Operation Manual

Control Console Operation Manual Rev 0400809.doc

ENVIRCO

Control Console

Models: CC1-10 (Part No. 63971-001)

CC1-25 (Part No. 63971-002)

CC1-50 (Part No. 63971-003)

ENVIRCO Control Console

Operation Manual

Page 2

TABLE OF CONTENTS

TITLE PAGE

1.0. SAFETY PRECAUTIONS............................................................................................................................ 3

2.0. OVERVIEW .................................................................................................................................................. 4

2.1. CONTROL CONSOLE MODELS............................................................................................................. 4

2.2. MAIN FUNCTIONS............................................................................................................................... 4

2.3. FEATURES......................................................................................................................................... 4

2.4. BENEFITS .......................................................................................................................................... 4

3.0. SPECIFICATIONS........................................................................................................................................ 5

3.1. ELECTRICAL SPECIFICATIONS............................................................................................................. 5

3.2. ELEVATION AND DIMENSIONS ............................................................................................................. 5

4.0. INSTALLATION ........................................................................................................................................... 6

4.1. NETWORK WIRING ............................................................................................................................. 6

4.2. CONTROL CONSOLE INSTALLATION TEMPLATE..................................................................................... 7

5.0. CONTROL CONSOLE OPERATION........................................................................................................... 8

5.1. FRONT PANEL FEATURES................................................................................................................... 8

5.2. POWER ON........................................................................................................................................ 8

5.3. STANDBY MONITOR MODE ................................................................................................................. 9

5.4. USER MONITOR MODE ..................................................................................................................... 10

5.5. USER ADJUST MODE........................................................................................................................ 10

5.6. OPTION MENU ................................................................................................................................. 11

5.7. ACCESS LEVELS .............................................................................................................................. 12

6.0. LIMITED WARRANTY ............................................................................................................................... 13

ENVIRCO Control Console

Operation Manual

Page 3

1.0. Safety Precautions

Please read and save the following important safety information regarding the

VOR-12 Surgery Isolator prior to unit operation.

To reduce the risk of fire, electrical shock or injury to persons, observe the following:

• Installation work and electrical wiring for the Control Console and other clean system

equipment must be done by a qualified person(s) in accordance with all applicable codes

and standards, including fire-rated construction.

• When cutting or drilling into a wall or ceiling, do not damage electrical wiring or other hidden

utilities.

• Service to the Control Console cannot be performed in the field. Returned equipment still

under warranty to Envirco.

• Before trying to remove the Control Console from the clean system it controls, switch power

off for the entire clean system at service panel and lock service panel to prevent power from

being switched on accidentally, and follow proper procedures as necessary.

• Use this unit only in the manner intended by the manufacturer. If you have questions,

please contact:

ENVIRCO CORPORATION FEDDERS INTERNATIONAL

Envirco Office Headquarters

5601 Balloon Fiesta Parkway N.E. No. 268 Xi Zang Road (M)

Albuquerque, New Mexico 87113 Haungpu District, Shanghai 200001

U.S.A. PRC

Tel : (505) 345-3561 Tel : (86) 512 6258 7180

Fax : (505) 345-8875 Fax : (86) 512 6258 0035

Email: info@envirco.com Email: [email protected]

TRION LTD. FEDDERS INTERNATIONAL, INC.

The Cavendish Centre DP Computers Building

Winnall Close 128 Joo Seng Road #05-01

Winchester, Hampshire, SO23 0LB, UK Singapore 368356

Tel : 44 1962 840465 Tel : 65 286 0995

Fax : 44 1962 828619 Fax : 65 286 0859

Email: info@trion.co.uk Email: infoAsia@envirco.com

ENVIRCO Control Console

Operation Manual

Page 4

2.0. Overview

The Envirco Control Console combines intelligent speed control with industry standard

MODBUS®networking. The versatile design allows control of an array of MAC 10 XL installed

Envirco Phase Controllers or “Smart” MAC 10 units linked to an Envirco DC Controller.

The console combines a user interface with MODBUS master capability so no additional

networking components are needed and no MODBUS knowledge is necessary to install a

network. Once the console has automatically scanned the network, only a few simple

configuration selections are required.

2.1. Control Console Models

Envirco CC1-Series Control Console

Model No. Addresses No. of MAC 10 XL FFUs No. of “Smart” MAC 10 Units

CC1-10 10 up to 80 up to 10

CC1-25 25 up to 200 up to 25

CC1-50 50 up to 400 up to 50

2.2. Main Functions

• Individual address speed adjustment

• Global address speed adjustment

• Global address set-back speed adjustment

2.3. Features

• 7-Seginent LED Control Console Display

• Dual rotary dials for easy option selection and system adjustments

• “Set Speed Memory” resets to last setting under power loss

• Global standby feature

• Pre-programmed user access levels and pass-codes to prevent tampering or

accidental system changes

2.4. Benefits

• Quick and easy system air balancing of Envirco Fan Filter Units

• Global standby feature for energy savings

• Simple set-up and wall-mount Control Console installation

• No installer configuration required

ENVIRCO Control Console

Operation Manual

3.0. Specifications

3.1. Electrical Specifications

Supply Voltage: 6-12 Vdc

Typical Supply Current: 90 mA

Network Transceivers: 2-wire, 1/8 unit load type

Operating Temperature: 0-40° Celsius (32-104°F)

DC Power Connector: 2.1 mm DC power jack

MODBUS network: RJ45 socket

3.2. Elevation and Dimensions

Page 5

ENVIRCO Control Console

Operation Manual

Page 6

4.0. Installation

The Envirco Control Systems are engineered for easy installation. However testing either

before permanent installation or as the system is installed is strongly recommended.

The Control Console can be wall installed in the cleanroom or at a remote location, however,

the maximum recommended distance from the beginning to the end of the daisy chain should

not exceed 800 linear feet.

4.1. Network Wiring

Note: Cabling shall be provided and installed by others. Network cable requirements

should be specified based on:

A network is constructed by simply daisy-chaining MAC 10 XL installed Envirco Phase

Controllers or “Smart” MAC 10 installed DC Controllers from the Control Console.

Specific network wiring information can be found in the Envirco MAC 10 XL Control

System or MAC 10 DC Control System operation manuals.

Network cable requirements should be specified based on:

• Distance between nodes

• Total network length

• Noisy electrical environment

• Environmental conditions

• Mechanical issues

Once the Control Console has been connected to at least one phase controlled MAC 10

XL or “Smart” MAC 10 installed DC Controller, power can be applied. The Control

Console will automatically scan the network.

Each Phase Controller or DC Controlled “Smart” MAC 10 FFU should be given a unique

address within the Control Console’s available address range (determined by model

number.) The addresses do not need to be contiguous, but contiguous addressing will

make operator functions easier.

ENVIRCO Control Console

Operation Manual

4.2. Control Console Installation Template

Page 7

ENVIRCO Control Console

Operation Manual

5.0. Control Console Operation

5.1. Front Panel Features

• Rotate to Select Unit or

Option Menu.

•

Push to enter Option Menu

Selected Address

Status of Selected Unit

Speed of Selected Unit • Rotate to Adjust Speed or

tion Settin

5.2. Power On

At power-on, the Control Console displays a series of parameters including model

number on the three LED displays for about one second. The Control Console then

cycles all segments in display to confirm that the display is functional. Once display

cycling is complete, the Control Console then scans all addresses valid for that model

(10, 25 or 50.)

If no MAC 10 XL installed Envirco Phase Controllers or “Smart” MAC 10 units linked to

an Envirco DC Controller is detected, the Control Console repeats the scan sequence

until at least one unit is found.

Scan Address

Number of Units found No Effect

No Effect

Figure 1: Front Panel Functions During Power-On

Page 8

ENVIRCO Control Console

Operation Manual

5.3. Standby Monitor Mode

The Control Console immediately enters standby monitor mode at the conclusion of

power-on scanning. The Control Console remains in standby monitor mode until one of

the two dials are rotated. If the dials are not adjusted for a period of 30 seconds, the

Control Console will revert to standby monitor mode.

In standby monitor mode, the Control Console repeatedly polls all units detected during

power-on scanning. Unused motor addresses are skipped, but the highest address

must be within range of the Control Console model settings (10, 25 or 50.)

Address

Page 9

Figure 2: Standby Monitor Mode Front Panel Functions

The Control Console polls each Phase Controller or “Smart” MAC 10 FFU while

displaying status information on each unit for about 2 seconds. The following

information is displayed:

A. MODBUS Address of unit monitored (Top LED)

B. Pressure Switch Status

• “PG” for Pressure Good

• “PF” for Pressure Fault

• If Pressure Switches are not enabled, the display will be blank

• If the Control Console is in Low Speed Mode, then “LO” will be displayed instead

of the pressure switch status

C. Set Speed or Blank Display (Center LED)

• Displays Set speed in percent

• This value is read from MODBUS register 2.

Note: If no response is received, the middle and lower LED shall display “—“

Set Speed

Any rotation to exit standby

monitor mode

Pressure Switch Status

ENVIRCO Control Console

Operation Manual

5.4. User Monitor Mode

If any dial activity is detected, the Control Console leaves standby monitor mode and

enters user monitor mode. In this mode, any unit can be selected by rotating the Select

dial.

Figure 3: User Monitor Mode Front Panel Functions

Note: If the Select dial is moved past the valid address range, the select display shows

"OP". Pushing the Select dial enters the Option Menu.

Page 10

5.5. User Adjust Mode

This mode is identical to User Monitor mode, except that the set speed of any motor can

be adjusted.

Address

Set Speed No Effect

Rotate to select address.

Press to lock selection.

Pressure Switch Status

Address

Set Speed 2. Adjust Set Speed

Up or Down.

1. Rotate to select address.

Pressure Switch Status

Figure 4: User Adjust Mode Front Panel Functions

If the Select dial is moved below the valid address range, the select display shows "OP".

The current access level is also displayed. Pushing the Select dial enters the Option

Menu.

The Control Console writes the set speed as a percentage of the maximum speed (0-

99%). If power fails, each Digital Speed Controller will run at the most recent speed

selected.
