Electrocution an accidental discharge of electric current

on a human body.

B.3 Machine and Manufacturer’s

identification data

A reproduction of the marking or dataplate on the machine is

given below:

The dataplate gives the product identification and technical data;

listed below is the meaning of the various information given on it.

F.Mod. factory description of product

Comm.Model commercial description

PNC production number code

Ser.No. serial number

230V 1N~ power supply voltage

—electric convertibility (depending

on the model)

Hz power supply frequency

Max – kW max. power

Nominal – kW nominal power

IPX4 dust and water protection rating

2017F.Mod.

Comm. Model: PNC Ser.Nr. EL Hz Max 12.9 W Nominal 9.9 W

6.9 WMin

Electrolux Professional spa - Viale Treviso, 15 - 33170 Pordenone (Italy)

Type ref.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Electrolux Professional Waschmaschine Handbücher

Electrolux Professional

Electrolux Professional Clarus Vibe WH6-7 Bedienungsanleitung

Electrolux Professional

Electrolux Professional WB6-20 Bedienungsanleitung

Electrolux Professional

Electrolux Professional Compass Pro WH6-7 Bedienungsanleitung

Electrolux Professional

Electrolux Professional Compass Pro WH6-8 Bedienungsanleitung

Electrolux Professional

Electrolux Professional WE 170 P Bedienungsanleitung

Electrolux Professional

Electrolux Professional myPRO XL W1100P Bedienungsanleitung

Electrolux Professional

Electrolux Professional WE 170 V Bedienungsanleitung

Electrolux Professional

Electrolux Professional Compass Pro WN6-9 Bedienungsanleitung

Electrolux Professional

Electrolux Professional WP4 700H Bedienungsanleitung

Electrolux Professional

Electrolux Professional WH6-14LAG Bedienungsanleitung

Electrolux Professional

Electrolux Professional Compass Pro WS6-9 Bedienungsanleitung

Electrolux Professional

Electrolux Professional WE170PP Bedienungsanleitung

Electrolux Professional

Electrolux Professional Compass Pro WB6-13 Bedienungsanleitung

Electrolux Professional

Electrolux Professional WP4700H Leitfaden

Electrolux Professional

Electrolux Professional WB6-20 Bedienungsanleitung

Electrolux Professional

Electrolux Professional WB5130H Bedienungsanleitung

Electrolux Professional

Electrolux Professional WH5 Bedienungsanleitung

Electrolux Professional

Electrolux Professional W575N Bedienungsanleitung

Electrolux Professional

Electrolux Professional ZPPWES Bedienungsanleitung

Electrolux Professional

Electrolux Professional WE170V Bedienungsanleitung

Electrolux Professional

Electrolux Professional WE170P Bedienungsanleitung

Electrolux Professional

Electrolux Professional Wascator FOM71 CLS Bedienungsanleitung

Electrolux Professional

Electrolux Professional WH6-20LAC Bedienungsanleitung

Electrolux Professional

Electrolux Professional myPRO XL WE1100P Bedienungsanleitung

Beliebte Waschmaschine Handbücher anderer Marken

Tricity Bendix

Tricity Bendix AW 1000 W Produkthandbuch

Panasonic

Panasonic NA-F60L5WRB Bedienungsanleitung

GE WSLP1500 Handbuch

Electrolux

Electrolux EWF1284EDW Bedienungsanleitung

Bosch

Bosch WAN2829BSN Bedienungsanleitung

LG TV2516DV3B Bedienungsanleitung

LG TH2517DSAV Bedienungsanleitung

VESTEL

VESTEL CMH-XL 7510 TE Bedienungsanleitung

AEG

AEG 74335 Bedienungsanleitung

Johnson

Johnson JWF721A Bedienungsanleitung

Beko

Beko WTE7604XLW0 Bedienungsanleitung

Danby

Danby DTT100A1WDB Montageanleitung

Amica

Amica WA 14 Ex Bedienungsanleitung

Daewoo

Daewoo DWD-F1222 Bedienungsanleitung

Bosch

Bosch WAS28461AU Bedienungsanleitung

Miele

Miele PW 6080 Vario Bedienungsanleitung

Finlux

Finlux FLX108CF220 Bedienungsanleitung

Whirlpool

Whirlpool 3LBR5132AN0 Bedienungsanleitung
