EWT 1276 EOW

................................................ .............................................

EN WASHING MACHINE USER MANUAL

CONTENTS

1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

4. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

5. PROGRAMMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

6. CONSUMPTION VALUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

7. OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

8. BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

9. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

10. HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

11. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

12. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

13. TECHNICAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it

decades of professional experience and innovation. Ingenious and stylish, it has been designed

with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great

results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.electrolux.com/productregistration

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts.

When contacting Service, ensure that you have the following data available.

The information can be found on the rating plate. Model, PNC, Serial Number.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

2www.electrolux.com

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible if an incorrect installation and use causes in-

juries and damages. Always keep the instructions with

the appliance for future reference.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or in-

struction concerning use of the appliance in a safe way

and understand the hazards involved.

• Do not let children play with the appliance.

• Keep all packaging away from children.

• Keep all detergents away from children.

• Keep children and pets away from the appliance door

when it is open.

• If the appliance has a child safety device, we recom-

mend you activate it.

• Cleaning and user maintenance shall not be made by

children without supervision.

1.2 General Safety

• Before maintenance, deactivate the appliance and dis-

connect the mains plug from the mains socket.

• Do not change the specification of this appliance.

• Obey the maximum load volume of 7 kg (refer to the

“Programme chart” chapter).

ENGLISH 3

• If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

• The operating water pressure (minimum and maximum)

must be between 0,5 bar (0,05 MPa) and 8 bar (0,8

MPa)

• The ventilation openings in the base (if applicable) must

not be obstructed by a carpet.

• The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging and the

transit bolts.

• Keep the transit bolts. When you move

the appliance again you must block the

drum.

• Do not install or use a damaged appli-

ance.

• Do not install or use the appliance

where the temperature is less than 0 °C

or where it is exposed to the weather.

• Obey the installation instruction sup-

plied with the appliance.

• Make sure that the floor where you in-

stall the appliance is flat, stable, heat

resistant and clean.

• Do not install the appliance where the

appliance door can not be fully opened.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Make sure that there is air circulation

between the appliance and the floor.

• Adjust the feet to have the necessary

space between the appliance and the

carpet.

Electrical connection

WARNING!

Risk of fire and electrical shock.

• The appliance must be earthed.

• Make sure that the electrical information

on the rating plate agrees with the pow-

er supply. If not, contact an electrician.

• Always use a correctly installed shock-

proof socket.

• Do not use multi-plug adapters and ex-

tension cables.

• Make sure not to cause damage to the

mains plug and to the mains cable.

Should the appliance power supply ca-

ble need to be replaced, this must be

carried out by our Service Centre.

• Connect the mains plug to the mains

socket only at the end of the installa-

tion. Make sure that there is access to

the mains plug after the installation.

• Do not pull the mains cable to discon-

nect the appliance. Always pull the

mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

• This appliance complies with the E.E.C.

Directives.

4www.electrolux.com

Water connection

• Make sure not to cause damage to the

water hoses.

• The appliance is to be connected to the

water mains using the new supplied

hose-sets. Old hose sets must not be

reused.

• Before you connect the appliance to

new pipes or pipes not used for a long

time, let the water flow until it is clean.

• The first time you use the appliance,

make sure that there is no leakage.

2.2 Use

WARNING!

Risk of injury, electrical shock, fire,

burns or damage to the appliance.

• Use this appliance in a household only.

• Do not change the specification of this

appliance.

• Obey the safety instructions on the de-

tergent packaging.

• Do not put flammable products or items

that are wet with flammable products

in, near or on the appliance.

• Make sure that you remove all metal

objects from the laundry.

• Do not put a container to collect possi-

ble water leakage under the appliance.

Contact the Service to ensure which

accessories can be used.

2.3 Care and Cleaning

WARNING!

Risk of injury or damage to the

appliance.

• Before maintenance, deactivate the ap-

pliance and disconnect the mains plug

from the mains socket.

• Do not use water spray and steam to

clean the appliance.

• Clean the appliance with a moist soft

cloth. Only use neutral detergents. Do

not use abrasive products, abrasive

cleaning pads, solvents or metal ob-

jects.

2.4 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent chil-

dren and pets to get closed in the ap-

pliance.

3. PRODUCT DESCRIPTION

1Control panel

2Lid

3Lid handle

4Filter access door

5Lever to move the appliance

6Feet for the appliance level

7Rating plate

ENGLISH 5

4. CONTROL PANEL

1 2 3 4 5

1011

1On Off button

2Programme knob

3Spin reduction touchpad

4Temperature touchpad

5Display

6Prewash touchpad

7Delay start touchpad

8Extra rinse touchpad

9Easy iron touchpad

10 Start pause touchpad

11 Time Manager touchpads

4.1 Display

A B C D

EFG

A) The Temperature area:

: Temperature indicator

: Cold water indicator

B) : Time Manager indicator.

C) The time area:

–: the programme duration

–: the delay start

–: the alarm codes

–: the message of error

–: Programme is completed.

D) : the child safety lock indicator.

E) Washing indicators:

–: the washing phase

–: the rinses phase

–: the spin phase

–: Extra rinse permanent option.

F) The spin area:

–: the Spin speed indicator

–: the No Spin indicator

6www.electrolux.com

–: the Rinse Hold indicator

–: the Extra Silent indicator.

G) : the Door locked indicator

5. PROGRAMMES

Programme

Temperature range

Type of load and soil

Maximum load, Maximum spin

Cottons

90°C — Cold

White cotton and coloured cotton. Normal soil

and light soil.

7 kg, 1200 rpm

Eco Cottons

60 °C – 40 °C

White cotton and colour-fast cotton. Normal soil.

7 kg, 1200 rpm

Synthetics

60 °C— Cold

Synthetic items or mixed fabric items. Normal

soil.

3 kg, 1200 rpm

Delicates

40 °C - Cold

Delicate fabrics as acrylics, viscose, polyester

items. Normal soil.

3 kg, 1200 rpm

Wool/Handwash

40 °C – Cold

Machine washable wool, hand washable wool

and delicate fabrics with «hand washing» care

symbol.

1 kg, 1200 rpm

Jeans

60 °C - Cold

Items in denim and jersey. Also for items in dark

colours.

3 kg, 1200 rpm

Rinse To rinse and spin the laundry. All fabrics.

7 kg, 1200 rpm

Spin/Drain To spin the laundry and to drain the water in the

drum. All fabrics.

7 kg, 1200 rpm

Lingerie

40 °C – Cold

Special programme for very delicate items, as lin-

gerie, bras and underwear etc.

1 kg, 800 rpm

Silk

30 °C

Special programme for silk and mixed synthetic

items.

1 kg, 800 rpm

Curtains

40 °C - Cold

Special programme for curtains. The prewash

phase activates automatically.

2.5 kg, 800 rpm

Duvet

60 °C – 30 °C

Special programme for one synthetic blanket, du-

vet, bedspread and so on.

2 kg, 800 rpm

ENGLISH 7

Programme

Temperature range

Type of load and soil

Maximum load, Maximum spin

Sports

30 °C

Synthetic and delicate items. Light soil or items to

refresh.

2 kg, 800 rpm

5 Shirts

30 °C

Washing cycle to wash 5 slightly soiled shirts.

about 1 kg, 800 rpm

1) Standard programmes for the Energy Label consumption values

According to regulation 1061/2010, the “Cottons Eco 60 °C” and “Cottons Eco 40 °C” are

respectively the “standard 60 °C cotton programme” and the “standard 40 °C cotton

programme”. They are the most efficient programmes in terms of combined energy and

water consumptions for washing normally soiled cotton laundry.

The water temperature of the washing phase may differ from the temperature de-

clared for the selected programme.

2) Do not use any detergent for prewash phase.

Programme options compatibility

Programme

■ ■ ■ ■ ■ ■ ■ ■

Eco ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■

■ ■ ■ ■■

■ ■

■ ■ ■ ■ ■

■ ■ ■

■ ■ ■ ■■

■■

■ ■ ■

1) If you set No Spin option the only drain phase is available.

8www.electrolux.com

5.1 Woolmark Certificate

The wool wash cycle of this machine has

been approved by The Woolmark Com-

pany for the washing of machine washa-

ble Woolmark product provided that the

garments are washed according to the in-

structions on the garment label and those

issued by the manufacturer of this wash-

ing machine. M1027

In UK, Eire, Hong Kong and India the

Woolmark symbol is a certification trade-

mark.

6. CONSUMPTION VALUES

At programme start the display shows the duration programme for the maxi-

mum load capacity.

During the washing phase the programme duration is automatically calculated

and can greatly be reduced if the laundry load is lower than the maximum load

capacity (e.g. Cotton 60°C, maximum load capacity 7 kg, the programme du-

ration exceeds 2 hours; real load 1 kg, the programme duration don’t reach 1

hour).

When the appliance is calculating the real programme duration a dot blinks in

the display.

The data of this table are approximate. Different causes can change the data:

the quantity and type of laundry, the water and ambient temperature.

Pro-

grammes

Load

(Kg)

Energy

consump-

tion (kWh)

Water con-

sumption

(litre)

Approxi-

mate pro-

gramme

duration

(minutes)

Remain-

ing mois-

ture (%)

Cottons 60

°C 71.16 58 197 53

Cottons 40

°C 70.61 56 192 53

Synthetics 40

°C 30.45 46 105 35

Delicates 40

°C 30.55 46 90 35

Wool 30 °C 10.35 50 65 30

Standard cotton programmes

Standard 60

°C cotton 71.08 48 259 53

Standard 60

°C cotton 3.5 0.70 40 179 53

Standard 40

°C cotton 3.5 0.65 50 179 53

Off Mode (W) Left On Mode (W)

ENGLISH 9

Pro-

grammes

Load

(Kg)

Energy

consump-

tion (kWh)

Water con-

sumption

(litre)

Approxi-

mate pro-

gramme

duration

(minutes)

Remain-

ing mois-

ture (%)

0.48 0.48

The information given in the chart above are in compliance with the EU Commis-

sion regulation 1015/2010 implementing directive 2009/125/EC.

1) At the end of spin phase.

7. OPTIONS

7.1 Temperature

Set this option to change the default tem-

perature.

Indicator = cold water.

The display shows the set temperature.

7.2 Spin

With this option you can decrease the de-

fault spin speed.

The display shows the indicator of the set

speed.

Additional spin options:

No Spin

• Set this option to remove all spin pha-

ses.

• Set it for very delicate fabrics.

• The rinse phase uses more water for

some washing programmes.

•The display shows the indicator

Rinse Hold

• Set this option to prevent the laundry

creases.

• The washing programme stops with the

water in the drum. The drum turns reg-

ularly to prevent the laundry creases.

• The door stays locked. You must drain

the water to unlock the door.

•The display shows the indicator .

To drain the water refer to ‘At the

end of the programme’.

Extra Silent

• Set this option to remove all spin pha-

ses and to perform a silent washing.

• The rinse phase uses more water for

some washing programmes.

• The washing programme stops with the

water in the drum. The drum turns reg-

ularly to prevent the laundry creases.

• The door stays locked. You must drain

the water to unlock the door.

•The display shows the indicator .

To drain the water refer to ‘At the

end of the programme’.

7.3 Prewash

With this option you can add a prewash

phase to a washing programme.

Use this option for heavy soil.

When you set this option the programme

duration increases.

The related indicator comes on.

7.4 Delay Start

With this option you can delay the start of

a programme from 30 minutes to 20

hours.

The display shows the related indicator.

7.5 Extra Rinse

With this option you can add some rinses

to a washing programme.

Use this option for persons allergic to de-

tergents and in areas where the water is

soft.

10 www.electrolux.com

Inhaltsverzeichnis

Andere Electrolux Waschmaschine Handbücher

Electrolux

Electrolux EWF 146410 W Bedienungsanleitung

Electrolux

Electrolux EW 934 S Bedienungsanleitung

Electrolux

Electrolux EWF 128500 H Bedienungsanleitung

Electrolux

Electrolux EWG 147540 W Bedienungsanleitung

Electrolux

Electrolux EWS 125210 A Bedienungsanleitung

Electrolux

Electrolux EWT 1264SS1 Bedienungsanleitung

Electrolux

Electrolux EWF 1297 HDW Bedienungsanleitung

Electrolux

Electrolux WASHING-MACHINES & WASHER-DRYERS Bedienungsanleitung

Electrolux

Electrolux EWS 1056 EGU Bedienungsanleitung

Electrolux

Electrolux EWF8024D3WB Bedienungsanleitung

Electrolux

Electrolux EWF12853S Bedienungsanleitung

Electrolux

Electrolux EW 1235 F Kurzanleitung

Electrolux

Electrolux EWS 1052 NDU Bedienungsanleitung

Electrolux

Electrolux WAGL4E201 Bedienungsanleitung

Electrolux

Electrolux EWF 1697 HDW Bedienungsanleitung

Electrolux

Electrolux EWT 2264IDW Bedienungsanleitung

Electrolux

Electrolux WAGL3E200 Bedienungsanleitung

Electrolux

Electrolux EWP 0862 TDW Bedienungsanleitung

Electrolux

Electrolux WH31 Bedienungsanleitung

Electrolux

Electrolux FOM 71 CLS Bedienungsanleitung

Electrolux

Electrolux EW 1100 F Kurzanleitung

Electrolux

Electrolux EWF 1676 HDW Bedienungsanleitung

Electrolux

Electrolux EWT 0862EWW Bedienungsanleitung

Electrolux

Electrolux EWF1141AEWA Bedienungsanleitung

Beliebte Waschmaschine Handbücher anderer Marken

Tricity Bendix

Tricity Bendix AW 1000 W Produkthandbuch

Panasonic

Panasonic NA-F60L5WRB Bedienungsanleitung

GE WSLP1500 Handbuch

Bosch

Bosch WAN2829BSN Bedienungsanleitung

LG TV2516DV3B Bedienungsanleitung

LG TH2517DSAV Bedienungsanleitung

VESTEL

VESTEL CMH-XL 7510 TE Bedienungsanleitung

AEG

AEG 74335 Bedienungsanleitung

Johnson

Johnson JWF721A Bedienungsanleitung

Beko

Beko WTE7604XLW0 Bedienungsanleitung

Danby

Danby DTT100A1WDB Montageanleitung

Amica

Amica WA 14 Ex Bedienungsanleitung

Daewoo

Daewoo DWD-F1222 Bedienungsanleitung

Bosch

Bosch WAS28461AU Bedienungsanleitung

Miele

Miele PW 6080 Vario Bedienungsanleitung

Finlux

Finlux FLX108CF220 Bedienungsanleitung

Whirlpool

Whirlpool 3LBR5132AN0 Bedienungsanleitung

Beko

Beko WKB 51231 PTMA Bedienungsanleitung
