INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 4100 / 4200W / 4300

Using the Remote Control

Make sure batteries are installed. Follow these

tips for using the remote control:

Point the remote control at the front of the projector or at the

screen.

Stand within 49 feet (15 meters) of the projector.

Controlling the Picture

You can use the remote control to preview and select your picture

sources, temporarily turn o the picture, freeze the action, and zoom

in on the picture.

Switching Between Picture Sources

If your projector is connected to more than one computer and/or

video source, you can switch between the dierent sources:

The easiest way to select your source is to press the Search button

on the remote control (or the Source Search button on the

projector) repeatedly until you see the image you want on the

screen.

On the remote control, you can press one of the Source buttons

to select the connected device you need.

After you select a source, the screen goes dark for a moment before the

image appears.

note

If a button is pressed longer

than 30 seconds, the remote

control stops operating to

conserve battery power.

When you release the

button, normal operation

resumes.

note

Using the remote under

bright uorescent lamps or

in direct sunlight may aect

projector response.

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 4100 / 4200W / 4300

Turning Off the Picture

You can temporarily turn o the image by pressing the A/V Mute

button on the remote control. This turns the image black. To turn the

image back on, press the button again.

You can have the screen turn blue or display an image

such as a company logo when you press the A/V Mute button.

Stopping Action

Press the Freeze button on the remote control to stop the action in

your video or computer image.

To restart the action, press the Freeze button again.

Zooming Part of Your Image

You can zoom in on a portion of the image using the E-Zoom buttons

on the remote control.

1. Press the E-Zoom button on the remote control.

You see a crosshair indicating the center of the zoom-in area.

note

Because the source continues

to transmit signals, when

you resume the action, it

won’t be at the point you

stopped it.

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 4100 / 4200W / 4300

2. Use the pointer button to position the crosshair.

3. Continue pressing the E-Zoom button to enlarge the selected

area up to 4 times.

4. While the image is enlarged, you can:

Use the pointer button to move around the screen.

Press the E-Zoom button to zoom out.

5. When done, press the Esc button to return the image to its

original size.

Highlighting Your Presentation

You can display a pointer to call out important information on the

screen, and you can choose from three shapes for the pointer.

Using the Pointer Tool

1. To activate the pointer tool, press the Pointer button on the

remote control. A pointer appears on the screen.

If you prefer to use a dierent style of pointer, see the instructions

in the next section.

2. Use the pointer button on the remote control to position the

pointer on the screen.

3. When you’re done using the pointer, press the pointer button

to clear the screen.

note

You cannot use the

Progressive or Noise

Reduction features

while you are using

E-Zoom.

Pointer

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 4100 / 4200W / 4300

Choosing a Different Pointer Shape

Follow these steps to select a dierent pointer shape:

1. Press the Menu button on the remote control, highlight the

Settings menu, and press Enter. Then highlight Pointer Shape

and press Enter. You can select one of the pointer shapes shown

at the right.

2. Select the shape you want and press Enter

3. Press Menu to exit.

Operating Your Computer With the

Remote Control

With the optional wireless mouse receiver, you can use

the remote control in place of your computer’s mouse. This gives you

more exibility when delivering slideshow-style presentations, since

you won’t have to stand next to the computer to change slides.

Use the Up and Down buttons to move through slides or

pages in a presentation.

Page up or down

to change slides

or pages

Right-click

Use to move pointer

on screen

Left-click

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 4100 / 4200W / 4300

Use the pointer button to move the pointer on the screen.

Press the Enter button once to left-click, or twice to double-click.

Press the Esc button to right-click.

To drag-and-drop, hold down the Enter button. Then use the

pointer button to drag the object. When it’s where you want

it, release the Enter button.

Operating Two or More Projectors With

the Remote Control

If you’re using more than one projector, you can control all the

projectors—or just selected ones—by using the projector ID system.

To operate a projector, set the remote control’s ID to match that of

the projector. Or you can control all the projectors at once by setting

the remote control’s ID to zero.

Setting the Projector ID

The projector’s default ID is set to O. This lets it respond to

commands from any remote control. To change the ID, follow these

steps:

1. Press theMenu button on the remote control. You see the

projector’s menu screen.

2. Select Extended, press Enter, select Projector ID, then press

Enter again.

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 4100 / 4200W / 4300

3. Use the pointer button to highlight the new ID, and press

Enter to select it.

4. When you’re done, press Menu to exit.

Checking the Projector ID

You can check the projector’s ID by following these steps:

1. Move the remote control ID switch to the On position.

2. Point the remote control at the projector you want to check.

3. While holding the ID button, press the Help button. You see a

message on the screen like this:

Setting the Remote Control ID

The remote control’s default ID is zero. This lets you operate any

projector. To set it to operate a specic projector, follow these steps:

1. Move the remote control ID switch to the On position.

note

When the remote control ID

switch is in the Off position,

you can control any

projector regardless of the

projector or remote control

ID settings.

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 4100 / 4200W / 4300

2. Press and hold the ID button on the remote control.

3. While holding the

ID button, press a numbered button on the

remote control (0 through 9) to select the desired ID. Select zero

to control all projectors, or select a number to match the ID of the

projector(s) you want to operate.
