Notices
Copyright
© Electron Plus Design Limited 2018-2021
This manual (or part thereof) may not be reproduced by any means (electronic or
photographic, including translation into a foreign language) without prior written
consent and agreement from Electron Plus Design Limited as set-out in United
Kingdom and international copyright laws.
Part Number
ASA101A User Manual
Issue
1.111
,
November
2021
Location
The latest version of this document can be found on our website:
www.electron.plus
Published by
Electron Plus Design Limited
Unit 8 Manor Farm Business Centre
Manor Lane
Stutton
Suffolk
IP9 2TD
UK
Trademark acknowledgement
Electron Plus fully recognises and acknowledges any trademark(s) of the respective trademark holder.
WindowsTM is a trademark of Microsoft Corporation.
Notes
We are likely to update this manual frequently as new features and improvements become available,
please ensure that you check our website for an updated version of this document, especially if
updating your Electron Plus software.
We make every effort to ensure the accuracy of this manual’s contents. If you find any errors, have
suggestions for expanding on a feature, or feel that we can improve it’s contents then please
Copying or reproducing this document or any part of this document without written permission of
Electron Plus is strictly prohibited.
Purpose of manual
The purpose of this manual is to enable you to safely setup, configure and operate your Electron
Plus instrument, associated software and/or accessories. Please pay particular attention to any
section with a warning symbol.
ASA101A User Manual - work in progress
4
/
17
Safety Warnings
Warnings, cautions and notes are colour coded through-out this manual. These are divided into several
categories and are described below:
WARNING - Pay special attention to anything written here - this is for
your safety and continued protection and is critical information!
CAUTION - Damage may occur to your equipment or any DUT (device
under test).
NOTE - General text, with useful information or tips.
ASA101A User Manual - work in progress
5
/
17
Getting Started
ASA101A User Manual - work in progress
6
/
17
System requirements
We recommend at least Windows 7 and a 64 bit machine (however, we know of Windows
XP and 32 bit machines working well with EPIC).
1x USB 2.0 type A (common) for connection to the instrument, at 0.5A.
Screen resolution of at least 1440(W) x 900(H), it will work with others, but you risk some of
the CONTROL RIBBON items not being visible.
EPIC uses the PC sound card for various alerts, although it will operate correctly without
sound.
Technical Note
We test EPIC builds mainly on Windows 10/64 bit machines.
ASA101A User Manual - work in progress
7
/
17
Getting help
Help is available by email (preferably) or via telephone.
email:
from UK:
01473 327100
international telephone:
+44 1473 327 100
If you are experiencing an issue with EPIC, please email a copy of the following files (see
below) found in the EPIC installation folder along with a description of the problem.
log.txt
bugreport.txt
This will help us understand your problem and provide a quicker fix.
ASA101A User Manual - work in progress
8
/
17
Introduction
Welcome
Congratulations and thank you for purchasing an Electron Plus product.
Please take a few minutes to read the
‘Before You Start
’ section of this manual, especially as misusing this
product can result in damage to it, your device-under-test or potentially place you in-danger.
ASA101A User Manual - work in progress
9
/
17
Before you Start
The metal spike is SHARP. When you have finished using the ASA101A, unscrew the spike, turn it round
and screw it lightly back into the ASA101A.
Ensure that all DUT* capacitors and energy storage devices are fully discharged before using the ASA101A.
The SIGNAL connection is protected by a large 'Transzorb' style device, but damage WILL occur if the
ASA101A is placed across a fully charged DCLINK capacitor.
Before connecting your device, please ensure you have installed the USB driver.
DUT* - device under test
ASA101A User Manual - work in progress
10
/
17
New in EPIC
EPIC covers most Electron Plus instruments and not all instruments are updated between versions.
V1.11
Bug fixes
CTL503 - Vgs vs Id (at fixed Vds) mode
V1.10
Bug fixes
Addition of version compiled for 32 bit systems
Addition of CTL503 to EPIC
ASA200/240 - addition of SIGNAL/COMMON to EDIT page
V1.09
Bug fixes
Addition of SPA100 to EPIC
Addition of REF50X to EPIC
V1.08
Bug fixes
