Epson CX5400 - Stylus Color Inkjet Montageanleitung

Macintosh OS X Software

Installation

If you’re using Macintosh OS X 10.2.x to 10.3.x, follow the instructions

on the front of the Start Here sheet to set up your CX5400 and to load ink

cartridges and paper. Then follow the steps below to install the CX5400

software.

1. Insert the CX5400 Software CD-ROM in your computer.

Note:

The software on the CD-ROM is compatible with Macintosh OS X 10.2.x

through 10.3.x.

2. Double-click the EPSON CD-ROM icon on your desktop.

3. Double-click the Mac OS X folder, then double-click the EPSON

icon.

4. When you see a message about disabling your antivirus software, click

Continue.

5. At the license agreement, click Agree.

CD installation booklet CPD-17853.fm Page 1 Friday, February 6, 2004 3:11 PM

6. When the Software Installation screen appears, click Install.

7. Enter your administrator password, if necessary, and click OK.

Click Install

CD installation booklet CPD-17853.fm Page 2 Friday, February 6, 2004 3:11 PM

8. When you see the EPSON Scan Installer screen, click Install.

9. After the files finish installing on your Macintosh, click Quit.

10.Follow the on-screen instructions to install the rest of the software,

including EPSON Smart Panel,

™ArcSoft PhotoImpression,

™and the

EPSON Information Center.

Note:

You may have to enter your administrator password before installing

additional components. Click Quit, if prompted, after each installation.

11.After all the components have finished installing, click Exit.

12.When you see the Product Registration screen, register your CX5400.

13.Close any open screens, remove the CD-ROM, and restart your

Macintosh to fully enable your software.

Click Install

CD installation booklet CPD-17853.fm Page 3 Friday, February 6, 2004 3:11 PM

Adding the Stylus CX5400 to the Printer List

1. Make sure your CX5400 is turned on.

2. Remove the sticker from the USB port on the side of the CX5400.

3. Connect the square end of the USB cable to the CX5400, then connect

the flat end to any available USB port on your Macintosh.

USB cable

CD installation booklet CPD-17853.fm Page 4 Friday, February 6, 2004 3:11 PM

4. Open the Applications folder on your OS drive, then open the

Utilities folder and start Print Center (OS 10.2.x) or the Printer

Setup Utility (OS 10.3.x).

Note:

If you see this screen, click Add.

5. On the Printer List screen, click the Add button.

6. Open the pull-down menu at the top of the next screen and select

EPSON USB.

Select

EPSON

USB

CD installation booklet CPD-17853.fm Page 5 Friday, February 6, 2004 3:11 PM

7. Click Stylus CX5400.

Note: If the CX5400 doesn’t appear, make sure it is turned on and

securely connected to your Macintosh.

8. Open the Page Setup pull-down menu at the bottom of the screen and

select All.

9. Click the Add button. You see the Printer List again with the Borderless

feature available.

10.Close the Printer List.

Click here

Then select All

CD installation booklet CPD-17853.fm Page 6 Friday, February 6, 2004 3:11 PM

Selecting the Stylus CX5400 in EPSON Photo Print

1. Double-click the EPSON Smart Panel icon on your desktop.

2. Click Reprint Photos.

3. When you see this screen, click No.

4. Click the scanner selection box shown below, choose EPSON Stylus

CX5400, then click Select.

Click No

Click here

CD installation booklet CPD-17853.fm Page 7 Friday, February 6, 2004 3:11 PM

5. Close the EPSON Photo Print screen, then close EPSON Smart Panel.

You’re ready to scan, copy, and print!

If you have any problems or questions, see the back of the Start Here sheet

for help.

EPSON and EPSON Stylus are registered trademarks and EPSON Smart Panel is a

trademark of SEIKO EPSON CORPORATION.

General Notice: Other product names used herein are for identification purposes

only and may be trademarks of their respective owners. EPSON disclaims any and

all rights in those marks.

Printed in USA

CD installation booklet CPD-17853.fm Page 8 Friday, February 6, 2004 3:11 PM
