ContinuousInkSupplySystem

for

Epson StylusPhoto 790

InstallationInstruction

ForSTPrefilledVersion

WithAutoResetChips

ThisVersion oftheContinuousInkFlowSystemcomeswithPrefilledCartridgesand

AutoResetChips.You justneedtofilltheReservoirbottles and print!Thewhole

operationisveryeasy.It sreallyaneffectivetooltosaveyourmoney.

CISforEPSONStylusPhoto790Instruction

Thankyou forpurchasingSTContinuousInkSupplySystem.Weappreciate

yoursupportandwilltryourbesttomakeyourexperiencewithourproductsa

pleasantone.Printinghasbeen adifferentexperienceeversinceyou installed

STContinuousInkSupplysystemon yourownprinter.Justimagining being

abletoprint withoutregardtothe inklevelinthoseexpensivelittlecartridges.

Pleasetakeyourtimeinstalling STContinuousInkSupplysystem.Donot

removeyouroldcartridgeuntilyouhavethe STCISsystemprimed and readyto

install(topreventthedryingofheads).Inaddition,makesureyouaregetting

perfectnozzlechecks beforeinstallingthe STCISsystem.The STCISsystem

won t be abletoworkproperlyif thenozzlesarepreviouslyclogged.

Mostpeoplegetaperfectnozzlecheck thefirsttimeafterinstalling the ST

ContinuousInkSupplysystem;othersmayneed toruntwoorthree cleaning

cyclesorlet theprintersit forawhilebeforetheyget theperfect results.

1General Guide:

1)Components

ACISsystem1setB Airfilters6pcs C SupportArm1set

DRefill Kit6pcs E Instruction CD 1pc

2)Openingboxinspection

aCheck whetherall the accessoriesareready.

bCheck whetherthere'sthe leakageofthe CISS,whethersometubeshavebeen

separated fromthe CISS,whetherthereareairbubblesinthe tube(Ifthereexistsmore

than 20CMairspace, pleasekindlytocontactwiththe localdealer)

2Printertesting:

1)Check whetherthe printerisinnormalcondition,likemechanicalstatus,lubrication

statusetc.

2)Print testinglinestoensuretheprintinghead isgood condition.

3)Print picturestosee whethertheprintingimageisok.

3InstallationProcedures:

1)First step

PuttheCISS ontheleft sidePull out thesmall rubberplug Place6pcsofairfiltersinto

oftheprinter.Inthemeantimefromtheairholeasaboveairholes,thethickerside

placeallthetubesatcorrectpictureshown.isdownintotank.

position.

2）Secondstep: Removecartridge

Press theinkcartridgereplaceMovethecartridge-cartothe cartridgeUnplug thepower

button replaceposition

3）Thirdstep: Setupthe ContinuousInkSupplySystem

Removeoriginalcartridge Insertourno-spongecartridgeClosethecoverforcartridge

intoprintercarefully

4)Fourthstep: FixSupportArm

TearoffthestickerFixthearmonthe8cmrightfarfromTearoffthesticker

you printer

FixthebalancearmTearoffthestickerofclampAttachedtheclamponyourprinter

and letitparallelwithprinter

5) Fivethstep: Install tubeline

InserttubellinethroughthearmFinished

6)SixthStep:Adjust thetubeline

Adjustthetubeline,removetheMakesuretublinewill notmeetMakesurethelengh oftublineis

Cartridge-carbackandforthprinterwhen printing enoughtoreachthefarleft andright

Too long twistPerfect

7)Seventhstep

Insterttheplug Turnon thepowerswitchcheck

wetherallthing isusual

8)Eighthstep: Nozzlecheck

Usual

Brokenline

If appearlikethis,plsclean prinerhead

Thenozzlecheck patternsareinbroken-line,mostlybecauseofsmall duskenteredintothenozzle,after

repeatedcleaning,ifthereisstillafewbroken line,plslettheprinterdon tworkabout1hour,thenprint

thenozzlecheck pattern,maybeit workswell.

4ResetProcedure:

Ifthe indicatorlightflashingwhen printing,ittellsthatyouneedtoresetthechiptofull

status.Pleaseturnoffyourprinterforabout30secondsandswitchitback on.Inkmeterbar

shall showfullink.Youcanstart printingasusual.

5Refill Ink:

Pleasepayattention totheinklevelinthereservoirs;ifthe inklevelisbelow1CMasthe

abovepictureshown, pleaseuserefill kitstofillinkintoReservoirbottles.Carefullypull out

the rubberplugsfromthe refillholes.(thereispossibilityof inkspattering.Becareful!)Refill

inkaccordingtothecolorinshortsupply. Thenputtherubberback.(Pleasekeeptheprinter

and the reservoirat the samehorizontallineduringthe process ofrefillingink.)

6Attentionformaintenance:

Takeoutthe CISS including the innercartridgesand othercomponents.Then

removesupportarmfromprinter,and placethe originalcartridgesin.Please

inquirelocaldealerbeforesending tomaintenance.

Notice:

1.Pleasedon ttakeoutcartridge atrandomafterinstalling theCISsystem.

Keep the reservoirbottleson thesamelevelwiththe printer.

2.Trytokeep at least 1/2inchof inkinthe bottles, asyou don twanttorun out

of inkand drawairintothecartridge.

3. Don t placethe ReservoirBottleshigherorlowermuchthan the printer.

4.Tobeusedinadryplacebetween 15and 35degree.Avoidexposuretodirect

sunlight.

5.Don tputthe continuousinksupplysystemsreversedorleaningduring the

shipment. Pleasemakesureallthe inkfillingholesandVentilation holesare

closedtightlyduring the transportation. Otherwise, the inkshallleakout.

6. Don t swaythe cartridge frequently. It maycauseinkleakage.

7.Don tpull outthe connectorof cartridge anddon ttearoffadhesivetapeatthe

bottomof cartridge.

Warning:

1. Not drinkable; keepit outreachof children.

2.Avoidexposuretodirectsunshineanddon tkeepitinhighorfreezing

temperature.

3.Avoidcollision and fallendown.
