Entel RP500 Series Montageanleitung
HOWTOPLACEARP500IN
PROGRAMMINGMODE
Rev.1.1TechnicalSupportBulletin
Page:1 /3 ©
Copyright Entel UK 2012 All Rights Reserved REF: ED029
1
1
G
GE
EN
NE
ER
RA
AL
L
D
DE
ES
SC
CR
RI
IP
PT
TI
IO
ON
N:
:
ThisdocumentoutlineshowtoplaceanEntelRP500seriesrepeaterintoprogrammingmodesothatitcanbe
configuredusingEntelProgrammer.Seethe“EntelProgrammerUserGuide”forinformationonhowtoloadthe
RPseriesprogrammerfiles.
2
2
R
RE
EQ
QU
UI
IR
RE
EM
ME
EN
NT
TS
S:
:
EntelRP500SeriesRepeater.
EntelCPROGRPRepeaterProgrammingLead.
3
3
P
PL
LA
AC
CI
IN
NG
G
A
A
R
RE
EP
PE
EA
AT
TE
ER
R
I
IN
N
P
PR
RO
OG
GR
RA
AM
MM
MI
IN
NG
G
M
MO
OD
DE
E:
:
Toplacearepeaterintoprogrammingmode:
3.1 Ensuretherepeateristurnedoff.
3.2 Ensurethe"Talk‐ThroughOn/Off"buttononthefrontpaneloftherepeaterissettoon,sothatthe
buttonisinthe"out"position.
3.3 ConnecttheprogrammingleadbetweenyourPCandtheRepeater.
Page:2 /3 © Copyright Entel UK 2012 All Rights Reserved REF: ED029
3.4 Whilepressing&holdingthebuttonontheprogrammingleadturnonthebasestation.
3.5 Releasetheswitchontheprogramminglead.
3.6 Pushinthetalkthroughbuttononthefrontpaneloftherepeater.
Therepeaterwillnowbeinprogrammingmode,thiswillbeindicatedbytheRedTXLEDonthefrontpanelofthe
repeaterflashingon/offandtheGreenRXLEDconstantlyglowing.
Page:3 /3 © Copyright Entel UK 2012 All Rights Reserved REF: ED029
4
4
R
RE
ES
SO
OL
LV
VI
IN
NG
G
C
CO
ON
NN
NE
EC
CT
TI
IO
ON
N
I
IS
SS
SU
UE
ES
S:
:
Ifyouareexperiencingaproblemplacingarepeaterinprogrammingmodeyoushouldperformacompletereset
oftherepeaterby:
4.1 Switchingoffthemainspowertotherepeaterusingtheswitchattherearoftherepeaterormainssocket.
4.2 Turnontherepeaterusingthefrontrotarypowerswitchtoremoveanyresidualcharge,thiswillcausethe
poweronLEDtomomentarypowerup&thenpowerdown.
4.3 OncethepoweronLEDhascompletelyextinguished,switchofftherepeaterusingthefrontrotarypower
switchandleavetherepeaterfor30seconds.
4.4 Switchthemainspowerbackon.
4.5 Therepeaterwillnowbereset,repeatthestepsinsection3.
PleaseNote:Itisimportanttocompletelydischargetherepeaterbeforeyoupoweritbackon.
