Elo TouchSystems 2200L Bedienungsanleitung
2200L 22-inch LCD Touchmonitor User Guide
[Model ET2200L]
Elo TouchSystems
2200L 22-inch LCD Touchmonitor
User Guide
Revision B
P/N E945960
Elo TouchSystems
1-800-ELOTOUCH
www.elotouch.com
Elo TouchSystems 2200L User Guide 3
Copyright © 2008 Tyco Electronics. All Rights Reserved.
No part of this publication may be reproduced, transmitted, tran-
scribed, stored in a retrieval system, or translated into any language
or computer language, in any form or by any means, including, but not
limited to, electronic, magnetic, optical, chemical, manual, or other-
wise without prior written permission of Elo TouchSystems.
Disclaimer
The information in this document is subject to change without
notice. Elo TouchSystems makes no representations or warranties
with respect to the contents hereof, and specifically disclaims any
implied warranties of merchantability or fitness for a particular pur-
pose. Elo TouchSystems reserves the right to revise this publication
and to make changes from time to time in the content hereof without
obligation of Elo TouchSystems to notify any person of such revisions
or changes.
Trademark Acknowledgments
IntelliTouch, APR (Acoustic Pulse Recognition), Elo TouchSystems,
TE Logo, and Tyco Electronics are trademarks. Other product names
mentioned herein may be trademarks or registered trademarks of their
respective companies. Elo TouchSystems claims no interest in trade-
marks other than its own.
Elo TouchSystems 2200L User Guide 4
Table of Contents
Chapter 1: Introduction....................................................................5
About the Product .............................................................................................................5
Precautions......................................................................................................................... 6
Chapter 2: Installation and Setup ...................................................7
Unpacking Your Touchmonitor .........................................................................................8
Connecting the Cables to the Touchmonitor and Computer..............................................9
Installing the Touch Driver ..............................................................................................10
Monitor Overview and Dimensions................................................................................. 11
Monitor Mounting and Orientation..................................................................................12
Chapter 3: Operation......................................................................15
About Touchmonitor Adjustments .................................................................................. 15
On-Screen Display (OSD) Control Panel........................................................................16
Preset Display Modes ......................................................................................................20
Speakers and Audio Features...........................................................................................21
Chapter 4: Troubleshooting...........................................................22
Solutions to Common Problems ......................................................................................22
Technical Support ............................................................................................................ 23
Appendix A: Touchmonitor Safety................................................24
Care and Handling of Your Touchmonitor.......................................................................25
Warning............................................................................................................................25
Waste Electrical and Electronic Equipment (WEEE) Directive......................................25
Appendix B: Technical Specifications..........................................26
2200L Specifications........................................................................................................26
Regulatory Information..................................................................29
Warranty..........................................................................................32
Elo TouchSystems 2200L User Guide 5
C H A P T E R
1
INTRODUCTION
About the Product
The Elo TouchSystems 2200L touchmonitor senses touch on the
display in a completely new way, by recognizing the unique pattern of
sounds. Consisting only of a glass overlay mounted in front of the LCD
panel, Elo’s 2200L zero-bezel Acoustic Pulse Recognition (APR) deliv-
ers benefits that combine the ultimate in optical qualities with a stylish,
easy to clean, seamless front face.
Wide-aspect displays like the Elo 2200L are easier to use and in-
corporate into the workplace than traditional desktop touchmonitors.
Wide-screen format displays allow extra content on screen and are
ideal in corporate environments for spreadsheets, publishing, and
dual-window applications.
The 2200L is available in both zero-bezelAPR and IntelliTouch Sur-
face Acoustic Wave touch technologies.
Typical applications for the 2200L include: point-of-sale (POS), point-
of-service, digital signage, loyalty systems, kiosk information systems,
light industrial shop-floor automation and home control.
• Wide-screen format provides more application space
• Sleek, integrated design offers a stylish look for public venues
• AC and DC power for maximum input flexibility
• User-lockable on-screen display – designed for public access
• Adjustable height stand provides the flexibility to be raised or
lowered to meet the application’s height requirements
Elo TouchSystems 2200L User Guide 6
• VGA and DVI-D video input (DVI-D not available in Europe)
• Space-saving built-in speakers
• Sealed screen is resistant to water, dust, grease
• One-time factory calibration for easy deployment and integration
• Pure glass construction provides superior optical performance
and the true-flat surface is easy to clean
• VESA compliance makes wall or arm-mounting possible
For more detailed information, please visit our website:
www.elotouch.com.
Precautions
Follow all warnings, precautions, and maintenance as recommended
in this user’s manual to maximize the life of the unit. SeeAppendix A
for more information on touchmonitor safety.
C H A P T E R
2
INSTALLATIONAND SETUP
This chapter discusses how to install and set up your LCD
touchmonitor and how to install Elo TouchSystems driver software.
Elo TouchSystems 2200L User Guide 7
Elo TouchSystems 2200L User Guide 8
USB Cable
Touchmonitor
Unpacking Your Touchmonitor
Check that the following items are present:
VGA Video Cable
Serial Cable
(not included with
APR models)
TouchTools or APR CD and
Quick Install Guide
DVI-D Cable
(not included with
European models)
AND/
OR
Power Cable
AND/
OR
Input Audio
Cable
Elo TouchSystems 2200L User Guide 9
Connecting the Cables to the Touchmonitor and Computer
Connector Panel Underneath the Monitor
To connect the touchmonitor to the computer:
1 Tilt the monitor to reveal the connector panel in the recessed area
underneath the bottom edge of the monitor.
2Connect the AC power cable to the connector panel and connect
the other end to the power outlet.
3 Connect either the USB cable OR the serial cable to the connector
panel. Note: Do not use both. This cable connects the
touchmonitor to your computer. Attach the other end to your
computer.
4Connect the video cable (VGA) or the DVI-D cable to the connector
panel. Tighten by turning the two thumb screws clockwise to
ensure proper grounding. Connect the other end to your computer.
5Connect the audio cable to the Audio Input on the connector panel
and connect the other end to your computer.
6Press the power button on the side panel of the monitor to turn on
the monitor.
Power VGADVI-D
USB
LED
DC
in Audio
Output Audio
Input
Serial
Elo TouchSystems 2200L User Guide 10
Installing the Touch Driver
Your Elo touchmonitor is Plug-and-Play compliant. Information on
the video capabilities of the touchmonitor is sent to the video display
adapter when the computer’s operating system starts. If the comput-
er’s operating system detects the touchmonitor, follow the instructions
on the screen to install a generic Plug-and-Play monitor.
Elo TouchSystems provides touchscreen driver software that allows
your touchmonitor to work with your computer. Drivers are located on
the enclosed CD.
The latest versions of drivers and driver information for all operating
systems, including those that are not included with the CD, are avail-
able on the Elo TouchSystems website at www.elotouch.com/
support/downloads/.
To install the Touch Driver, follow the steps below:
1Insert the TouchTools orAPR CD in your computer’s CD-ROM
drive.
2Click on Install Driver for This Computer.
3 Follow the on-screen instructions to complete the installation.
If there are no on-screen instructions when you install the
TouchTools or APR CD :
1Click Start > Run.
2Click the Browse button to locate the EloCd.exe program
on the CD-ROM.
3Click Open, then OK to run EloCd.exe.
4Follow the directions on the screen to complete the driver
installation.
