A captivating combination

of quality and performance

With resolution up to 2544 x 1904 pixels, the

EPSON PhotoPC 3100Z combines top-notch

image quality with easy operation and high

performance features like its revolutionary

PRINT Image Matching™technology.

Up to 4.8 megapixel resolution with EPSON HyPict™

technology

■

Increases the 3.3 megapixel CCD sensor resolution

to 2544 x 1904 pixels for prints up to 11" x 17"

Maximum 6X zoom

■

Includes 3X optical zoom and 2X digital zoom;

equivalent to 34mm-102mm on a 35mm camera

Innovative print tools

■

Uses PRINT Image Matching technology to optimize

images captured and produce the best quality prints

possible on PRINT Image Matching-enabled photo

printers. Includes a print button utilizing Digital Print

Order Format (DPOF) for quick, easy selection of

images to print.

Aperture and shutter priority

■

Advanced features that can be fully automated or

manually controlled

Web-ready audio and video clip capability

■

Records video clips with sound, up to 25 seconds

at 15 frames per second (320 x 240 pixels)

16MB CompactFlash™memory card included

■

Stores up to 199 standard resolution images; supports

CompactFlash memory cards up to 256MB

Hot shoe and add-on lens support

■

Supports optional external flash units and optional

close-up, wide-angle, or telephoto converter lenses

and filters

Key Features

••••••••

••••

••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••

••••

Camera Specifications

CCD Sensor

1/1.8 inch color CCD (3.34 million pixels)

File Format

JPEG (EXIF), TIFF uncompressed, DCF (Design Rule for Camera File System)

and DPOF (Digital Print Order Format) compliant

Resolution Modes

HyPict 2544 x 1904 pixels

Tiff Uncompressed 2048 x 1536 pixels

Super Fine 2048 x 1536 pixels

Fine 1600 x 1200 pixels

Standard 640 x 480 pixels

Color Modes

24-bit color and monochrome

Lens

Focal length 7 –21mm

(equivalent to 34mm to 102mm lens on a 35mm film camera)

7 elements in 8 group construction (2 aspherical lenses)

Lens adapter included for optional add on lenses

Auto-Focus Range (Automatic and Manual)

Normal mode 20" to infinity (0.5m –infinity)

Macro mode 2.36" to 20" (0.06m - 0.5m)

User adjustable 3’, 10’, 50’

Capture Modes

Full Auto, program (sports, landscape, portrait, normal), manual, macro,

continuous shoot, interval shooting, stitching, and 2x digital zoom

Built-in Microphone and Speaker

Capable of recording up to 10 second voice message

Listen to the voice message on the camera, through a computer

or television

Audio File format WAV (PC), AIFF (MAC)

Audio andVideo Clip

QuickTime Motion JPEG (15 frames/sec)

Max recording time 25 seconds (35 seconds when sound is off)

LCD Monitor

1.8" color LCD monitor

Supports instant preview, playback, delete, and slide show

Picture Storage Capacity

16MB CompactFlash card

Average number of images (standard compression) stored on 16MB:

HyPic 12 images

Super Fine 29 images

Fine 56 images

Standard 199 images

Uncompressed TIFF 1 image (9MB)

OpticalViewfinder

Real-image optical viewfinder and diopter

Shutter Speed (Automatic and Shutter Priority)

Mechanical shutter and electronic control shutter

Flash On 1/30 seconds –1/1000 seconds

Slow sync and Flash OFF 1/2 seconds –1/1000 seconds

Manual exposure: 8 seconds –1/500 seconds

Apert

F2, 2.3

Expo

Progra

(0.5/0.

White

Built-

Range

Modes

Hot Sh

Sensi

Autom

User a

Utilizes

numbe

SelfT

Tripod

Minim

CD-RO

monito

16-bit s

Video

Provid

Powe

Includ

Accep

Option

Conte

EPSON

comm

strap,

Enviro

Tempe

Humid

Came

Dimen

Weigh

Warra

One ye

ystem)

macro,

Aperture (Automatic and Aperture Priority)

F2, 2.3, 2.8, 4, 5.6, 8

Exposure Control

Program auto exposure with manual +/- 2.0 exposure value adjustment

(0.5/0.2 EV increments); spot and matrix metering

White Balance Modes

Auto/Fixed 5200°K/Custom

Built-in Flash

Range 20" –13.8' (normal),

8" –20" (macro)

Modes Auto Flash, Flash On, Flash Off,

Red-eye Reduction, Slow Synchronized

Hot Shoe for adding optional external flash units

Sensitivity

Equivalent to ISO 100/200/400

PRINT Image Matching

Automatically sets print commands for compatible printers.

User adjustable brightness and sharpness settings.

Print Button

Utilizes Digital Print Order Format (DPOF). Index ON/OFF, mark image to print, mark

number of copies. Compatible with printers that read DPOF files.

SelfTimer

10 seconds (fixed)

Tripod Mount

Built-in

Minimum System Requirements

CD-ROM drive, 32MB RAM, 30MB of available hard disk space, VGA

monitor minimum resolution of 640 x 480 with 256 colors (24-bit recommended),

16-bit sound card and speakers (for audio playback only), USB connection

Windows

Pentium

166 MHz or higher processor,

Windows 98/Me/2000

Macintosh

System 8.5.1 to 9.1

Power Macintosh G3, G4 or iMac

Video Interface

Provides NTSC and PAL video output signal

Power

Includes 4 AA alkaline batteries

Accepts 4 AA size batteries (alkaline, lithium, Ni-Cd and NiMH)

Optional AC adapter, rechargeable batteries and charger

Contents

EPSON PhotoPC 3100Z digital camera, 16MB CompactFlash card, USB

communication cable, video cable, neck strap, soft case, lens cap with

strap, lens adapter, User’s Guide, four AA size Alkaline batteries

Environmental Requirements (Operating range)

Temperature 41°to 95°F (5°through 35°C)

Humidity 30% to 80% (non-condensing)

Camera Dimensions andWeight

Dimensions 4.25" x 3.50" x 2.56"

Weight without batteries 12.9 oz.

Warranty

One year limited Camera

Specifications and terms are subject to change without notice. EPSON is a registered trademark and PRINT Image Matching is a

trademark of Seiko Epson Corporation. Epson Connection is a service mark and HyPict is a trademark of Epson America, Inc. All

other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any

Epson America, Inc.

3840 Kilroy Airport Way

Long Beach, CA 90806

Epson Latin America, Inc.

6303 Blue Lagoon Drive

Miami, FL 33126

Epson Canada, Ltd.

550 McNicoll

Willowdale, Ontario M2H 2E1

• • •

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •

• • •

www.epson.com
