EWS 11056 EDU

EWS 11256 EDU

................................................ .............................................

EN WASHING MACHINE USER MANUAL

CONTENTS

1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

4. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

5. WASHING PROGRAMMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

6. CONSUMPTION VALUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

7. OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

8. BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

9. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

10. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

11. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

12. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

13. TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it

decades of professional experience and innovation. Ingenious and stylish, it has been designed

with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great

results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.electrolux.com/productregistration

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts.

When contacting Service, ensure that you have the following data available.

The information can be found on the rating plate. Model, PNC, Serial Number.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

2www.electrolux.com

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible if an incorrect installation and use causes in-

juries and damages. Always keep the instructions with

the appliance for future reference.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or in-

struction concerning use of the appliance in a safe way

and understand the hazards involved.

• Do not let children play with the appliance.

• Keep all packaging away from children.

• Keep all detergents away from children.

• Keep children and pets away from the appliance door

when it is open.

• If the appliance has a child safety device, we recom-

mend you activate it.

• Cleaning and user maintenance shall not be made by

children without supervision.

1.2 General Safety

• Before maintenance, deactivate the appliance and dis-

connect the mains plug from the mains socket.

• Do not change the specification of this appliance.

• Obey the maximum load volume of 5 kg (refer to the

“Programme chart” chapter).

ENGLISH 3

• If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

• The operating water pressure (minimum and maximum)

must be between 0,5 bar (0,05 MPa) and 8 bar (0,8

MPa)

• The ventilation openings in the base (if applicable) must

not be obstructed by a carpet.

• The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging and the

transit bolts.

• Keep the transit bolts. When you move

the appliance again you must block the

drum.

• Do not install or use a damaged appli-

ance.

• Do not install or use the appliance

where the temperature is less than 0 °C

or where it is exposed to the weather.

• Obey the installation instruction sup-

plied with the appliance.

• Make sure that the floor where you in-

stall the appliance is flat, stable, heat

resistant and clean.

• Do not install the appliance where the

appliance door can not be fully opened.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Make sure that there is air circulation

between the appliance and the floor.

• Adjust the feet to have the necessary

space between the appliance and the

carpet.

Electrical connection

WARNING!

Risk of fire and electrical shock.

• The appliance must be earthed.

• Make sure that the electrical information

on the rating plate agrees with the pow-

er supply. If not, contact an electrician.

• Always use a correctly installed shock-

proof socket.

• Do not use multi-plug adapters and ex-

tension cables.

• Make sure not to cause damage to the

mains plug and to the mains cable.

Should the appliance power supply ca-

ble need to be replaced, this must be

carried out by our Service Centre.

• Connect the mains plug to the mains

socket only at the end of the installa-

tion. Make sure that there is access to

the mains plug after the installation.

• Do not pull the mains cable to discon-

nect the appliance. Always pull the

mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

• This appliance complies with the E.E.C.

Directives.

4www.electrolux.com

Water connection

• Make sure not to cause damage to the

water hoses.

• The appliance is to be connected to the

water mains using the new supplied

hose-sets. Old hose sets must not be

reused.

• Before you connect the appliance to

new pipes or pipes not used for a long

time, let the water flow until it is clean.

• The first time you use the appliance,

make sure that there is no leakage.

2.2 Use

WARNING!

Risk of injury, electrical shock, fire,

burns or damage to the appliance.

• Use this appliance in a household envi-

ronment.

• Do not change the specification of this

appliance.

• Obey the safety instructions on the de-

tergent packaging.

• Do not put flammable products or items

that are wet with flammable products

in, near or on the appliance.

• Do not touch the glass of the door

while a programme operates. The glass

can be hot.

• Make sure that you remove all metal

objects from the laundry.

• Do not put a container to collect possi-

ble water leakage under the appliance.

Contact the Service to ensure which

accessories can be used.

2.3 Care and Cleaning

WARNING!

Risk of injury or damage to the

appliance.

• Before maintenance, deactivate the ap-

pliance and disconnect the mains plug

from the mains socket.

• Do not use water spray and steam to

clean the appliance.

• Clean the appliance with a moist soft

cloth. Only use neutral detergents. Do

not use abrasive products, abrasive

cleaning pads, solvents or metal ob-

jects.

2.4 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent chil-

dren and pets to get closed in the ap-

pliance.

ENGLISH 5

3. PRODUCT DESCRIPTION

1 2 3

1Worktop

2Detergent dispenser

3Control panel

4Door handle

5Drain pump filter

6Rating plate

7Feet for the appliance level

4. CONTROL PANEL

53 4

1011

1 2

Temperatura

Wirowanie

Opóźnienie

Startu

Łatwe

Prasowanie Dodatkowe

Płukanie

Pranie

wstępne

Delikatne

Bawełniane

Wirowanie/

Spust wody

WŁ./WYŁ.

Wełniane/Pranie ręczne

JeansBielizna

Jedwabne

Firany

Płukanie

Szybkie

Odświeżanie

Koc

Bawełniane Eco

Syntetyczne

Time Manager Start/Pauza

1On Off button

(WŁ./WYŁ.)

2Programme knob

3Spin reduction touchpad

(Wirowanie)

4Temperature touchpad

(Temperatura)

5Display

6Prewash touchpad

(Pranie wstępne)

7Delay start touchpad

(Opóznienie Startu)

8Extra rinse touchpad

(Dodatkowe Płukanie)

9Easy iron touchpad

(Łatwe Prasowanie)

10 Start pause touchpad

(Start/ Pauza)

11 Time Manager touchpads

6www.electrolux.com

4.1 Display

A B C D

EFG

A) The Temperature area:

: Temperature indicator

: Cold water indicator

B) : Time Manager indicator.

C) The time area:

–: the programme duration

–: the delay start

–: the alarm codes

–: the message of error

–: Programme is completed.

D) : the child safety lock indicator.

E) Washing indicators:

–: the washing phase

–: the rinses phase

–: the spin phase

–: Extra rinse permanent option.

F) The spin area:

–: the Spin speed indicator

–: the No Spin indicator

–: the Rinse Hold indicator

–: the Extra Silent indicator.

G) : the Door locked indicator

5. WASHING PROGRAMMES

Programme

Temperature range

Type of load and soil

Maximum load, Maximum spin

Bawełniane

90° C - Cold

White cotton and coloured cotton (normal soil

and light soil).

5 kg, 1000 rpm (EWS11056EDU), 1200 rpm

(EWS11256EDU)

Bawełniane Eco

60° C - 40° C

White cotton and colour-fast cotton. Normal soil.

5 kg, 1000 rpm (EWS11056EDU), 1200 rpm

(EWS11256EDU)

Syntetyczne

60° C - Cold

Synthetic items or mixed fabric items. Normal

soil.

2.5 kg, 1000 rpm (EWS11056EDU), 1200 rpm

(EWS11256EDU)

ENGLISH 7

Programme

Temperature range

Type of load and soil

Maximum load, Maximum spin

Delikatne

40 °C - Cold

Delicate fabrics as acrylics, viscose, polyester

items. Normal soil.

2.5 kg, 1000 rpm (EWS11056EDU), 1200 rpm

(EWS11256EDU)

Wełniane/Pranie ręczne

40 °C – Cold

Machine washable wool, hand washable wool

and delicate fabrics with «hand washing» care

symbol.

1.5 kg, 1000 rpm (EWS11056EDU), 1200 rpm

(EWS11256EDU)

Jeans

60 °C – Cold

Items in denim and jersey. Also for items in dark

colours.

5 kg, 1000 rpm (EWS11056EDU), 1200 rpm

(EWS11256EDU)

Płukanie

Cold

To rinse and spin the laundry. All fabrics.

5 kg, 1000 rpm (EWS11056EDU), 1200 rpm

(EWS11256EDU)

Spust wody / Wiro-

wanie

To spin the laundry and to drain the water in the

drum. All fabrics.

5 kg, 1000 rpm (EWS11056EDU), 1200 rpm

(EWS11256EDU)

Bielizna

40 °C – Cold

Special programme for very delicate items, as lin-

gerie, bras and underwear etc.

1 kg, 800 rpm

Jedwabne

30 °C

Special programme for silk and mixed synthetic

items.

1 kg, 800 rpm

Firany

40 °C - Cold

Special programme for curtains. The prewash

phase activates automatically.

1 kg, 800 rpm

Koc

60° C - 30° C

Special programme for one synthetic blanket, du-

vet, bedspread and so on.

2 kg, 800 rpm

Odświeżanie

30 °C

Synthetic and delicate items. Light soil or items to

refresh.

2 kg, 800 rpm

Szybkie

30 °C

Synthetic and mixed fabric items. Light soil and

items to freshen up.

1 kg, 800 rpm

1) «Cotton Energy Saving programme» at 60° C with a load of 5 kg is the reference

programme for the data entered in the energy label, in compliance with EEC 92/75

standards.

2) Do not use any detergent for prewash phase.

8www.electrolux.com

Programme options compatibility

Programme

■ ■ ■ ■ ■ ■ ■ ■

Eco ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■

■ ■ ■ ■■

■ ■ ■

■ ■ ■ ■ ■

■ ■ ■

■ ■ ■ ■■

■■

■ ■ ■

1) If you set No Spin option the only drain phase is available.

6. CONSUMPTION VALUES

At programme start the display shows the duration programme for the maxi-

mum load capacity.

During the washing phase the programme duration is automatically calculated

and can greatly be reduced if the laundry load is lower than the maximum load

capacity (e.g. Cotton 60°C, maximum load capacity 5 kg, the programme du-

ration exceeds 2 hours; real load 1 kg, the programme duration don’t reach 1

hour).

When the appliance is calculating the real programme duration a dot blinks in

the display.

The data of this table are approximate. Different causes can change the data:

the quantity and type of laundry, the water and ambient temperature.

ENGLISH 9

Pro-

grammes

Load

(Kg)

Energy

consump-

tion (kWh)

Water con-

sumption

(litre)

Approxi-

mate pro-

gramme

duration

(minutes)

Remain-

ing mois-

ture (%)

Bawełniane

60 °C 50.83 44 125 60

/ 53

Bawełniane

40 °C 50.60 52 115 60

/ 53

Syntetyczne

40 °C 2.5 0.39 41 89 37

/ 35

Delikatne 40

°C 2.5 0.45 51 49 37

/ 35

Wełniane/

Pranie reczne

30 °C

1.5 0.40 61 40 32

/ 30

Standard cotton programmes

Standard 60

°C cotton 50.70 41 205 60

/ 53

Standard 60

°C cotton 00.65 34 151 60

/ 53

Standard 40

°C cotton 00.50 33 147 60

/ 53

Off Mode (W) Left On Mode (W)

0.48 0.48

The information given in the chart above are in compliance with the EU Commis-

sion regulation 1015/2010 implementing directive 2009/125/EC.

1) At the end of spin phase.

2) For model EWS11056EDU .

3) For model EWS11256EDU.

7. OPTIONS

7.1 Temperature

Set this option to change the default tem-

perature.

Indicator = cold water.

The indicator of the set temperature

comes on.

7.2 Spin

With this option you can decrease the de-

fault spin speed.

The display shows the indicator of the set

speed.

Additional spin options:

No Spin

• Set this option to remove all spin pha-

ses.

• Set it for very delicate fabrics.

• The rinse phase uses more water for

some washing programmes.

10 www.electrolux.com

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Electrolux Waschmaschine Handbücher

Electrolux

Electrolux Swissline L EWF 1090 Bedienungsanleitung

Electrolux

Electrolux EW8T663G1G Bedienungsanleitung

Electrolux

Electrolux LAVAMAT 50600 Bedienungsanleitung

Electrolux

Electrolux WASL2E 200 Bedienungsanleitung

Electrolux

Electrolux EW6F5247G2 Bedienungsanleitung

Electrolux

Electrolux WA 1668 Bedienungsanleitung

Electrolux

Electrolux EW 800 F Kurzanleitung

Electrolux

Electrolux EWC 1350 Bedienungsanleitung

Electrolux

Electrolux EWF 1476 EDU Bedienungsanleitung

Electrolux

Electrolux EWIE08F3MMW Bedienungsanleitung

Electrolux

Electrolux EWF 106510 W Bedienungsanleitung

Electrolux

Electrolux EWF 1434 Bedienungsanleitung

Electrolux

Electrolux W4130N Bedienungsanleitung

Electrolux

Electrolux WA 1457 F Bedienungsanleitung

Electrolux

Electrolux WE 170 V Bedienungsanleitung

Electrolux

Electrolux EW7F249S Bedienungsanleitung

Electrolux

Electrolux CALIMA EWFM 14480 W Bedienungsanleitung

Electrolux

Electrolux WASL 3 T Bedienungsanleitung

Electrolux

Electrolux EW 901 F Kurzanleitung

Electrolux

Electrolux 300 Series Bedienungsanleitung

Electrolux

Electrolux Swissline L EWF 1090 Bedienungsanleitung

Electrolux

Electrolux EWF10841 Bedienungsanleitung

Electrolux

Electrolux EWG 14740 W Bedienungsanleitung

Electrolux

Electrolux EWF12763E Bedienungsanleitung

Beliebte Waschmaschine Handbücher anderer Marken

Tricity Bendix

Tricity Bendix AW 1000 W Produkthandbuch

Panasonic

Panasonic NA-F60L5WRB Bedienungsanleitung

GE WSLP1500 Handbuch

Bosch

Bosch WAN2829BSN Bedienungsanleitung

LG TV2516DV3B Bedienungsanleitung

LG TH2517DSAV Bedienungsanleitung

VESTEL

VESTEL CMH-XL 7510 TE Bedienungsanleitung

AEG

AEG 74335 Bedienungsanleitung

Johnson

Johnson JWF721A Bedienungsanleitung

Beko

Beko WTE7604XLW0 Bedienungsanleitung

Danby

Danby DTT100A1WDB Montageanleitung

Amica

Amica WA 14 Ex Bedienungsanleitung

Daewoo

Daewoo DWD-F1222 Bedienungsanleitung

Bosch

Bosch WAS28461AU Bedienungsanleitung

Miele

Miele PW 6080 Vario Bedienungsanleitung

Finlux

Finlux FLX108CF220 Bedienungsanleitung

Whirlpool

Whirlpool 3LBR5132AN0 Bedienungsanleitung

Beko

Beko WKB 51231 PTMA Bedienungsanleitung
