EMPORIA TOUCH smart.2 Bedienungsanleitung
English
Eveline Pupeter, emporia Telecom
www.emporia.eu
Thank you for purchasing an emporia product!
Please read this user guide before
attempting to use your phone.
TOUCH
smart.2
Wi-Fi
connection or
mobile data tariff
required
2
1
4
16
7
9
12
11
3
13 14
21
18
20
19
5
10
› YOUR MOBILE PHONE AT A GLANCE
1Loudspeaker
2Home screen
3Navigation ring
4Left function key
5Selection key
6Right function key
7Phone book key
8Camera key
9Green key
10 Chat app key
11 Red key
12
1
key (voicemail)
13 Camera lens and ash
14 Emergency button
(extra battery cover without
an emergency button)
15 Headset port
16 Torch button
17 Volume controls
and
18 Battery cover
19 Loudspeaker
20 Microphone
21 Port for USB charging cable
6
15
17
8
›Symbols on the external
display
Reception indicator
Battery
12:3012:30 Time
21.0821.08 Date
SunSun Day
Incoming call
Missed call
New SMS
New messaging
appmessage
›Other symbols on
the home screen
Vo LTE
Reception indicator
Wi-Fi
Alarm
Silent mode
Bluetooth
12 °C12 °C Temperature
› SYMBOLS AND OPERATING THE PHONE
ENGLISH–03
›How do I return a missed call?
1. Tap on the word Show on the screen below the notication
Missed call.
2. The call function will open and the number or name of
thecaller will be highlighted by a red bar.
›How do I access a new SMS message?
1. Tap on the word Show on the screen below the notication
New message.
2. The text message function will open.
3. The number or name of the sender will be highlighted by a bar.
4. Tap on the new SMS to read it.
›How do I access a new messaging app message?
• Tap on the chat app key to open the app.
›How do I remove indicators for missed calls,
SMS messages and messaging app notifications?
The symbols on the external display and along the top of the
screen will disappear as soon as you've read the SMS, opened
the messagingapp or had a look to see who the missed call
was from.
ENGLISH–04
› CONTENTS
› Your mobile phone at a
glance..................02
› Symbols and operating
thephone ..............03
1. Getting started .........06
1.1 Inserting a SIM card........06
1.2 Inserting and charging
thebattery................06
1.3 Turning on the phone......07
1.4 Entering a PIN code........07
1.5 Saving battery power......07
2. Setting up your phone...08
2.1 Setting up a
messaging app............08
2.2 Personalising the menu ....09
2.3 Updating your system
andapps..................09
3. Using the phone ........10
3.1 Using the home screen ....10
3.2 Dual-function keys ........10
3.3 Using the menu ...........11
3.4 Writing text ...............12
4. Calls ...................13
4.1 Accepting, rejecting or
ending a call ..............13
4.2 Calling someone ..........13
5. Contacts................14
5.1 Searching for a contact
in the phone book.........14
5.2 Adding a contact ..........14
5.3 Transferring contacts ......15
5.4 Opening and editing
acontact record ...........16
5.5 Contact options ...........17
6. Messages (SMS) .........18
6.1 Writing and sending
amessage ................18
6.2 Reading a message ........18
7. Messaging app..........19
7.1 Setting up a messaging app19
7.2 Using the messaging app ..19
7.3 Closing the messaging app 19
ENGLISH–05
8. Info centre .............20
8.1 Receiving a notification ....20
8.2 Opening a notification .....20
8.3 Deleting notifications......20
9. Camera.................21
9.1 Taking a photo or
recording a video..........21
9.2 Changing the camera
settings...................21
10. Photo album............22
10.1 Viewing a photo or video ..22
10.2 Sending or editing a photo 22
11. Settings ................24
11.1 Alarm.....................24
11.2 Silent mode ...............24
11.3 Wi-Fi......................25
11.4 Bluetooth .................25
11.5 Mobile data . . . . . . . . . . . . . . .26
11.6 Flight mode ...............26
11.7 Location (GPS).............26
11.8 Open to answer calls.......26
11.9 Voice assistant ............27
11.10 Wi-Fi hotspot ............27
11.11 Wallpaper ...............27
11.12 Messaging app ..........27
11.13 More settings............28
12. Internet ................29
13. Calendar ...............30
13.1 Entering a new event ......30
13.2 Opening an event
you've entered ............31
13.3 Searching for an event .....31
14. System updates.........32
15. Weather ................33
16. Emporia emergency call
function................34
17. Guarantee and service...36
ENGLISH–06
1. GETTING STARTED
1.1 Inserting a SIM card
1. Remove the battery cover (opening in the bottom left-hand corner).
2. Slide the SIM card into the SIM card holder with the gold
contacts facing down.
3. To add more storage, insert a memory card into the memory
card holder with the gold contacts facing down.
1.2 Inserting and charging the battery
1. Insert the battery, making sure that the battery contacts touch
the phone's gold contacts.
2. Place the battery cover over the battery and click it into place.
3. Plug the charging cable into the USB port of the phone and
the power plug into a mains outlet.
Charge the battery for at least four hours before the rst time you
use it. Only use batteries and chargers that are permitted for use
with this specic model.
ENGLISH–07
1.3 Turning on the phone
• Press and hold the key for at least two seconds until
the emporia logo appears. It will take a few seconds for the
homescreen to be displayed.
• To turn the phone o, press and hold the key
for 2seconds again.
1.4 Entering a PIN code
• Enter the four-digit PIN code for your SIM card when asked
todo so and conrm the entry.
• You can change or turn o the PIN code in Menu _Settings
_More settings _SIM card lock.
You have a maximum of three attempts to enter the correct
number. If you enter the wrong number three times in a row, you
will only be able to unblock the SIM card with the PUK code. You
will nd your original PIN code and PUK code in the documents
supplied with your SIM card by your network operator.
1.5 Saving battery power
After a few seconds of inactivity, the display will turn o to
save battery power. In the event of an incoming call or you
pressing any key, the screen will automatically light up again.
ENGLISH–08
2. SETTING UP YOUR PHONE
When you use a new SIM card for the rst time, you need to set
the language, date, time and any data connections. You can also
congure and change these later in Menu _Settings if you wish
(See »11. Settings« on page 24).
If you use the phone's mobile data facility, your network tari
must include mobile data. Ask your retailer or network provider for
more information.
2.1 Setting up a messaging app
1. When on the home screen, press the chat app key and
select YES to conrm your answer to the security question.
2. Select the messaging app you want to install.
You can choose from Signal, Telegram and WhatsApp.
3. Pressing the chat app key again now will open
themessaging app you've selected straight away.
More information on setting up a messaging app is available in
the messaging app manual, which is supplied separately.
ENGLISH–09
2.2 Personalising the menu
• The menu has been preset to display the following functions:
Contacts, Messages, Chat app, Calendar, Camera,
Photo album, Settings and Applications.
• The placement of each of these functions can be altered
individually, apart from that of the unmovable Applications
button.
• To replace a function with another one, tap and hold one of
the buttons for approx. 3seconds and select your chosen
function from the list that appears.
2.3 Updating your system and apps
Updates are not performed automatically on the
emporiaTOUCHsmart. When a system update is available,
youwill receive a notice in the info centre.
Always carry out these updates.
(See »14. System updates« on page 32)
If the notice Update app appears when you're opening your
messaging app, proceed as follows:
4. Tap on Download and grant permission to any requests.
5. Go to the info centre and tap on the downloaded document.
6. Allow Install unknown apps and answer the
securityquestions.
7. The new version of your messaging app will be installed.
ENGLISH–10
3. USING THE PHONE
This phone can be controlled both via its touchscreen and via its
numeric keypad and navigation ring. In the following, operating
the phone using the keys has been prioritised.
3.1 Using the home screen
• Left function key : opens the menu
• Right function key :opens the info centre
(can be made visible for present notications)
• Phone book : opens Contacts
• Camera :opens the photo function
• key: opens your call history
• Chat app key: opens the messaging app installed
3.2 Dual-function keys
Some keys have additional functions if they are pressed and
held down for a few seconds:
•
1
key: allows you to listen to your voicemail
Changing your voicemail settings:
Menu _Contacts _Settings _Voicemail _Setup
_Voicemail number
• key: + for country code, e.g. +49 for Germany
• key: turns the torch on continuously
