OWNER'S MANUAL

AM / FM CLOCK RADIO

with SURE-ALARM™

BATTERY BACK-UP

CK5028

Visit our web site at www.emersonradio.com

IMPORTANT

Call toll-free 1-800-210-2281 for exciting information

and special discounts on Extended Service Plans.

Thankyou............................

For purchasing this Emerson AM/FM Clock Radio with Sure-Alarm™Battery Back

Up System. It has been designed and engineered to provide you with many years

of reliable operation with a minimum of care. Listen to your favorite AM/FM radio

stations; wake up to the radio or an electronic buzzer alarm; sleep to music with the

auto shutoff timer; and use the Snooze Alarm when you need a few more minutes

sleep before you can get up and face a new day.

The Sure-Alarm™Battery Back Up System not only maintains the time and alarm

settings in case of a power failure, but it will also wake you up even if the power is

'off' at the selected alarm time, as long as the back up battery has sufficient power.

Please read this instruction manual completely to make sure that you understand

all the features of your new clock radio, and please save this manual for future

reference. If you experience any problems with the set up or operation of this radio,

please call the Emerson Radio Corporation Customer Service Hotline, toll free at:

1-800-898-9020.

The serial number of your radio is located on a label on the bottom of the cabinet.

Wesuggestthat yourecord theserialnumber inthe spacebelowfor futurereference.

MODEL NO: CK5028

SERIAL NUMBER:

WARNING: TO PREVENT FIRE OR SHOCK HAZARD,

DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

This device complies with part 15 of the FCC rules. Operation is subject to the

condition that this device does not cause harmful interference.

Avoid installing the unit in locations described below:

• Places exposed to direct sunlight or close heat radiating appliances such as electric

heaters.

• Dusty places.

• Places subject to constant vibration.

• Humid or moist places.

IMPORTANT NOTES

ATTENTION

The Owner's Manual contains important operating and

maintenance instructions.

For your safety, it is necessary to refer to the manual.

DANGEROUS VOLTAGE

Uninsulated Dangerous Voltage, that may be of sufficient

magnitude to constitute a risk of electric shock to persons is

present within this product's enclosure.

PREPARATION FOR USE

UNPACKING AND SET UP

• Remove all packing materials from the unit. Also remove any descriptive labels

from the front or top of the radio. Do not remove any labels from the back or

bottom of the radio.

• Place the radio on a stable shelf, desk, nightstand, table, etc, convenient to a

110V 60Hz AC outlet, and away from direct sunlight or sources of heat, humidity,

moisture, dust, or vibration.

• Unwind the AC power cord. The FM antenna is built into the power cord so be

sure to extend it to its full length for best FM reception.

BACK UP BATTERY INSTALLATION

The Back Up battery compartment is located on the bottom of the radio. Open the

battery door, as shown in the illustration, and connect a 9V battery (not included)

to the battery terminals. The battery can only be connected one way. Push the

battery back into the battery compartment and replace the battery door.

Note: Use only a well known brand of Alkaline battery for longest life and best

performance.

In the event of a temporary power interruption the clock display will go off, but the

back up battery will maintain the time and alarm settings. When power is restored

the clock display will come on again and the time and alarm settings will be correct.

POWER FAILURE INDICATION

If you do not install a battery, or if the battery is exhausted and the power is

interrupted, the time and alarm settings will be lost. When power is restored the

display will begin flashing. This flashing display is your indication that the clock is

incorrect and you must reset both the time and alarm settings.

9VOLT

Press

LOCATION OF CONTROLS AND INDICATORS

1. Power Switch.

(BUZ / AUTO / ON / OFF)

2. CLOCK Set Button.

3. ALARM Set Button.

4. SLEEP Button.

5. MINUTE Button.

6. HOUR Button.

7. SNOOZE Button.

8. AM Indicator.

9. AUTO(Alarm) Set Indicator.

10. Clock Display.

11. Tuning Dial.

12. TUNING Control.

13. BAND Selector.

(AM / FM)

14. VOLUME Control.

15. Speaker.

16. Battery Compartment.

(Bottom of unit)

17. AC Power Cord.

12 00

9 11

4 1

OPERATING INSTRUCTIONS

POWER SOURCE

This radio is designed to operate on normal 110V 60Hz AC house current only.

Operating the radio with any other power supply may cause damage to the unit

which is not covered by your warranty.

Fully extend the AC power cord and insert the plug into a polarized AC outlet.

Note that this unit has a polarized AC plug with

one wide blade and one narrow blade. This is a

safety feature designed to protect you from

electricshock. If thisplugwill not fitintoyour outlet

you may have an outdated, non-polarized outlet.

Do not try to defeat this safety feature by using

an adapter, or filing the wider blade on the plug

to make it fit into your outlet. Contact a licensed

electrician to replace your outdated outlet.

Note: Be sure to connect this radio to an outlet that is always 'live'. Do not connect

this unit to an outlet that is controlled by a wall switch.

SETTING THE CLOCK

When the unit is plugged in for the first time the clock will show (AM) " 12:00" and

the display will flash. The flashing will stop after the clock has been set.

1. Depress the CLOCK button and the HOUR button together to adjust the clock

to the correct hour, then release the buttons.

Note:Be sure to set the hour correctly for AM or PM. If the AM Indicator is 'On',

the time displayed is AM. If the AM indicator is 'Off', the time displayed is

PM.

2. Depress the CLOCK button and the MINUTE button together to adjust the clock

to the correct minute, then release the buttons.

AM indicator

AUTO indicator

SETTING THE WAKE UP TIME

1. Depress the ALARM button and the HOUR button together to adjust the clock

display to the correct wake-up hour, then release the buttons. Be sure to set

the wake-up hour correctly for either AM or PM.

2. Depress the ALARM button and the MINUTE button together to adjust the clock

display to the correct wake-up minute, then release the buttons.

LISTENING TO RADIO

1. Set the BAND switch to the desired band, AM or FM.

2. Set the VOLUME control to a low setting.

3. Slide the Power switch to the 'ON' position.

4. Use the TUNING control to select the desired station.

5. Adjust the VOLUME control to a comfortable level.

6. When you are finished listening, slide the Power switch to the 'OFF' position.

Hints For Better Reception

FM - The FM antenna is inside the power cord. Make sure the power cord is fully

extended for best reception.

AM - The AM antenna is inside the radio cabinet. If AM reception is unsatisfactory,

try rotating or repositioning the cabinet until you find the position that provides

the best reception for that particular station.

WAKE TO RADIO

1. Depress the ALARM button. The display will change from the correct time to

wake up time. Adjust the wake up time as described on page 6, if necessary.

2. Slide the Power switch to the 'ON' position and select the station and the volume

level that you want to hear when you wake up.

3. Slide the Power switch to the 'AUTO' position. The radio will turn 'Off'.

4. At the selected wake up time the radio will turn 'On' automatically. It will play for

1 hour and 59 minutes and then shut off automatically and reset itself for the

following day.

5. To stop the radio sooner, slide the Power switch to the 'OFF' position.

WAKE TO BUZZER ALARM

1. Depress the ALARM button. The display will change from the correct time to

wake up time. Adjust the wake up time as described on page 6, if necessary.

2. Slide the Power switch to the 'BUZ' position.

3. At the selected wake up time an electronic buzzer alarm will turn 'On'

automatically. It will continue for 1 hour and 59 minutes and then shut off

automatically and reset itself for the following day.

4. To stop the buzzer alarm sooner, slide the Power switch to the ''OFF' position.

SNOOZE (REPEAT ALARM)

If you need a few extra minutes sleep when the alarm comes on in the morning,

press the SNOOZE button. The alarm will stop for approximately 9 minutes, and

then turn on again. This operation can be repeated several times if necessary.

SLEEP TO MUSIC TIMER

The sleep to music timer allows you to fall asleep to music for up to 1 hour and 59

minutes, and then shuts the radio off automatically.

The sleep timer can be activated when the Power switch is set to the 'OFF', 'AUTO',

or 'BUZ' positions.

1. Depress the SLEEP button to start the sleep timer. The display indicates "0:59"

and the radio turns on.

2. To adjust the amount of sleep timer operation, continue to hold the SLEEP

button and depress the MINUTE button. The display starts counting down from

59 minutes. Release the MINUTE button when the display shows the desired

minute. To add 1 hour, continue to hold the SLEEP button and press the HOUR

button once.

3. When the desired amount of sleep time appears on the display, release all the

buttons. The radio will continue to play until the sleep timer counts down to

"0:00", and then the radio shuts off automatically.

4. To shut off the radio and cancel the sleep timer before it counts down to "0:00",

press the SNOOZE button. The radio stops immediately.

IMPORTANT:

Remember that the station and volume setting that you select for sleep timer

operation are the same settings you will hear the following morning if you have the

alarm set for 'WAKE TO RADIO'.

CARE AND MAINTENANCE

There are no user serviceable parts inside this radio. Please refer all service

problems to a qualified service facility. See the warranty page of this manual for

further details.

If the cabinet becomes dusty, wipe the exterior with a soft dust cloth only. Never

use dusting sprays or polishes on the cabinet.

If the cabinet becomes dirty or smudged with fingerprints it may be wiped with a

soft cloth that has been slightly dampened with a mild soap and water solution.

Always disconnect the power cord from the AC outlet before cleaning, and never

allow any liquid to get inside the cabinet.

Note: If there is no battery in the back-up battery compartment, the Time and Alarm

settings will be lost when the power cord is disconnected for cleaning. Reset

the clock and wake up times after reconnecting the power cord.

FOR CUSTOMER SERVICE, PLEASE WRITE TO:

Emerson Radio Corp.

Consumer Affairs Dept.

1901 Diplomat Drive,

Farmers Branch, TX 75234.

FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE

PLEASE CALL:

1-800-898-9020

TO FIND THE LOCATION AND PHONE NUMBER

OF YOUR NEAREST SERVICE CENTER

PERMITTED TO PERFORM WARRANTY...

CALL TOLL FREE: 1-800-695-0098

SERVICE

Inhaltsverzeichnis

Andere Emerson Radiowecker Handbücher

Emerson

Emerson Research SmartSet iC172 Bedienungsanleitung

Emerson

Emerson CKD3630 Bedienungsanleitung

Emerson

Emerson girlpower GP808 Bedienungsanleitung

Emerson

Emerson CKD1612 Bedienungsanleitung

Emerson

Emerson RP6251 Bedienungsanleitung

Emerson

Emerson CKS2288 Bedienungsanleitung

Emerson

Emerson SpongeBob Squarepants SB816 Bedienungsanleitung

Emerson

Emerson CKD3810 Bedienungsanleitung

Emerson

Emerson CK5888 Bedienungsanleitung

Emerson

Emerson CK5250 Bedienungsanleitung

Emerson

Emerson SmartSet ER100113 Bedienungsanleitung

Emerson

Emerson SmartSet CKS1900 Bedienungsanleitung

Emerson

Emerson CKS1800 Bedienungsanleitung

Emerson

Emerson Research AC100 Bedienungsanleitung

Emerson

Emerson SMARTSET CKS1708 Bedienungsanleitung

Emerson

Emerson CK9902 Bedienungsanleitung

Emerson

Emerson SMARTSET CKS1850C Bedienungsanleitung

Emerson

Emerson CKS3029 Bedienungsanleitung

Emerson

Emerson girlpower GP890 Bedienungsanleitung

Emerson

Emerson cK5027 Bedienungsanleitung

Emerson

Emerson CKS5060B Bedienungsanleitung

Emerson

Emerson RET66TQ Bedienungsanleitung

Emerson

Emerson Dora the Explorer DTE810 Bedienungsanleitung

Emerson

Emerson CK5859 Bedienungsanleitung

Beliebte Radiowecker Handbücher anderer Marken

Denver

Denver CRQ-105 Bedienungsanleitung

Audiovox

Audiovox CE90 Bedienungsanleitung

Sony

Sony Dream Machine ICF-C763L Bedienungsanleitung

Sanyo

Sanyo DMP-P6 Bedienungsanleitung

RCA

RCA RPC100 Bedienungsanleitung

Yamaha

Yamaha ISX-80 Bedienungsanleitung

Pyle

Pyle PLMR20W Bedienungsanleitung

Blaupunkt

Blaupunkt CR7BK Bedienungsanleitung

Philips

Philips AJ3180 Bedienungsanleitung

HoMedics

HoMedics SS-5500-2EU Bedienungsanleitung

RCA

RCA RC66i Bedienungsanleitung

Versaudio

Versaudio Vers Bedienungsanleitung

SOUNDMASTER

SOUNDMASTER UR8100 Bedienungsanleitung

Audiovox

Audiovox CE90 Bedienungsanleitung

Jensen Audio

Jensen Audio JCR-222 - AM/FM Projection Alarm Clock Radio Bedienungsanleitung

Roberts

Roberts ChronoDAB Bedienungsanleitung

AEG

AEG MRC 4132 BT Bedienungsanleitung

Tokai

Tokai TC-155 Bedienungsanleitung
