Electronics Line SecuPlace Gebrauchsanweisung

Quick User Guide

SecuPlace

Connecting to MyELAS

To get started connect to MyELAS via the Web or Smartphone apps.

Registering & Logging into MyELAS – Web App

To register to MyELAS:

1. Go to: www.MyELAS.com register. On the registration

screen fill in all required fields:

2. Press REGISTER.

3. Open the e-mail (sent to the e-mail address defined as the

To log in to MyELAS:

1. Go to: www.MyELAS.com. On the login screen enter the

user name and password used when registering:

2. Enter your PIN code (same as your user code – the default

master code is 1234), and then press ENTER.

Registering & Logging into MyELAS – Smartphone App

To register to MyELAS:

1. Download the Smartphone app:

iOS app Android app

2. On the registration screen fill in all required fields:

Android registration screen iOS registration screen

3. Press Register.

4. Open the e-mail (sent to the e-mail address defined as the

To login to MyELAS:

1. Go to the Login screen.

Android login screen iOS login screen

2. Enter the user name and password used when registering.

3. Enter your PIN code (same as your user code – the default

master code is 1234).

4. Press ENTER.

Describing Control Panel Keypad & System LEDs

Control Panel Keypad

Keypad buttons Description

Arming – from left to right: full

arm, partial arm, perimeter arm

Alphanumeric

buttons for user code

Disarming – for disarming the

system. Also silences the sounder.

Accept / OK –for confirming

selection and for saving.

Reject / cancel – for cancelling, or

returning to prior menu item.

Menu navigation – for scrolling

up / down through menu options.

Panic alarm – sends notification

(control panel is silent).

Control Panel LEDs

L D Color State Status

OK L D

/A Off Both AC electrical power and

battery power are disconnected

Green On System power status is ok (no

system trouble)

Green Flashing

Open (activated) zone. Check that

the windows and doors are closed

and no movement is detected by

the detectors within the protected

area.

Yellow On System trouble

Yellow Slow flashing Low battery (in control panel or

transmitters)

Yellow Quick

flashing AC power loss

Yellow Slow and

quick flashing

System trouble in addition to AC

power loss / low battery

(System

Status

L D)

/A Off System is disarmed

Green On System is armed

Red Flashing

Alarm activation (flashes until

system is disarmed).

NOT : Scroll on keypad to view

trouble message(s).

Keyfob LED

The keyfob LED flashes once when transmitting a command, and

flashes repeatedly to indicate a low battery condition.

PIR-Pet Detector LED

The PIR-Pet detector LED flashes upon detection.

Defining Users & Follow-Me Contact

SecuPlace supports up to 32 users, each requiring a unique 4-digit

user code to operate the system.

NOTE: ontrolled codes communicate your system commands to

the alarm receiving centre, whereas non-controlled codes do not.

Slot(s) Code type Description

1 Master code

[Controlled] For master user. Default is 1234.

NOT : For security, it is best to change the code

immediately after system setup.

2-19 User codes [Controlled] For system users.

20-25 User codes [Non-controlled] For system users.

26-27 Limited

user codes [Controlled] For temporary users, valid 24 hours.

28 Duress

code

For all system users, for situations when one is

forced to disarm the system. It sends a “silent”

duress event message to the alarm receiving

centre or to a pre-defined user.

29 Telecontrol

code

For remote system operations and two-way

audio (TWA) communication to the control

panel via telephone.

Alarm

Receiving

Centre /

TWA code

For alarm receiving centre operator. For two-way

audio (TWA) communication with control panel

for up to 10 minutes after an alarm activation.

32 Engineer

code

For the engineer only. Default code is 1111.

NOT : For security, it is recommended to change

the code immediately after system installation.

Defining User Codes

System user codes are typically designated from MyELAS. They can

also be assigned from the control panel by the Master user.

To define user codes at the control panel:

1. Press , and then enter the master code (default is

1234) or the engineer code (default is 1111).

2. Use to scroll to 4. USER ODES, then press .

3. Use to scroll to the specific code slot that you

would like to assign, edit or delete (see chart above for the

available slots and their descriptions), and then press .

4. Scroll and select either: 1. EDIT ODE (to change or delete

a code) or 2.DES RIPTOR (to change the code description

name), and then press .

5. Enter either the changed code or the changed code

description as follows:

•Use to move from character to character on

the display (or wait a second after entering a character to

automatically move to the next space).

•Press any button repeatedly to toggle between the letters

and number printed on it.

•Press to delete a character.

NOTE: If you want to delete a code, change it to 0000.

6. Press to confirm.

Designating a Follow Me Contact Number

Designate the cell phone number of a system user to receive SMS

Follow Me notifications of system events.

To designate a Follow Me number:

1. At the control panel press , then enter the master code

(default is 1234) or the engineer code (default is 1111).

2. Use to scroll to 5. FOLLOW ME #, then press .

3. Enter the area code and number, and then press .

NOTE: To edit the number, scroll to 5. FOLLOW ME #, then

press . Use to move between digits, and

press to delete a digit.

Performing Commands

User-performed commands can be performed at the control panel,

keyfob, and via the Smartphone and Web apps.

Control Panel and Keyfob Commands

Command Control Panel Procedure Keyfob

Procedure

Full arm Press . Then if prompted enter code. Press .

Partial

arm Press . Then if prompted enter code Press .

Perimeter

arm Press . Then if prompted enter code. Press .

Disarm

(& silence

alarms)

Enter code Press .

Panic

alarm Press and simultaneously.

Press

simultaneously

Fire alarm Press and simultaneously. /A

Medical

alarm

Press and simultaneously;

control panel beeps to indicate alarm

activation.

View

troubles

If a trouble message displays, press

to scroll and view system troubles.
