Epson EMP-X3 Bedienungsanleitung

The ideal projector - at work, in a

classroom, on the move or at home

Stylish, lightweight, compact and easy to use, the

Epson EMP-X3 multi-functional projector is ideal for

office, education or mobile use. Ready to display in just

4 seconds, it’s one of the quickest projectors on the market.

Versatile, affordable and packed with

the latest Epson technology

The Epson EMP-X3 multi-purpose

projector combines high quality

performance with the latest Epson

technology, in a sleek, stylish, easy to

use projector. The new Epson EMP-X3

has been designed to provide you with a

compact, easily transportable projector

which comes with its own carry-case. At

just 2.6kg, it is also one of the lightest

projectors in its class. As well as desktop

and mobile capability, the Epson EMP-X3

comes with enhanced installation

features, making it great as a permanent

fixture for meetings, training or

educational use.

Quick Start and Instant Off

If increased time constraints in

business seem to add to your daily

pressures, you’ll be delighted that the

Epson EMP-X3 projector takes only

4 seconds before information begins to

be displayed. It also benefits from the

Instant Off feature so there’s no

waiting around after you have finished.

Compact and lightweight - take it wherever

you go

Convenient panel control

Multi-media capability

The Epson EMP-X3 supports SXGA PC

signals, as well as being High Definition

compatible, allowing you to view higher

resolution images and movies. Optional

cables allow you to connect to other

media, such as DVD players and digital

cameras, bringing to life any presentation

in rich, multi-media formats.

E-TORL technology

Our patented E-TORL lamp ensures clear

visibility even in light rooms giving

increased brightness for lower power

consumption than standard lamps.

Smaller, brighter, more energy efficient,

the E-TORL is tomorrow’s lamp, today.

Real home cinema experience

Whatever types of movies you love, you’ll

love the way the Epson EMP-X3

gives you the sharpest, clearest, most

natural looking images. Our patented

3LCD technology gives you the brightest,

richest colours and perfectly smooth

video playback.

With 16:9 movie format compatibility and

wide angle lens, even small projection

distances create a satisfying big screen

effect.

Versatile, affordable, compact - perfect for business, the classroom and home

• Lightweight (2.6kg) and portable

• Exceptional image quality with Epson’s 3LCD technology

• Quick Start and Instant Off functions

• Convenient, intuitive function panel and remote control

• Enhanced security with password protection

• Quiet operation at only 30 dB in low brightness mode

• Brighter, more energy efficient with Epson’s exclusive E-TORL lamp

• Multi-media compatible and amazing big screen entertainment

1 3

2 2 4

All the connections you need for your

PC, TV, DVD or games console.

1. RGB in for PC input

2. RCA for composite video and audio inputs

3. S-Video

4. USB (B) for PC remote control (with optional cable)

5. RGB out for external monitor

Instant Off

On the back:

Optical zoom

Model Epson EMP-X3

Pro

ection S

stem RGB Liquid Crystal Shutter Projection System

Pro

ection Method Front / Rear / Ceiling Mount

ecification of Main Part

Size: 0.6" with MLA; Driving Method: Poly-silicon TFT Active Matrix; Pixel Number: 786432

LCD dots (1024x768) x3; Native Resolution: XGA; Aspect Ratio: 4:3; Pixel Arrangement: Stripe;

Refresh Rate: 50 Hz - 72 Hz

Projection Lens Type: Manual: zoom / focus; F-Number: 1.60-1.74; Focal Length: 18.4 mm-22.12 mm;

Zoom Ratio: 1-1.2; Lens Cover: Included

Lamp Type: 170W UHE; Life: 2000 hours (High brightness) / 3000 hours (Low brightness)

Screen Size 30" to 300" [1.1 to 11 m] (Zoom:Tele)

(Projected Distance) 30" to 300" [0.9 to 9.0 m] (Zoom:Wide) / 60" screen 1.8 - 2.1 m

Offset 10:1

High Brightness Mode 2000 ANSI lumens (Colour mode: Game, Zoom: Wide)

Low Brightness Mode 1500 ANSI lumens (Colour mode: Game, Zoom: Wide)

Contras

400:1 (Colour mode : Game, High brightness mode)

Bri

htness Uniformit

85%(Typ.) 70% (Min)

Colour Re

roduction Full Colour (16.77million colours)

Sound Out

1W Monaural

Function Effect, User Logo, A/V mute, Freeze

Remote Control Infrared Right/Left: -30 to +30 degrees / Upper/Lower: -15 to +15 degrees

Receiver Directivit

Effective Scannin

Pixel Clock: 13.5MHz to 162MHz; Horizontal: 15KHz to 92KHz; Vertical: 50Hz to 85Hz

Fre

uenc

Ran

(

Analo

)

ustment Function Projector / Remote Control: Keystone (Vertical) / Brightness / Contrast / Tint / Saturation/

Sound / Input signal etc.; Foot Adjuster: Front-centre; Tilt Angle: 0 to 10 degrees; Keystone

Correction: Vertical: -30 to +30 degrees (Zoom: Tele); Source Search; Auto Detection of

RGB/YCbCr; Operation Panel Protected Function; "Password Protected Function; (Security

function)"; Colour Mode: "PC: Photo, Presentation, Theatre, Game, sRGB, Blackboard; Video:

Sports, Presentation, Theatre, Game, sRGB, Blackboard"; Direct Power On

Analo

ue RGB I/O

Display Performance Native: 1024 x 768 dots

Input Signal Signal Type: Separate signal; Video Signal: Analogue (0.7V p-p, 75 ohm / Mac0.714Vp-p,

75ohm); Sync. Signal: Separate (positive & negative, bi-polarity 2-5Vpp) / Composite

(positive & negative, bi-polarity 2-5Vpp) / Sync-on-green (negative, 0.3Vpp); Audio Signal:

500mVrms / 47k-ohm

Input Terminal Video: Mini D-sub 15pin x 1 Blue-molding; Audio: -

Output Signal Video Signal: Analogue (0.7V p-p, 75 ohm / Mac 0.714Vp-p, 75ohm); Sync. Signal: Separate

(positive & negative,TTL) / Composite (positive & negative, TTL) / Sync. on green (negative

0.2-0.4 Vp-p)

Output Terminal Video: Mini D-sub 15pin x1 Black-molding

Video I/O

Display Performance NTSC: 560 line PAL: 560 line (Depend on observation of the multi burst pattern)

Input Signal Video Standard: NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM; Video Signal:

Composite Video (1.0Vpp/ Sync.negative, 75ohm) / S-Video (Luminous 0.714Vpp,

Chrominous 0.286Vpp, 75ohm) / Component Video (Analogue Y level 0.7V 75 ohm / Cr Cb

level +/-0.35V 75ohm/ sync.negative 0.3V or 3-state+/-0.3V on Y) / Video-RGB (0.7V p-p,

75 ohm/ Mac 0.714; Audio Signal: 500mVrms / 47k-ohm

Input Terminal Video: Composite Video: RCA (Yellow) x 1; S-Video: Mini DIN; "Component Video: Mini D-sub

15pin Blue-molding; (in common with Analogue RGB connector)"; Video-RGB: Mini D-sub

15pin Blue-molding (in common with Analogue RGB connector)

Control I/O USB I/O: I/O Terminal: USB connector series B x1 (for mouse, K/B, control)

Operatin

Temperatur

5°C to 35°C <41°F to 95°F> ( 20%-80% Humidity ) Thermal shut down > 45 °C

Start-u

Period about 4 seconds

Cool-down Period 0 seconds, Instant Off

Power Su

Volta

100-240V ±10% , 50/60Hz AC

Power Consum

tion 230V area (Europe): Lamp On: 240W; Stand-by: 5.0W

Rated Volta

e & Curren

100 - 240 VAC 2.9 - 1.2A 50/60Hz

Dimension Exclude Feet (D x W x H): 246(D) x 327(W) x 86(H) mm; Maximum Dimension (D x W x H):

246(D) x 327(W) x 98(H) mm

Wei

ht 2.6kg

Fan Noise Low Brightness Mode: 30dB

Accessories Power Cord: 1.8m; Computer Cable: 1.8m, Slim-cable with blue colour jacks, Mini D-sub 15pin

(Male) - Mini D-sub 15pin (Male); Remote Control; Battery: AAA Alkaline battery x2;

Soft Carrying Case; Frame Air Filter; Password Protect Sticker; User's manual

tions Spare Lamp: ELPLP34; Air Filter Set: ELPAF08; Soft Carrying Case: ELPKS16;

Ceiling Mount: Silver: ELPMB18

Warrant

UK - 3 year next day on site repair or replace

Ireland - 3 year next day on site repair or loan

EMP-X3 – 2GB – 11/05

Screen Diagonal (inches)

Projection Distance (wide/tele) (metres)

EPSON® is a registered trademark of SEIKO EPSON® Corporation. All other product names and other company

names used herein are for identification purposes only and may be trademarks or registered trademarks of their

respective owners. Errors and omissions excepted, all specifications are subject to change without notice.

Telephone: +44 (0) 1442 261144

E-mail: [email protected]

Fax: +44 (0) 8702 413093

www.epson.co.uk
