Orb™Hub Module
Gas, Energy, Stretch.
Our Orb Hub Module is a central hub that connects to up to four Zoë™ Culture Modules.
It provides a simple solution for installing and operating our system within the lab environment.
The sphere acts as a transformer by harvesting CO2and electricity from standard lab
connections, and outputs the precise balance of air and energy required by our Zoë
Culture Modules for optimum cell culture performance.
The Orb Hub Module also supplies the vacuum pump functionality required for automated
control of the dynamic mechanical forces the Zoë Culture Modules require for Organ-Chips
that require breathing motions or peristalsis — such as the lung or intestine.
Our work is directed towards a clear goal — to democratize Organs-on-Chips technology and
create an easy-to-use research platform that emulates human biology for understanding how
diseases, medicines, chemicals, and foods, aect human health.
This user guide contains important information to safely and eectively operate the Orb-HM1™ instrument.
Please ensure that all users thoroughly read and understand this guide before operation.
This product is for research use only.
1 2 3
Introduction
System Components
Specifications
General, Functional & Technical
Safety
Information & Precautions
Page 9 Page 15 Page 19
Introduction
User Guide
Table of Contents
Orb™Hub Module (HM1) / Table of Contents
Page 7
4 5 6
Installation
Equipment & Procedure
Use
Interface & Control Panel
Page 23 Page 31 Page 35
Use
Care
Maintenance & Troubleshooting
Page 9
Introduction
Page 9
1
This section contains an overview of the Orb™Hub Module
and its functions. The Orb Hub Module provides the power,
gas mixture, and vacuum required for Organ-Chip cell culture.
It can generate the appropriate gas mixture from an external
100% carbon dioxide supply, or from a portable carbon dioxide
canister for increased flexibility. The Orb Hub Module can
support up to four Zoë™Culture Modules simultaneously, which
equates to up to 48 Organ-Chips.
Orb-HM1™
System Components
Orb™Hub Module (HM1) / Introduction
The Orb™ Hub Module provides all the necessary elements to power and
run up to four Zoë™ Culture Modules at once. These elements include
mixed gas, vacuum, and power. The Orb Hub Module takes 100% carbon
dioxide from one of two sources, mixes the CO2with air, and outputs a gas
mixture that contains 5% CO2. The CO2sources can be a direct line from an
external 100% CO2source, such as one that provides CO2to incubators, or a
portable CO2canister. The CO2canister is installed directly onto the Orb Hub
Module in the center of the Control Panel. The Orb Hub Module generates
the vacuum required to apply Organ-Chip stretching, and contains four
individual power ports.
Important note: this user guide covers the basic operation of the Orb
Hub Module. For specific protocols on using the Organ-Chips and Pod™
assemblies to culture cells, please refer to the appropriate Organ-Chip
documentation.
