If you are unable to identify or solve the problem,contact our service centre. Before telephoning, make a note

of the model, serial number and purchase date of your machine: the Service Centre will require this information.

Contents of this user manual may be modified without informing you.

Waterisnot

visibleinthemachine?Themachine,

whichistheresultofmoderntechnology,runs

inaveryeconomicalwaywithlowwater

consumption.Performanceis

neverthelessexcellent.

Themachinemakesanunusual

noise?Themachineisfittedwithacommutator

motorwhichimprovesmachine

performance.

Possible causeProblem

Spinning starts late or the laundry

is not spun enough :

The electronic unbalance detection device has cut

in because the laundry is not evenly distributed in

the drum.The laundry is redistributed by reverse

rotation of the drum.This may happen several times

beforetheunbalancedisappearsandnormalspinning

can resume.if ,after few minutes,the laundry is still

not evenly distributed in the drum,the machine will

spin at a lower speed or will not spin.If at the end of

the programme the laundry is not spun enough,

redistriute the load manually and select the spin

programme.

The door can not open : The program is still running and the drum is turning.

The door lock has not yet released.

The water level is above the bottom edge of the door.

The machine is heating the water, and the water

temperature is higher than 55

The door can only be opened when the relevant light

has gone out.

221

Something not working?

Problems which you can resolve yourself

During machine operation it is possible that one of the End light starts to flash:

Possible causeProblem

The door is not firmly closed. E40

The machine is not plugged in or there is no power at

the socket.

The main fuse or the fuse in the plug has blown.

The START/PAUSE button has not been pressed.

The DELAY option has been selected.

The machine does not start up:

The machine fills them empties

immediately:

The machine does not fill:

The water tap is closed. E10

The inlet hose is squashed or kinked. E10

The filter in the inlet hose is blocked. E10

The door is not properly closed. E40

The end of the drain hose is too low. Refer to relevant

paragraph in drainage section.

The machine does not empty and/or

doesnotspin:

There is water on the floor:

Unsatisfactory washing results:

The drain hose is squashed or kinked. E20

The drain pump is clogged. E20

The laundry is not evenly distributed in the drum.

The RINSE HOLD or NIGHT CYCLE option has been

selected.

Too much detergent or unsuitable detergent (creates

too much foam) has been used.

Check whether there are any leaks from one of the

inlet hose fittings. It is not always easy to see this as

the water runs down the hose ; check to see if it is

damp.

The drain hose is damaged.

Check that the filter has been fastened.

Too little detergent or unsuitable detergent has Been

used.

Stubborn stains have not been treated prior to washing.

The correct program or temperature was not selected.

Excessive laundry load.

The transit bolts and packing have not been removed.

The support feet have not been adjusted.

The laundry in drum has not been evenly distributed.

Too little laundry is washed.

Once the problem has been eliminated, press the START/PAUSE button to restart the programme. If

after all checks, the problem persists, contact your local Service Centre.

The machine vibrates or is noisy:

E10:problem with the water supply

E20: problem with the water draining

E40:door open

21-22

15 -17

Screw the pump fully in.

Close the pump door. If the machine is installed in a place where the tem-

perature could drop below 0 , proceed as follows:

7. Frost precautions

Remove the plug from the socket.

Close the water tap and unscrew the water inlet hose

from the tap.

Place the end of the emergency emptying hose and

that of the inlet hose in a bowl placed on the floor

and let water drain out.

Screw the water inlet hose back on and reposition the

emergency emptying hose after having put the cap

on again.

By doing this, any water remaining in the machine is

removed, avoiding the formation of ice and,

consequently, breakage of the affected parts.When

you use the machine again, make sure that the ambi-

ent temperature is above 0 .

Remove any objects from the pump impeller by

rotating it.

Put the cap back on the emergency emptying hose

and place the latter back in its seat.

Turn off the water tap.

Take off the inlet hose from water tap. Drain water in

this hose.

Unscrew the hose from the inlet valve.

Clean the filter with a stiff brush.

Put on the hose back onto the tap and the inlet

valve.

5. Water inlet filter

If you notice that the machine is taking longer to fill,

check that the filter in the water inlet valve is not

blocked:

Clean the pump if necessary as previously described.

Replace the emergency emptying hose in its seat

after having plugged it.

Screw the pump again and close the door.

If the water is not discharged , proceed as follows to

empty out the machine:

6. Emergency emptying out

Pull out the plug from the power socket;

Close the water tap;

If necessary, wait until the water has cooled down;

Open the pump door;

Place a bowl on the floor and place the end of the

emergency emptying hose into the bowl. Remove

its cap. The water should drain by gravity into the

bowl.Whe the bowl is full,put the cap back on the

hose. Empty the bowl. Repeat the procedure until

water stops flowing ou;

85 cm

60 cm

49 cm

5 kg

2 kg

1 kg

2 kg

1000

1200

EWS1050

EWS1250

EWS1250Z

0.05MPa

0.8MPa

AC 220V/50Hz

2000 W

10A

Maintenance

Check from time to time the door seal and eliminate

eventual possible objects that could be trapped in the

fold.

1. Door seal

After a while, detergents and fabric softeners leave

deposits in the drawer.

Clean the drawer from time to time by rinsing it under

a running tap. To remove the drawer from the machine,

press the button in the rear left-hand corner.To facili-

tate cleaning, the top part of the additive compart-

ment can be removed.

3. Detergent dispenser drawer

Clean the outside of the machine with warm water and

a neutral, non-abrasive household detergent. Rinse

with clean water and dry with a soft cloth.

2. Bodywork

Important: do not use methylated spirits, solvents or

similar products to clean the bodywork.

Detergent can also accumulate inside the drawer

recess: clean it with an old toothbrush. Refit the drawer

after cleaning.

The drain pump should be inspected if

4. Drain pump

The machine does not empty and/or spin.

The machine makes an unusual noise during draining

due to objects such as safety pins,coins etc.

blocking the pump.

Disconnect the appliance.

If necessary wait until the water has cooled down.

Open the pump door.

Place a container close to the pump to collect any

spillage.

Release the emergency emptying hose, place it in

the container and remove its cap.

When no more water comes out, unscrew the pump

and remove it. Always keep a rag nearby to dry up

spillage of water when removing the pump.

Proceed as follows

Programme table

Type of laundry

and symbols on

labels

Programme/

temperature Description of

programme Available options Max load

Wash at 60-30

or cold

three rinses

long spin

Coloured cotton:

e.g.shirts,blouse

underwear towels

household linen

Cottons

60-30

cold 5Kg

Wash at 60-30 ,

or cold

three rinses

Short spin

Synthetic

fabricand

blends:

e.g.shirts,blouse,

underwear

Synthetic

60-30

cold 2Kg

Wash at 40-30 ,

or cold

three rinses

Short spin

Delicate fabric

e.g. acrylic fabric,

viscose, polyester,

synthetic blends

Delicates

40-30

cold 2Kg

Wash at 40-30 ,

or cold

three rinses

Short spin

Wool,hand

wash

Wool/Hand

wash

40 - 30

cold

1Kg

Wash at 30 ,

or cold

three rinses

Short spin

Silk

silk

cold 2Kg

Spin speed

Rinse hold

Night cycle

Economy

Super Quick wash

Prewash

Anti-allergic rinse

Wash at 60-95

three rinses

long spin

white cotton:

e.g. : work clothes,

sheet,household

linen, table cloth

Cottons

60-95 5Kg

60 95

3040

Spin speed

Rinse hold

Night cycle

Economy

Super Quick wash

Prewash

Anti-allergic rinse

Spin speed

Rinse hold

Night cycle

Economy

Super Quick wash

Prewash

Anti-allergic rinse

Spin speed

Rinse hold

Night cycle

Super Quick wash

Prewash

Anti-allergic rinse

Spin speed

Rinse hold

Night cycle

40 30

Spin speed

Rinse hold

Night cycle

BAB

C B

617

12. How to cancel a programme dur-

ing its cycle

To cancel a programme that is being carried out, first

pause the washing machine by pressing theSTART/

PAUSE button, then press the SKIP RESET button

repeatedly, until the display shows three blinking

dashes.

13.How to Open the door during the

cycle of a programme

You can open the door, after having set the washing

machine to PAUSE, provided the following conditions

exist:

The washing machine is not in the heating phase

beyond 55°C;

The level of the water is not high;

The drum is not turning.

If these requirements are met, when you pause the

washing machine, the door can be opened instantly.

Should it not be possible to open the door, and should

it be absolutely necessary to do so, switch the ma-

chine off by pressing the ON/OFF button. After ap-

proximately 3 minutes, you can open the door instantly.

Pay attention to the level and temperature of the

water in the washing machine!

When you close the door and press the ON/OFF but-

ton again, the washing machine will resume the

programmefromthepointwhere it had been interrupted.

14. End of programme

If you had selected the RINSE HOLDor NIGHT CYLCE

option , the light of the START/PAUSE button goes out,

the zero on the display begins to flash, the door is

locked and RINSE HOLD or NIGHT CYCLE light re-

mains lit.

When the programme has been completed, a blinking

zero appears on the display and the audible signal is

given.

Press the SKIP RESET button repeatedly to erase

the programme that has just been carried out. If

you omit to do this, the next time you switch the

washing machine on, the blinking zero will ap-

pear on the display and you will hear the audible

signal.

Press the ON/OFF button to switch the machine off.

The relevant light will go out. Remove the laundry

from the washing machine. Check whether the drum is

completely empty, by rotating it with your hand. The

purpose of this is to prevent any items of laundry

from remaining accidentally in the drum, where they

might get damaged in a subsequent wash (e.g. by

shrinking) or bleed colour into another load of laundry.

We advise you to close the water supply tap and

disconnect the plug from the socket. Leave the door

ajar in order to air the washing machine.

60cm

220V/50Hz

60 90cm

At the end of the programme, the washing machine

stops automatically, gives an audible signal, and dis-

plays a blinking zero.

16 7

7. Select the SPIN SPEED or the RINSE

HOLDoption

Press the SPIN SPEED button repeatedly, in order to

select the desired spin speed or the RINSE HOLD

option. The relevant light will light up. If you select the

RINSE HOLD option, the machine will stop at the end

of the programme with the water still in the tub.

8. Select the desired options

If your laundry is very dirty or has stubborn stains, it

may be advisable to select the PREWASH, ANTI-

ALLERGIC RINSE option. Press the OPTIONS button

so as to cause one or both of the lights to light up. If

your laundry is only slightly soiled, depress ECONOMY

or SUPER QUICK WASH button. The relevant light

illuminates.

9.Select the DELAY START

delay. The selected delay time value (up to 23 hours)

will appear on the display for 3 seconds, then the

duration of the programme will appear again.

10. Start the programme

Press the START/PAUSE button. The relevant light will

stop flashing and only the light relevant to the phase

that is in progress will remain lit. If you have chosen a

delayed start, the washing machine will begin the count-

down The display will show the duration of the

programme or the selected delay.

Important!

Every programme has its limited spin speed in order to

preventing laundry from being spoiled,so it’s normal

that some speed can not be chosed.

Important!

Every programme has its limited temperature in order

to preventing laundry from being spoiled,so it’s normal

that some temperature can not be chosed.

Before you start the programme, if you wish the

starting to be delayed, press the DELAYSTARTbutton

repeatedly, or keep it pressed, to select the desired

11. How to change a programme dur-

ing its cycle

PAUSE the machine by pressing the START/PAUSE

button;

Press the SKIP RESET button repeatedly, until only

the DRAIN light remains lit;

Press the START/PAUSE button again.

Before you make any change, you must pause the

washing machine by pressing the START/PAUSE

button. It is possible to change any phase before the

programme carries it out.

Changing the type of fabric or temperature is possible,

obviously, only during the washing phase.

If it is necessary to drain the water in order to change

the programme in progress,proceed as follows:

When the water has been drained, the display shows a

blinking zero. You may now select a new programme

and press the START/PAUSE button to start it.

Operating sequence.

1. Place the laundry in drum

Open the door.

Place the laundry in drum, one item at a time,shaking

them out as much as possible.

Close the door.

2. Measure out the detergent

Pull out the dispenser drawer until it stops. Measure

out the amount of detergent recommended by the

manufacturer in a graduated cup and pour it into the

main wash compartment.

If you wish to carry out the prewash, pour detergent

into the appropriate compartment marked.

3. Measure out the additives

If required, pour fabric softener into the compartment

marked, without exceeding the MAX mark.6. Select temperature

4. Switch the machine on

5. Select the desired programme/

fabric

Press the FABRICS button repeatedly, in order to

select the desired programme/fabric. The relevant light

will light up. The lights relevant to the phases that form

the programme will light up. The display will show the

duration of the selected programme, calculated on the

basis of the maximum load for each type of fabric.

The light of the START/PAUSE button will start flashing.

If the load of laundry to be washed is small, at the

beginning of the cycle the display will still indicate the

duration relevant to the maximum load. The duration

value will be gradually adjusted during the execution of

the cycle.

Press the TEMPERATURE button if you wish to select

a temperature value different from the one proposed

by the washing machine. The relevant light will light up.

To switch the machine on, press the ON/OFF button :

the mains-on light comes on. The display will show

three blinking dashes or a blinking zero.

245

68910111 3 12

Before washing your first load of laundry we recom-

mend that you run a cotton cycle at 60 with the

machine empty, in order to remove any manufac-

turing residue from the drum and tub.

6-7

These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry.

International wash code symbols

Energetic

wash Max. wash

temperature

95 C

Max. wash

temperature

60 C

Max. wash

temperature

40 C

Max. wash

temperature

30 CHand wash Do not

wash

at all

Delicate wash

Bleaching Bleach in cold water Do not bleach

lroning Do not ironLukewarm iron

max 110 C

Hot iron

max 200 CWarm iron

max 150 C

Dry cleaning Do not

dry clean

Dry cleaning

in petrol,

pure alcohol

and R 113

Dry cleaning

in all solvents Dry cleaning in

perchlorethylene,

petrol, pure alcohol,

R 111 & R 113

Drying Do not

tumble dry

Tumble dryFlat On the line On clothes

hanger

high

temperature

low

temperature

4095

cI -

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Electrolux Waschmaschine Handbücher

Electrolux

Electrolux EWF 12480 W Bedienungsanleitung

Electrolux

Electrolux EWF 1476 EDU Bedienungsanleitung

Electrolux

Electrolux EWT655WN Bedienungsanleitung

Electrolux

Electrolux EWF 1294BW Bedienungsanleitung

Electrolux

Electrolux EWH 147313 W Bedienungsanleitung

Electrolux

Electrolux EWT 10420 W Bedienungsanleitung

Electrolux

Electrolux W365H Bedienungsanleitung

Electrolux

Electrolux UFW 47 K 9161 Bedienungsanleitung

Electrolux

Electrolux EWT 1362HDS Bedienungsanleitung

Electrolux

Electrolux W4240H Bedienungsanleitung

Electrolux

Electrolux EW2F672S Bedienungsanleitung

Electrolux

Electrolux FOM 71 CLS Bedienungsanleitung

Electrolux

Electrolux EN2F4862BF Bedienungsanleitung

Electrolux

Electrolux WA SL1 E100 Bedienungsanleitung

Electrolux

Electrolux EWF 888 Bedienungsanleitung

Electrolux

Electrolux EWN 14991 K Bedienungsanleitung

Electrolux

Electrolux EWS 1054 EDU Bedienungsanleitung

Electrolux

Electrolux EW6S426BI Bedienungsanleitung

Electrolux

Electrolux EWFLW65IRR - 27" Front-Load Washer Bedienungsanleitung

Electrolux

Electrolux EWS 126540 W Bedienungsanleitung

Electrolux

Electrolux EWP10742 Bedienungsanleitung

Electrolux

Electrolux WF 1029 Bedienungsanleitung

Electrolux

Electrolux MKTG15DNAWB Bedienungsanleitung

Electrolux

Electrolux EWT 0862 EOW Bedienungsanleitung

Beliebte Waschmaschine Handbücher anderer Marken

Tricity Bendix

Tricity Bendix AW 1000 W Produkthandbuch

Panasonic

Panasonic NA-F60L5WRB Bedienungsanleitung

GE WSLP1500 Handbuch

Bosch

Bosch WAN2829BSN Bedienungsanleitung

LG TV2516DV3B Bedienungsanleitung

LG TH2517DSAV Bedienungsanleitung

VESTEL

VESTEL CMH-XL 7510 TE Bedienungsanleitung

AEG

AEG 74335 Bedienungsanleitung

Johnson

Johnson JWF721A Bedienungsanleitung

Beko

Beko WTE7604XLW0 Bedienungsanleitung

Danby

Danby DTT100A1WDB Montageanleitung

Amica

Amica WA 14 Ex Bedienungsanleitung

Daewoo

Daewoo DWD-F1222 Bedienungsanleitung

Bosch

Bosch WAS28461AU Bedienungsanleitung

Miele

Miele PW 6080 Vario Bedienungsanleitung

Finlux

Finlux FLX108CF220 Bedienungsanleitung

Whirlpool

Whirlpool 3LBR5132AN0 Bedienungsanleitung

Beko

Beko WKB 51231 PTMA Bedienungsanleitung
