Elprotronic FlashPro-CC Bedienungsanleitung

FlashPro-CC Flash Programmer

for the CC series devices - Chipcon product from TI

Remote Control Programming User’s Guide

PM024A02 Rev.2

December-17-2007

Elprotronic Inc.

16 Crossroads Drive

Richmond Hill,

Ontario, L4E-5C9

CANADA

Web site: www.elprotronic.com

E-mail: [email protected]

Fax: 905-780-2414

Voice: 905-780-5789

Disclaimer:

No part of this document may be reproduced without the prior written consent of Elprotronic Inc.

The information in this document is subject to change without notice and does not represent a

commitment on any part of Elprotronic Inc. While the information contained herein is assumed to

be accurate, Elprotronic Inc. assumes no responsibility for any errors or omissions.

In no event shall Elprotronic Inc, its employees or authors of this document be liable for special,

direct, indirect, or consequential damage, losses, costs, charges, claims, demands, claims for lost

profits, fees, or expenses of any nature or kind.

The software described in this document is furnished under a licence and may only be used or copied

in accordance with the terms of such a licence.

Disclaimer of warranties: You agree that Elprotronic Inc. has made no express warranties to You

regarding the software, hardware, firmware and related documentation. The software, hardware,

firmware and related documentation being provided to You “AS IS” without warranty or support

of any kind. Elprotronic Inc. disclaims all warranties with regard to the software, express or implied,

including, without limitation, any implied warranties of fitness for a particular purpose,

merchantability, merchantable quality or noninfringement of third-party rights.

Limit of liability: In no event will Elprotronic Inc. be liable to you for any loss of use, interruption

of business, or any direct, indirect, special incidental or consequential damages of any kind

(including lost profits) regardless of the form of action whether in contract, tort (including

negligence), strict product liability or otherwise, even if Elprotronic Inc. has been advised of the

possibility of such damages.

END USER LICENSE AGREEMENT

PLEASE READ THIS DOCUMENT CAREFULLY BEFORE USING THE SOFTWARE AND

THE ASSOCIATED HARDWARE. ELPROTRONIC INC. AND/OR ITS SUBSIDIARIES

(“ELPROTRONIC”) IS WILLING TO LICENSE THE SOFTWARE TO YOU AS AN

INDIVIDUAL, THE COMPANY, OR LEGAL ENTITY THAT WILL BE USING THE

SOFTWARE (REFERENCED BELOW AS “YOU” OR “YOUR”) ONLY ON THE CONDITION

THAT YOU AGREE TO ALL TERMS OF THIS LICENSE AGREEMENT. THIS IS A LEGAL

AND ENFORCABLE CONTRACT BETWEEN YOU AND ELPROTRONIC. BY OPENING THIS

PACKAGE, BREAKING THE SEAL, CLICKING “I AGREE” BUTTON OR OTHERWISE

INDICATING ASSENT ELECTRONICALLY, OR LOADING THE SOFTWARE YOU AGREE

TO THE TERMS AND CONDITIONS OF THIS AGREEMENT. IF YOU DO NOT AGREE TO

THESE TERMS AND CONDITIONS, CLICK ON THE “I DO NOT AGREE” BUTTON OR

OTHERWISE INDICATE REFUSAL, MAKE NO FURTHER USE OF THE FULL PRODUCT

AND RETURN IT WITH THE PROOF OF PURCHASE TO THE DEALER FROM WHOM IT

WAS ACQUIRED WITHIN THIRTY (30) DAYS OF PURCHASE AND YOUR MONEY WILL

BE REFUNDED.

1. License.

The software, firmware and related documentation (collectively the “Product”) is the property of

Elprotronic or its licensors and is protected by copyright law. While Elprotronic continues to own

the Product, You will have certain rights to use the Product after Your acceptance of this license.

This license governs any releases, revisions, or enhancements to the Product that Elprotronic may

furnish to You. Your rights and obligations with respect to the use of this Product are as follows:

YOU MAY:

A. use this Product on many computers;

B. make one copy of the software for archival purposes, or copy the software onto the hard disk

of Your computer and retain the original for archival purposes;

C. use the software on a network

YOU MAY NOT:

A. sublicense, reverse engineer, decompile, disassemble, modify, translate, make any attempt

to discover the Source Code of the Product; or create derivative works from the Product;

B. redistribute, in whole or in part, any part of the software component of this Product;

C. use this software with a programming adapter (hardware) that is not a product of

Elprotronic Inc.

2. Copyright

All rights, title, and copyrights in and to the Product and any copies of the Product are owned by

Elprotronic. The Product is protected by copyright laws and international treaty provisions.

Therefore, you must treat the Product like any other copyrighted material.

3. Limitation of liability.

In no event shall Elprotronic be liable to you for any loss of use, interruption of business, or any

direct, indirect, special, incidental or consequential damages of any kind (including lost profits)

regardless of the form of action whether in contract, tort (including negligence), strict product

liability or otherwise, even if Elprotronic has been advised of the possibility of such damages.

4. DISCLAIMER OF WARRANTIES.

You agree that Elprotronic has made no express warranties to You regarding the software, hardware,

firmware and related documentation. The software, hardware, firmware and related documentation

being provided to You “AS IS” without warranty or support of any kind. Elprotronic disclaims all

warranties with regard to the software and hardware, express or implied, including, without

limitation, any implied warranties of fitness for a particular purpose, merchantability, merchantable

quality or noninfringement of third-party rights.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital devices,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one

of more of the following measures:

* Reorient or relocate the receiving antenna

* Increase the separation between the equipment and receiver

* Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

* Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications not expressly approved by Elprotronic Inc. could void the user’s authority

to operate the equipment.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference and

(2) this device must accept any interference received,

including interference that may cause undesired

operation.

This Class B digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

Cet appereil numerique de la classe B respecte toutes les exigences du

Reglement sur le material brouilleur du Canada.

Table of Contents

1. Introduction ............................................................. 9

2.Demoprogram .......................................................... 16

3.GettingStarted .......................................................... 23

3.1 Example with single FPA API DLL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3.2 Example with Multi-FPA API DLL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.ListoftheDLLinstructions................................................ 27

4.1Multi-FPAinstructions ............................................ 28

F_Trace_ON.................................................. 28

F_Trace_OFF ................................................. 28

F_OpenInstances .............................................. 28

F_CloseInstances .............................................. 29

F_OpenInstancesAndFPAs, F_OpenInstances_AndFPAs . . . . . . . . . . . . . . 29

F_API_DLL_Directory ......................................... 33

F_Set_FPA_index ............................................. 34

F_Get_FPA_index ............................................. 35

F_Disable_FPA_index.......................................... 35

F_Enable_FPA_index .......................................... 35

F_LastStatus.................................................. 36

F_Multi_DLLTypeVer.......................................... 36

F_Get_FPA_SN ............................................... 37

4.2Genericinstructions ............................................... 38

F_Check_FPA_access .......................................... 38

F_DLLTypeVer ............................................... 40

F_Initialization................................................ 40

F_Close_All .................................................. 41

F_GetSetup .................................................. 42

F_ConfigSetup ................................................ 42

F_SetConfig .................................................. 45

F_GetConfig ................................................. 50

F_DispSetup.................................................. 51

F_ReportMessage, F_Report_Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

F_GetReportMessageChar ....................................... 53

F_ReadCodeFile, F_Read_CodeFile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

F_Get_CodeCS ............................................... 55

F_ConfigFileLoad, F_Config_FileLoad . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

F_Clr_Code_Buffer ............................................ 57

F_Put_Byte_to_Code_Buffer..................................... 58

F_Get_Byte_from_Code_Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

F_Put_IEEEAddr64_to_Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

F_Put_IEEEAddr_Byte_to_Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

F_Get_IEEEAddr64_from_Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

F_Get_IEEEAddr_Byte_from_Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

F_Power_Target............................................... 61

F_Reset_Target ............................................... 61

F_Get_Targets_Vcc ............................................ 62

4.3Encapsulatedinstructions........................................... 63

F_AutoProgram ............................................... 63

F_Verify_Lock_Bit ............................................ 64

F_Memory_Erase.............................................. 65

F_Memory_Blank_Check ....................................... 66

F_Memory_Write.............................................. 66

F_Memory_Verify ............................................. 66

F_Memory_Read .............................................. 67

F_Write_IEEE_Address......................................... 68

F_Read_IEEE_Address ......................................... 68

F_Write_Lock_Bits ............................................ 69

4.4Sequentialinstructions ............................................. 70

F_Open_Target_Device ......................................... 71

F_Close_Target_Device......................................... 71

F_Segment_Erase.............................................. 72

F_Sectors_Blank_Check ........................................ 73

F_Write_Byte_to_XRAM ....................................... 73

F_Read_Byte_from_XRAM ..................................... 74

F_Write_Byte_to_direct_RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

F_Read_Byte_from_direct_RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

F_Copy_Buffer_to_Flash........................................ 76

F_Copy_Flash_to_Buffer........................................ 76

F_Copy_Buffer_to_XRAM ...................................... 77

F_Copy_XRAM_to_Buffer ...................................... 78

F_Copy_Buffer_to_direct_RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

F_Copy_direct_RAM_to_Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

F_Put_Byte_to_Buffer .......................................... 80

F_Get_Byte_from_Buffer ....................................... 81

F_Set_PC_and_RUN ........................................... 81

F_Get_MCU_Data............................................. 82

Appendix A ............................................................... 84

FlashPro-CC Command Line interpreter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

1. Introduction

FlashPro-CC Flash Programmer (USB ) can be remotely controlled from other

software applications (Visual C++, Visual Basic etc.) via a DLL library. The Multi-FPA - allows

to remotely control simultaneously up to eight Flash Programming Adapters (FPAs)

significantly reducing programming speed in production.

Figure 1.1 shows the connections between PC and up to eight programming adapters. The

FPAs can be connected to PC USB ports directly or via USB-HUB. Direct connection to the PC

is faster but if the PC does not have required number of USB ports, then USB-HUB can be used.

The USB-HUB should be fast, otherwise speed degradation can be noticed. When the USB hub

is used, then the D-Link’s Model No: DUB-H7, P/N BDUBH7..A2 USB 2.0 HUB is

recommended.

Figure 1.1

Inhaltsverzeichnis

Andere Elprotronic Hauptplatine Handbücher

Elprotronic

Elprotronic FlashPro2000 Bedienungsanleitung

Elprotronic

Elprotronic GangPro430 Bedienungsanleitung

Elprotronic

Elprotronic GangPro430 Bedienungsanleitung

Elprotronic

Elprotronic MSP430 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
