Electrolux LFD619Y Bedienungsanleitung

LFD619Y

EN Cooker Hood User Manual

CONTENTS

1. SAFETY INFORMATION AND INSTALLATION................................................ 2

2. BEFORE FIRST USE......................................................................................... 3

3. PRODUCT DESCRIPTION................................................................................ 3

4. DAILY USE......................................................................................................... 3

5. CARE AND CLEANING......................................................................................5

6. TROUBLESHOOTING........................................................................................7

7. ENVIRONMENTAL CONCERNS....................................................................... 7

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can

be safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website to:

Get usage advice, brochures, trouble shooter, service and repair information:

www.electrolux.com/support

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

1. SAFETY INFORMATION AND INSTALLATION

WARNING!

Refer to the separate

Installation Instructions

booklet for Safety

Information and Installation.

Read carefully the Safety

chapters before any use or

maintenance of the

appliance.

www.electrolux.com2

2. BEFORE FIRST USE

WARNING!

Refer to Safety chapters.

2.1 Closing the glass

When the slider do not open and the

panel blinks white the glass inside the

slider is loose. The glass must be closed

in order to open the slider and operate

the appliance.

1. Reach to the front side of the

appliance inside the furniture.

2. Open the small cover in front and

make sure that the glass inside is not

loosened.

Gently push the glass if it is loosened to

close it.

3. Close the cover in front of the

appliance.

The appliance is now ready to use.

3. PRODUCT DESCRIPTION

3.1 Control panel overview

1 2 3 4 5 6 7 8

1On / Off, Open / Close

2First motor speed

3Second motor speed

4Third motor speed

5Maximum motor speed

6Breeze function

7Filter notification

8Lamp

4. DAILY USE

4.1 Opening and closing the

hood

WARNING!

Risk of injury or damage to

the appliance! Do not put

any cookware or other

objects on and under the

slider.

ENGLISH 3

1. Press and hold until the slider

start to open.

The appliance turns on and slider goes

up.

2. To close the slider and turn off the

appliance press and hold until

slider starts to go down.

Use the hood only when slider stops and

is fully open.

4.2 Using the hood

Check the recommended speed

according to the table below.

While heating up food, cooking with covered pots.

While cooking with covered pots on multiple cook‐

ing zones or burners, gentle frying.

While boiling and frying big quantities of food with‐

out a lid, cooking on multiple cooking zones or

burners.

While boiling and frying big quantities of food with‐

out a lid, big humidity.

Refreshes the air in kitchen after cooking at a very

low noise level. It can be activated and de-activa‐

ted by touching the symbol. The function turns off

automatically after 60 minutes. Use after cooking

only.

It is recommended to leave

the hood operating for

approximately 15 minutes

after cooking.

The control Panel is a

sensor field. Touch the

symbols for 1 second to

activate the functions.

To operate the hood when the hood is

open:

1. Turn on the appliance by pressing

the symbol.

You can now activate the functions.

2. To activate the function touch the

symbol.

3. If needed, touch the light symbol

to illuminate the cooking surface.

To turn off the appliance press the

symbol again.

4.3 Activating Maximum Motor

Speed

When you press the button , the

Maximum Motor Speed starts to operate

for 8 minutes. After that time, the

appliance returns to its previous speed

settings.

When the function is turned

on, additional touch on the

button does not have any

effects.

www.electrolux.com4

4.4 Filter notification

Filter alarm reminds to change or clean

the charcoal filter and clean the grease

filter. The filter indicator is turned on

for 30 seconds if the grease filter must

be cleaned. The filter indicator flashes

for 30 seconds if the charcoal filter must

be replaced or cleaned.

Refer to cleaning the grease

filter in care and cleaning

chapter.

Refer to cleaning the

charcoal filter or replacing

the charcoal filter in care and

cleaning chapter.

To reset the function touch for 3

seconds.

To activate or deactivate function

(only for charcoal filter):

1. Switch on the control panel.

2. Make sure that the icons are turned

white.

3. To activate function touch for 3

seconds.

If the function is activated, the filter icon

flashes five times.

4. To deactivate function touch for 3

seconds.

If the function is deactivated, the filter

icon flashes three times.

5. CARE AND CLEANING

5.1 Notes on cleaning

Cleaning

Agents

Do not use abrasive detergents and brushes.

Clean the surface of the appliance with a soft cloth with warm water

and a mild detergent.

After cooking some parts of appliance can get hot. To avoid stains

appliance must be cooled down and dried with clean cloth or paper

towels.

Clean stains with a mild detergent.

Keep the hood

clean

Clean the appliance and grease filters each month. Clean the inte‐

rior and grease filters carefully from fat. Fat accumulation or other

residue may cause fire.

Follow the instructions for cleaning the accessories when filter noti‐

fication is on. Refer to Filter notification in daily use chapter.

Grease filters can be washed in a dishwasher.

The dishwasher must be set to a low temperature and a short cy‐

cle. The grease filter may discolour, it has no influence on the per‐

formance of the appliance.

Charcoal filter

The time of saturation of the charcoal filter varies depending on the

type of cooking and the regularity of cleaning the grease filter.

Charcoal filter is washable, clean or regenerate the filter after ap‐

proximately every two months. Refer to leaflet included in the ac‐

cessory.

ENGLISH 5

5.2 Cleaning the grease filter

Filters are mounted with the use of clips

and pins on the opposite side.

To clean the filter:

1. Pull the cover to open it.

Be careful! To prevent

accidental collapse, the

cover has two hooks on the

sides.

2. Press the handle of the mounting clip

on the filter panel underneath the

hood (1).

3. Slightly tilt the front of the filter

downwards (2), then pull.

Repeat the first two steps for all filters.

4. Clean the filters using a sponge with

non abrasive detergents or in a

dishwasher.

The dishwasher must be set

to a low temperature and a

short cycle. The grease filter

may discolour, it has no

influence on the

performance of the

appliance.

5. To mount the filters back follow the

first two steps in reverse order.

Repeat the steps for all filters if

applicable.

After closing the cover, the control panel

turns white. The appliance is ready to

use.

5.3 Cleaning the charcoal filter

To remove the filter:

1. Remove the grease filters from the

appliance.

Refer to "Cleaning the grease filter" in

this chapter.

2. Remove the clips holding the filter

bed (1), then the filter bed (2).

3. Wash the filter bed in hot water

without using detergent or use a

dishwasher.

Set the dishwasher without

using rinse aids or any other

detergents. The dishwasher

cannot be filled with dishes.

4. Leave the filter bed to dry or use an

oven.

WARNING!

Risk of burns! Refer to

safety chapter in oven user

manual.

Set the oven for 10 minutes in the

maximum temperature of 60°C.

5. To install the filter, perform the steps

in reverse order. The filter has to be

fully dried before installing it back into

appliance.

Replace the filter bed every 2 years or

when the cloth is damaged.

www.electrolux.com6

5.4 Replacing the lamp

This appliance is supplied with a LED

lamp. This part can be replaced by a

technician only. In case of any

malfunction refer to "Service" in the

"Safety Instructions" chapter.

6. TROUBLESHOOTING

WARNING!

Refer to Safety chapters.

6.1 What to do if...

Problem Possible cause Remedy

You cannot activate the

appliance.

The appliance is not con‐

nected to a power supply

or it is connected incorrect‐

ly.

Check if the appliance is

correctly connected to the

electrical supply.

You cannot activate the

appliance.

The fuse is blown. Make sure that the fuse is

the cause of the malfunc‐

tion. If the fuse is blown

again and again, contact a

qualified electrician.

You cannot open the slider

and the panel blinks red

and white.

The glass inside the appli‐

ance is opened.

Close the glass. Refer to

"Closing the glass" in the

"Before first use" chapter.

The lamp does not oper‐

ate.

The lamp is defective. Replace the lamp. Refer to

the "Care and Cleaning"

chapter.

The appliance does not

absorb enough vapours.

The motor speed is not ad‐

equate to the appearing

vapours.

Change the speed of the

motor.

The filter alarm indicator

is on.

The filter alarm is on. The

grease filter must be

cleaned or the charcoal fil‐

ter must be replaced or

cleaned.

Refer to the filter notifica‐

tion in "Daily use" chapter.

7. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol .

Put the packaging in relevant containers

to recycle it. Help protect the

environment and human health by

recycling waste of electrical and

electronic appliances. Do not dispose of

appliances marked with the symbol

with the household waste. Return the

product to your local recycling facility or

contact your municipal office.

ENGLISH 7

www.electrolux.com/shop

867351206-D-192022

Andere Handbücher für LFD619Y

Inhaltsverzeichnis

Andere Electrolux Dunstabzugshaube Handbücher

Electrolux

Electrolux CH 950 Bedienungsanleitung

Electrolux

Electrolux WRJ903U Bedienungsanleitung

Electrolux

Electrolux EFP 629 Bedienungsanleitung

Electrolux

Electrolux FHWC3055LSA Bedienungsanleitung

Electrolux

Electrolux EFT 7466 Bedienungsanleitung

Electrolux

Electrolux CHDL 4150 Technisches Datenblatt

Electrolux

Electrolux DAK5530WE Bedienungsanleitung

Electrolux

Electrolux ICON RH36WCT6GS Bedienungsanleitung

Electrolux

Electrolux 316488524 Bedienungsanleitung

Electrolux

Electrolux MCH 660 Bedienungsanleitung

Electrolux

Electrolux LFG616W Bedienungsanleitung

Electrolux

Electrolux EFC 6420 Bedienungsanleitung

Electrolux

Electrolux DCE3960HM Bedienungsanleitung

Electrolux

Electrolux HOST11 Bedienungsanleitung

Electrolux

Electrolux LFV429Y Bedienungsanleitung

Electrolux

Electrolux RH30WC55GSA Bedienungsanleitung

Electrolux

Electrolux Icon E36WC45FSS Bedienungsanleitung

Electrolux

Electrolux Husqvarna QFC 60350 Bedienungsanleitung

Electrolux

Electrolux EFC 9461 Bedienungsanleitung

Electrolux

Electrolux RH36WC55GS Bedienungsanleitung

Electrolux

Electrolux EFC 9440 Bedienungsanleitung

Electrolux

Electrolux EFV716K Bedienungsanleitung

Electrolux

Electrolux EFA1030X Bedienungsanleitung

Electrolux

Electrolux LFP216S Bedienungsanleitung

Beliebte Dunstabzugshaube Handbücher anderer Marken

emmeti

emmeti RECUPA MED A-140 Leitfaden

Nibe

Nibe F135 Bedienungsanleitung

Kuppersberg

Kuppersberg INTRO 60 Montage- und Wartungsanleitung

Zephyr

Zephyr Spruce AK9834BS Installationsanleitung

Hisense

Hisense MH6INBG Bedienungsanleitung

Miele

Miele DA 1255 Bedienungsanleitung

Broan

Broan 46000 Bedienungsanleitung

GE Profile PV977 Originalbetriebsanleitung

FALMEC

FALMEC FFRIA24W5FS Bedienungsanleitung

Whirlpool

Whirlpool RH2600XL-1 SERIES Bedienungsanleitung

Küppersbusch

Küppersbusch DX ISLA Bedienungsanleitung

ETNA

ETNA AV360RVS Bedienungsanleitung

JUNO

JUNO JDF603E6 Bedienungsanleitung

Miele

Miele DA 6708 D Bedienungsanleitung

Tricity Bendix

Tricity Bendix LE 150 Handbuch

AEG

AEG X68163BV1 Bedienungsanleitung

AEG

AEG 125 D Bedienungsanleitung

Smeg

Smeg KSEV97X Bedienungsanleitung
